Summary of Contents for Smarthome Group Bio-Eagle

Page 1 Bio-Eagle Users Manual Bio-Eagle Biometrics Time Attendance & Access Control...
Page 2: Table Of Contents
Directory 1. Introduction............4 1.1 Basic Concepts ............ 6 1.1.1 User Enrollment................6 1.1.2 User Verification...............7 1.1.3 Match Threshold Levels ............7 1.1.4 User ID Numbers..............8 1.1.5 Authority (status) Levels............8 1.1.6 Start-up window................8 2.1 How to place the finger ........9 2. Enrollment and Verification Procedures ..11 2.1 Enrolling Users..........
Page 3 Bio-Eagle Users Manual 4.1 Install Attendance Management System... 27 4.2 Connect PC and Bio-Eagle with RS232 ... 28 4.3 Setup PC Com port rate:115200 or 9600 ..28 4.4 Connecting and Download AC Records ... 31 4.5 Upload staff's name to TAP-01 ......35 4.6 Connect PC and TAP-01 with TCP/IP ....
Page 4: Introduction
Introduction This chapter shows the Bio-Eagle Fingerprint T&A basic concepts and how to place the finger. Figure (Model: Bio-Eagle) Figure (Model: Bio-Eagle) keypad ▲ ▼ MENU...
Page 5 Bio-Eagle Users Manual Keypad Definition Confirm the current present. Access to manage. Escape or cancel. Scroll up. Scroll down. Power button. ˉˉ ：Numerical key.
Page 6: Basic Concepts
1.1 Basic Concepts This section contains definitions and descriptions of Time Recorder Fingerprint T&A Concepts, including: ·User Enrollment ·User Verification ·Match Threshold Levels ·User ID Numbers ·Authority (Status) Levels The two most important TimeClock Fingerprint T&A Functions are user enrollment and user verification. User Enrollment 1.1.1 Enrollment is the process of create an ID number and scanning a...
Page 7: User Verification
Bio-Eagle Users Manual available. While recording the finger type is optional, it is recommended such as left or right index, so that at verification the user is prompted as to which finger to use. User Verification 1.1.2 Verification occurs when a user either enters an ID number or places a finger in the fingerprint sensor, then input password for comparison with the stored template.
Page 8: User Id Numbers
High Middle Middle High User ID Numbers 1.1.4 Before beginning fingerprint enrollment, a user is assigned User ID Number. This ID number is used to call up the fingerprint template each time that verification is requested. ID numbers are normally called up via the keypad, but they can be called up through other means such as RF Card.
Page 9: How To Place The Finger
Bio-Eagle Users Manual 2.1 How to place the finger 1.The correct way is: Place a finger flatwise on the sensor surface Place it to the center of the sensor surface 2.When registering, please place finger on sensor surface for about 1 second.
Page 10 Incorrect Ways ①Touching ②put on the left ③Put on the right ④not straight ⑤Put on the lower place Note: Please adopt the correct way to place the finger; this company assumes no responsibility for errors from the use of the Time Recorder. This company reserves the right to revise document and to make changes from time to time in the contents here of without obligation to notify any person...
Page 11: Enrollment And Verification Procedures
Bio-Eagle Users Manual of such revision or changes. Enrollment and Verification Procedures This chapter describes how to enroll and verify users on the Fingerprint T&A verification system. The following topics are included: ·Enrolling User ·Testing an Enrollment ·Enrolling a User with the Display Finger Option On ·Verifying Your Identity...
Page 12 who have better quality fingerprints; Fingerprint & Password suited few people who enrolling successful, but verification was difficult; Password enrollment suited people verification unsuccessful. To start the enrollment process, identify yourself firstly-press [Menu], enter your ID number or fingerprint, and then verify your identity.
Page 13 Bio-Eagle Users Manual Fingerprint Enrollment (1) Access the Enroll Fingerprint to press [OK], the following display: Enroll Fp New Enroll？ (2) Press [OK], the following appears: New Enroll Enroll No. (3) Input the enrolling number (the range is 1 to 65534), press [OK],...
Page 14 The last number 1 means the first fingerprint. Press [OK], the previous message continues to be displayed while the template is created. If your identity cannot be verified, you are prompted to try again. And you must restart the verification procedure (step 3). 2.
Page 15 Bio-Eagle Users Manual (4) Input the password, press [OK], the following appears: New Enroll Input Pwd ***** Pwd Affirm ***** (5) Input the password again, press [OK], the following appears: New Enroll 00008-P Note: 00008-P The last letter P means password.
Page 16 (3) Input the password (range is 1 to 65534), press [OK], the following appears: New Enroll Place Finger…… (4) If the test is successful three times in a row, the following appears: New Enroll Input Pwd ***** (5) Input your password, the following appears: New Enroll Input Pwd ***** Pwd Affirm *****...
Page 17: Testing An Enrollment
Bio-Eagle Users Manual Press [OK], the previous message continues to be displayed while the template is created. 2.2 Testing an Enrollment Ask the users to place their finger to perform a test verification. If the test was successful, you will adopt Fingerprint enrollment. If the poor quality of fingerprint, you will be recommended to use Fingerprint &...
Page 18: Start-Up Window
verification, ID number & Fingerprint. The following appears Start-up window 2.4.1 Place the finger on the sensor surface, the following appears: Fp Verify Pls. Move finger It continues for about 0.5 seconds. If the test is successful, it will say “Thank you”, the following appears: Fp Verify Enroll No 00008 ifi d！...
