- Page 1 UltraSystem PowerPlus INSTALLATION MANUAL Control unit MARINE GROWTH PREVENTION SYSTEM (MGPS) Manual ref: 29-01-2019...
-
Page 2: Table Of Contents
DO NOT operate the system for more than 5 MINUTES without transducers being installed and in contact with material to dissipate its energy. IF IN DOUBT SEEK PROFESSIONAL ADVICE Ultrasonic Antifouling support team: T: +44 (0) 1202 606 185 E: info@ultrasonic-antifouling.com... -
Page 3: Control Unit Location
CONTROL UNIT LOCATION The control unit should be located in a dry and ventilated locker or compartment above water line level. Water ingress into the unit must be avoided at all times. Keep away from sources of high temperatures such as heater outlets and exhaust pipes. Mount vertically to allow a good free flow of air through the vents located top and bottom of the housing. -
Page 4: Electrical Connections
CABLE LAYOUT and ELECTRICAL CONNECTIONS CABLE LAYOUT Plan the cable layout for both the power and transducer cables. All cables should be adequately secured, protected from physical damage and excessive vibration. Route cables through conduits for additional protection. DO NOT CUT AND RE-JOIN TRANSDUCER CABLE. If it is necessary to run a transducer cable through a bulkhead, a 20mm drill bit or hole saw should be used to accommodate the plug. -
Page 5: System Schematic Diagram (Dc System)
SYSTEM SCHEMATIC DIAGRAM - DC DC SYSTEM... -
Page 6: System Schematic Diagram (Ac System)
SYSTEM SCHEMATIC DIAGRAM - AC AC SYSTEM... -
Page 7: Transducer Positioning And Installation
TRANSDUCER POSITIONING and INSTALLATION For transducer positioning and installation, please refer to the separate manual enclosed which will be relevant to the application and type of transducer and mounting bracket supplied. TRANSDUCER CONNECTION TO CONTROL UNIT – IMPORTANT! Connect the transducers to the control unit output sockets (TR1, TR3, TR2 & TR4) according to the number of transducers being used as follows: 1 transducer –... -
Page 8: The Ultrasystem In Operation
THE ULTRASONIC SYSTEM IN OPERATION When the power is switched on, the system will at first initialise and run through a checking procedure, this is indicated by the green LED light flashing only. Once this procedure is completed, normally taking up to 5 seconds, both the green and red LED lights will show. -
Page 9: Troubleshooting Guide
Check the two vents (upper and lower) for blockages / obstructions. • Check the ambient temperature of the control unit’s location. If you cannot resolve any issue you have or require further assistance, please contact the technical team at Ultrasonic Antifouling Ltd. - Page 10 NOTES Serial number:...
