Solo Up Canopy with
Solar Powered LED Lights
Assembly and Safety Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the Solo Up and is the answer not in the manual?

Questions and answers

Summary of Contents for Suntime Solo Up

  • Page 1 Solo Up Canopy with Solar Powered LED Lights Assembly and Safety Instructions...
  • Page 2 READ ALL INSTRUCTIONS BEFORE USE. WARNING-- To reduce the risk of fire, electrocution, or serious personal injury: • This product is not a toy. Children are not allowed to assemble/disassemble this item. Extra caution and close supervision are necessary when assembling/disassembling or using this product near children.

  • Page 3: Parts List

    Parts List Description Illustration Wheeled Carry Bag Gazebo Frame Gazebo Cover Mesh Screen Guy Cord Ground Stake Large Ground Stake Small Solar Panel NOTICE: Before beginning assembly, ensure all listed parts are included.
  • Page 4 Gazebo Assembly 1. Select a desired location for positioning the gazebo. 2. Remove the gazebo fabric, solar panel, guy cords and ground stakes from the carrying case for later use. 3. Place the gazebo frame on the desired location and remove the carrying case.
  • Page 5 7. Connect plugs in between solar panel and socket on the top of gazebo. Push down and tighten by twisting clockwise until solar panel is securely fastened. 8.Pull open the Gazebo as much as you can. Step underneath it and firmly push the centered frame handle upward until the clamps snap into place and rest securely over the frame brace.
  • Page 6 each remaining leg. 10.Assemble the vent cover to the Gazebo fabric by using the velcro. 9.Pull out the extendable awning bar from the top of the gazebo pole. Make sure to extend the bar fully and gently push it downwards to lock it into position. Repeat for the remaining extendable awning bars.
  • Page 7 11.To secure placement of the gazebo: Insert the stakes through the hole at the end of each leg. Weight down the gazebo by using the sand bag. 3) Unfold the four guy cords, located on the top corners of the poles.
  • Page 8 Mesh Screen Assembly Attach the netting to the gazebo with velcro. Begin by attaching the center of the netting to the corner gazebo pole. The zipper section of the netting will be centered between the poles. 2. Zip the top of the two nettings together and assemble to the gazebo.
  • Page 9 For Customer service in the US, Please call :800-306-3829 , or send email to sales @caesarhardware.com. Service Hours are 9:00am-5：00pm , Monday-Friday.
