EagleEye-1™ UV-A LED LAMP INSPECTION KIT
Part No. EEX-1000

INTRODUCTION

The EagleEye-1™ EEX-1000 inspection kit contains the EEX-1000 lamp, a
palm-sized, portable, versatile,
ultra-high intensity UV-A LED for NDT testing. In addition, the lamp contains an
adjustable strap so the lamp can be worn on a helmet or directly on the head for
hands-free operation. EEX-1000 is ideal for a variety of specialized inspection
applications.
UV light emitted from this product. Avoid eye and skin exposure
to unshielded products
FOR PROFESSIONAL EXAMINATION USE ONLY
IMPORTANT SAFETY INSTRUCTIONS (Read all instructions)
•Do not operate the lamp if it has been damaged.
•Do not look directly into the UV light. Wear UV-absorbing protective eyewear
when operating this or any UV lamp. Never operate the lamp with the UV filter lens
removed.
•Never use this equipment in any manner not specified in these instructions because
your protection may be impaired.

FEATURES

•Instant-on operation. Reaches full UV-A intensity immediately.
•Lamp is equipped with antioxidant blacklight filter glass to minimize the visible
light and increase the UV light.
•Fan-less mechanical cooling keeps light source cool to maintain optimum UV-A
intensity during extended use.
•Powered by one rechargeable lithium-ion battery. Provides up to 4 hours of
continuous inspection between charges.

TECHNICAL SPECIFICATIONS

Length..............................................................................................3.75 in (9.5 cm)
Width...............................................................................................2.25 in (5.7 cm)
Height..............................................................................................1.85 in (4.7 cm)
Weight (with battery)......................................................8 oz (227 g) (with battery)
Light Source.........................................................................................1 UV-A LED
Power Requirement...................................One 3.7V, 3000mAh lithium-ion battery
Continuous Run Time...................................................................................5 hours
Charge Time..................................................................................................4 hours

KIT COMPONENTS

Unpack and inspect the components for possible damage in shipment. If any damage
is noted, immediately notify the carrier and supplier and do not use the light source.
6
5
1)EagleEye-1™ EEX-1000 UV-A LED Lamp
2)Battery Charging Cradle
3)Charging Cradle Cord Set
4)Lithium Ion Batteries (2)
5)UV-Absorbing Spectacles
6)Protective Hard Carrying Case
*Each of the AC cords is fitted with the appropriate plug for the country of
destination.