Page 19: Id Number & Fingerprint
Bio-Eagle Users Manual following appears: 1：1 Fp Match Enroll No 0008 Press [OK], the following appears: Pwd Affirm Enroll No 0008 Input Pwd ***** Input correct password, press [OK], the following appears: Pwd Affirm Enroll No 0008 Verfied If the password cannot be verified, the following appears:...
Page 20: Hints For Successful Enrollments
1：1 Fp Match Enroll No 0008 If your identity is verified, the following appears: 1：1 Fp Match Enroll No 00008 2.5 Hints for Successful Enrollments The fingerprint is of good quality, the verification speed will fast; otherwise, it will verify slowly or occur to FRR. In order to improve the fingerprint verification quality, the following hint appears: Table 2-1 Enrolled unsuccessful or the fingerprint of poor quality...
Page 21 Bio-Eagle Users Manual middle finger. Use fingerprints of good quality, without worn or hurt. The user usually selects the forefinger, if it was of a poor quality, you will be recommended to middle finger or ring finger. How to place the finger? Place your finger firmly and touch the sensor surface must be over 2/3.
Page 22: System Options
System Options Press the [Menu], then verify your identity. The following appears: MENU User Manage Option Sys Info Access Options, press [OK], the following appears: ▼ Option System Opt Power Mng The following topics included: System Options, Power Manage, Communication Options, Log Options and Auto Test. 3.1 System Options Access System Opt, the following appears: ▼...
Page 23: Date Time
Bio-Eagle Users Manual Date Time 3.1.1 Access Date Time, the following appears: Date Time 2004-01-02 08:24:35 To change the date, press , then input the correct date and time, press [OK] Changing the Default Language 3.1.2 Access Language, press [OK], it defaults to SCH. Press select another language.
Page 24: Power Manager
▼ Adv Option Restore Default Clear all Data Press to scroll up or down the screen to select the option. Restore Default: restore all setup information to default. Clear all Data: delete all enrolling fingerprints and logs. Delete Logs: delete all logs of flash disk. Clear Managers’...
Page 25: Communication Option
Time Recorder Fingerprint T&A support RS232, RS485, TCP/IP, whether you use Single-Board Computer (SBC) or Networking, Bio-Eagle will satisfy the user’s demands. Device Number: machine ID; the range is 1 to 255. Baud Rate: there are three options, 9600, 38400, 115200; the speed of communication is fast, recommend to use RS232;...
Page 26: Log Options
RS232: communication is RS232. RS485: communication is RS485. COMM Key: when connecting with PC, if there is a comm. Key, you need to key in it., if there is not a comm. Key, you just left the blank empty. 3.4 Log Options Access Log Opt, the following message appears: Log Opt Alm Attlog...
Page 27: Auto Test
Bio-Eagle Users Manual 3.6 Auto Test Access auto test, the following message appears: ▼ ▲ Auto Test Auto Test Run All Test Fp Reader FLASH Test Key Test In the option, you can run system device test. When the device broken down, it can analyze the cause of the device’s fault and the...
Page 28: Connect Pc And Bio-Eagle With Rs232
Connect PC and Bio-Eagle with RS232 Make sure the switch of controller is pointed at RS232/RS485 The communication for TAP-01 is RS232 “Menu”->”Option” ”Comm. Opt” ”RS232” ”Yes” Connect PC and Bio-Eagle with RS485 Setup PC Com port rate: 115200 or 9600...
Page 29 Bio-Eagle Users Manual...
Page 31: Connecting And Download Ac Records
Bio-Eagle Users Manual Connecting and Download AC Records (1)Double-click on shortcut on desktop (2)Active this product...
Page 32 (3)Click “Yes” (4)Make sure settings are correct, then click “Connect”...
Page 33 Bio-Eagle Users Manual (5)Product active succeed (6)Enter “Time Recorder Communication”, and again just do the same like step 4 (7) Check “Download user Info”, then click “Execute” button to download User name and password.
Page 34 (8) Check “Download Fp”, then click “Execute” button. (9)Click “Download all records” to download A.C. Records.
Page 35: Upload Staff's Name To Tap-01
Bio-Eagle Users Manual (10)Download successfully Upload staff's name to Bio-Eagle (1)Enter “Employee Maintenance”...
Page 36 (2)Input Names, then out of this window (3)Enter “Time Recorder Communication”...
Page 37 Bio-Eagle Users Manual (4) Click “Connect” (5) Check “Upload user info”, then click “Execute” to upload name and password.
Page 38: Connect Pc And Tap-01 With Tcp/Ip
FP’, then click on “Execute” button. 4.6 Connect PC and Bio-Eagle with TCP/IP Connect PC and Bio-Eagle with TCP/IP 1.Make sure the switch of controller is pointed at TCP/IP 2.The communication for TAP-01 is TCP/IP “Menu”->”Options” ”Comm Opt” ” IP Addr” ”213.10.15.124”(use fixed IP address.
Page 39: System Information
Bio-Eagle Users Manual Note: If the controller box is reset, please restart the box by pulling off the wire, if reset the comm. Options, please restart the Bio-Eagle. System Information Access [Menu] to Sys Info, press [OK], the following appears: ▼...
Page 40 From time to time, the optical platen, the keypad and display window require cleaning. Since working environments differ, it is not possible to define when cleaning should be performed. Following is guide: Table 5-1 Cleaning Schedule Item Cleaning Frequency Keypad and display window Cleaning when visibly dirty and hard to read.
Page 41 Bio-Eagle Users Manual (3) Using a non-abrasive and intone, pat dry. Be careful not to scratch the platen. If lint particles adhere to the platen surface, below them off when the platen is dry.
Page 42 User Manual...
