Summary of Contents for BNT PRO-100Q
- Page 1 7.1 Alignment by view finder & shading plate 7.2 Alignment using LEVEL LED 7.3 Alignment by audio tone indicator 7.4 Alarm memory function 7.5 Environment function 8.1 Four channel frequency selection 8.2 Beam power selection 8.3 Response time changeover function...
- Page 2 The PRO-100Q/200Q are quad photoelectric detectors designed to activate an alarm relay upon the detection of Intruder through 4 pulsed infrared beams. For stable operation, the PRO-100Q/200Q are equipped with the following features. ■ High power infrared The active infrared transmission is exceptionally strong with a maximum arrival distance ten times greater than the specified protection distance.
- Page 3 Mirror (upper) View finder Horizontal adjustment screw (upper) Vertical adjustment screw (upper) Shading plate Terminal Operation part View finder (see below) Vertical adjustment Horizontal screw (lower) adjustment screw (lower) Mirror(lower) Operation LED Re-transmit LED OPERATION POWER Power 10V ~ 30V DC Re-TRANSMIT (non-polarity) Beam channel (1,2)
- Page 4 * The advantage of this method is elimination of wiring from a detector or switch, back to the control panel. Note1) Max. wiring distance when two or more sets Maximum distance (meter) are connected is the above value divided Wire PRO-100Q PRO-200Q by the number of sets. Gauge 12V DC...
- Page 5 Pole Diameter 38~43 mm - Chose an appropriate mounting location for the system. Install the poles with a clear linesight between the transmitter and the receiver Clamping Screw - Loosen the transmitter’s cover mounting screw and remove (short) the cover. - Loosen the 2 unit mounting screws and remove the chassis by sliding it down againse the unit.
- Page 6 STEP 1 Rough alignment by view finder Looking through the view finder, locate the other detector in the center of the sights by adjusting vertically and horizontally. Horizontal adjustment Vertical adjustment Looking through the view finder, locate the other detector in the center of the sights by adjusting vertically and horizontally.
-
Page 7: Alarm Output
■ Beam alignment using LEVEL LED The alignment level indicators have 5 LED’s, each LED represents the level of alignment, ranging from poor to excellent. Excel Each LED will indicate 3 steps of alignment, slow flicker = okay, fast flicker=better, continuously on = best Good Fair... - Page 8 8.1) Four channel frequency selection - The beam pairs may be set at various frequency levels to avoid crosstalk between units which are stacked, in-line. Or other configurations which have the potential of spill-over transmission from to another . - Set the frequency level as illustrated. 1 ch 3 ch 3 ch...
- Page 9 Model HIGH relative to the application. For distance significantly less than the specified protection distance, the beam intensity should be reduced PRO-100Q 60 m 60~100 m to eliminate protential reflection problems. For zones reaching maximum protection distance, the beam level should be set to the...
- Page 10 Specifications Model PRO-100Q PRO-200Q Power supply DC 10V to 30V DC (non-polarity) Current comsumption 55mA or less 70mA or less ( Max 75mA or less) ( Max 100mA or less) Channel 4-channel Protection distance Outdoor 100 meter Outdoor 200 meter Response time 50msec.
- Page 11 ▣ PRO-100Q : outdoor 100m ▣ PRO-200Q : outdoor 200m • Caution : Please consult the instruction manual to ensure safe and proper operation of the product. Specification and • Caution : Please consult the instruction manual to ensure safe and proper operation of the product. Specification and design are subject to change without prior notice for improvement.
