Summary of Contents for Veloci Diamond
- Page 1 Instruction manual Veloci Diamond, Hopper, Hybrid (Sport), Solid, Spirit, Vivid...
- Page 2 Veloci manual © Bizbike 2022 powered by Bizbike Ireland | 2 Dublin Landings, Dublin, Ireland | www.bizbike.ie | customerservice@bizbike.ie | +353 1 697 2029...
-
Page 3: Table Of Contents
Contents Introduction Congratulations on the purchase of your Veloci Contact Bizbike Performing bike maintenance yourself Key to icons Warranty Safety Bike safety Transport by car Quickly on your way: Checklist before departure Electrical parts Battery Display & Control Panel Non-electrical parts... -
Page 4: Introduction
Read this manual carefully and keep it handy. - If you have any questions or comments To enjoy your Veloci for as long as possible, - To request your first free service after 500 km or please follow the recommendations and tips in within 6 months - whatever comes first. -
Page 5: Performing Bike Maintenance Yourself
Performing bike maintenance yourself: - Inflate your tires monthly to 4.5-5 bar. - Rinse your chain and chain case monthly, dry it and lubricate with chain oil. A little goes a long way: do not use too much chain oil. - Charge your battery every two months and store your battery indoors at room temperature. -
Page 6: Warranty
Warranty Warranty provision Voidance of warranty The exact warranty period is determined based on - In the following cases the warranty is void: the delivery date. You must always furnish Bizbike • Improper and/or careless use of the bicycle; with proof of purchase for the bicycle if you wish to •... - Page 7 Parts covered by warranty - You are responsible for paying the costs of transporting the bicycle and/or any out-of-war- ranty parts. - If a certain part is under warranty and the original is no longer available, Bizbike will provide an alternative of at least equal value.
-
Page 8: Safety
Safety Bike safety Transport by car - Observe all traffic rules. Do you want to transport your bicycle by car? Preferably use a bicycle carrier and follow the steps • Adjust your speed on slippery roads and con- below: sider a longer braking distance in rain or snow. - Remove any accessories that could become de- •... - Page 9 Element Check and consult Bizbike customer service if necessary Our bicycles are designed to carry a weight of up to 120 kg. If you weigh more than 120 Saddle kg and it turns out that overloading is the cause of damage, the warranty on the frame and non-electrical parts may become void.
-
Page 10: Quickly On Your Way: Checklist Before Departure
- Is the battery slotted correctly into place? If you the display. Adjust your speed to the traffic and have a Veloci Diamond, Hopper or Spirit, turn on weather conditions. the battery first. Then you can also switch on the - The battery and display will turn off automatically display. -
Page 11: Electrical Parts
The battery of your electric bike enables you to get - The battery can withstand rain but should never where you need to be. Veloci bicycles have batteries be submerged in water or cleaned with a pres- with different capacities. The reasons why its range sure washer. - Page 12 Range of your electrical bicycle Long distance/ long range Shorter distance/ shorter range Low speed and low support Higher speed and support level The journey No stops Multiple starts and stops you take Well-maintained and smooth road Sandy or gravel road Driving calmly Driving aggressively Bent over...
- Page 13 Unplugging and putting back in place Veloci Diamond, Hopper, Hybrid (Sport), Solid, Spirit To slide the battery out of the cradle, you need to open the lock. Make sure the lock clicks into place when you put the battery back in place. Do not forget to lock the battery.
- Page 14 Load - Charge your battery every two months and store - Always connect the charger to the battery first. your battery indoors at room temperature: after Only then insert the plug into the socket. Do not two months of inactivity, the battery will suffer do it the other way around, as that could serious- irreparable damage, and the warranty on the ly damage the charger.
-
Page 16: Display & Control Panel
Display 2. Display description 1. Display properties (A) Current battery capacity - Button system: ergonomic and easy to use (B) USB connection (has only charging function) - Speed modes: (C) Front and rear light indicator on or off (D) Error code/maintenance •... - Page 17 3. Description of control panel and buttons 3.1. Enable support Increase support Press and hold the power button for a few seconds Decrease support and activate pedestrian to turn the display on or off. The display will turn assistance (press and hold for 2 seconds) itself off after 5 minutes if there is no activity.
- Page 18 3.4. Turn lighting on and off 3.6. Battery indicator The front and rear lights are activated at dusk. Even When the battery is empty or almost empty, this if the battery is no longer charged enough to provide button starts flashing. This indicates that the battery support, the lighting will still work for a few hours.
- Page 19 Error Code: definitions - Press “i” twice quickly to exit the settings. - The settings will close automatically after 10 Code Description seconds. Overvoltage protection 5. Precautions Motor hall signal cable error - The display is water resistant but should not be Temperature controller submerged in water.
-
Page 20: Non-Electrical Parts
Non-electrical parts Saddle Hopper: - The saddle is at the correct height if you can sit - Adjust the height of the handlebars using the on the saddle with your leg straight and your heel quick lock (A). on the pedal in the lowest position. The correct - Adjust the rotation of the handlebars using the saddle height places less strain on your body. - Page 21 Diamond, Hybrid, and Solid & Spirit city bikes Vivid city bikes - Adjust the rotation of the handlebars by - Adjust the rotation of the handlebars by loosening these four bolts (A). loosening these four bolts (A). - Adjust the handlebar height by loosening this - Adjust the handlebar height by loosening this bolt(B).
-
Page 22: Bicycle Lock
Bicycle lock Folding your e-bike - Always lock your bike and the battery lock to - Loosen bolt (A) and put the seat in the lowest prevent theft. position. - If desired, you can purchase an extra bicycle lock. - Loosen the central bolt (B) and fold the frame in half. -
Page 23: Any Questions
Have you read the manual from A to Z not found the answer to your question? On our website repaired by one of Bizbike’s mobile technicians? (veloci.be/en*/faq) questions and comments You can request the first maintenance after 500 are discussed in detail. Is yours not among them? km or within 6 months (whichever occurs first);... - Page 24 powered by...
