Summary of Contents for Hunterhelp PRO 3
- Page 1 Speak the language of nature! HUNTERHELP PRO 3 USER MANUAL...
- Page 2 Designed to attract birds and animals for viewing, taking pictures of, or culling for sanitary or research purposes, Hunterhelp PRO 3 is a dedicated digital sound producing device. It reproduces the audio pieces recorded as special format tracks on a plug-in memory card.
-
Page 3: Specifications
2. SPECIFICATIONS 85.5 х 128 х 33 Dimensions, mm Weight (with batteries out), g Maximum power, W 2˟10 Frequency response, Hz 20 - 20 000 External power, V 9 (6 АА batteries) Internal power supply, V Recommended radiating resistance, Ohm Bitrate/track discretization 16 bits/48 kHz... - Page 4 2 power on/off settings menu, volume/balance adjustment key enter, play/stop key ; escape key channel selection key selection key ‘up’ selection key ‘down’ volume ‘up’ volume ‘down’ light sensor Figure 1: Hunterhelp PRO 3 design and control elements...
-
Page 5: Getting Started
4. GETTING STARTED Internal batteries installation Press the locking mechanism to remove the battery cover. Insert the batteries (6 AA batteries or accumulator cells) observing the polarity. Note! Use only alkaline batteries. Use of zinc-carbon batteries may result in faulty operation. External power supply Remove the rubber cover to plug the external power source (battery) into connector 2 (Fig.1). -
Page 6: Key Functions
5. KEY FUNCTIONS On/Off Press and hold key 7 (Fig.1) (please see Fig.1 for all the keys described in this section). Once the device is on, the list of folders or tracks (calls) selected before the device was switched off will be shown of the display. Note! If the memory card is not inserted, the ‘no memory card’... - Page 7 Note! The number and the names of folders with calls may vary depending on the sound library recorded on the memory card. The original Hunterhelp card may have the maximum of 8 folders. Each folder may contain up to 99 tracks.
- Page 8 Channel selection Press key 11 to select between channel 1 and channel 2 as they alternate. The number of the selected channel will be shown in the upper left hand corner of the screen, while the channel activated is light-background. Playback Press keys 12 and 13 to select folder.
- Page 9 Volume control, balance and equalizer settings Volume, balance and equalizer settings can be adjusted with the playback on or off. Setting the volume, balance or equalizer with the playback off enables the user to avoid too loud sound that may scare birds or animals away.
- Page 10 Playback ON The volume scale is shown on the display. To move between the volume, balance and equalizer scales, press 8. Press keys 14/15 to adjust the volume/balance. To adjust the equalizer settings repeat the steps above. Note: the equalizer is meant for frequency correction of the calls and for frequency correction of the speakers.
- Page 11 Press keys 12, 13 to select language. To activate the language, press 9. 6.1.3. Remote control To operate the call remotely (using a radio channel), the call must be connected to the remote control device. Hunterhelp PRO 3 can be...
- Page 12 connected to only one remote control device, whereas one remote control device can be connected to as many calls as you wish. This menu item consists of two sub-menus – ‘Connect’ and ‘Disconnect’. Press 12, 13 to move between the sub-menus. ‘Connect’...
- Page 13 6.2 PLAYBACK SETTINGS menu item This menu item sets pause and call repeat pattern, and activates JBD. To navigate within this menu item press the navigation keys above. 6.2.1 Repeat and pause setting. Repeat setting This item sets the repeat pattern of the track. If repeat is activated, the track will play continuously until stopped manually.
- Page 14 00. Pause can also be disabled by activating the repeat function on the given channel. If pause function is active, the corresponding sign will appear in the upper right hand corner of the display. To escape from this menu with all the settings saved, press 8 or 10. 6.2.2 JBD JBD (Jump between dynamics) is designed to enhance the true-to-life nature of sound and the efficiency of calling (call exchange, imitation of...
- Page 15 6.3 MY FOLDER menu item My Folder menu item enables you to create and edit lists of frequently played tracks (up to 10 tracks). It consists of two sub-menus – ‘Add Call’ and ‘Delete Call’. To move between the sub-menus press 12, 13. Enter 9 to enter the target sub-menu and 10 to escape.
- Page 16 The created playlist will be available in MY FOLDER, located on the general folder list. Delete call ‘Delete Call’ edits your playlist. Select a track in the manner you select a track for payback. Press 9 to delete. The screen will show the ‘Call deleted’ message: To escape from this menu with all the settings saved, press 8 or 10.
-
Page 17: Troubleshooting
7. TROUBLESHOOTING Malfunction Possible cause Malfunction repair • Too short pressing on key 7. Hold key 7 pressed for 2 to 3 seconds. • AA batteries depleted. Replace batteries. The device won’t start. • External power source generates Replace external power voltage under 12V of current source. -
Page 18: Warranty
8. WARRANTY Thank you for the choice of our product. We guarantee trouble-free operation of Hunterhelp PRO 3 provided you observe the operating rules specified in this user manual. Warranty repair will be denied if the product shows signs of 1.
