OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY Instructions to be followed in the event user smells
gas. This information shall be obtained by consulting your local gas
supplier. As a minimum, turn off the gas and call your gas company and
your authorized service agent. Evacuate all personnel from the area.
WARNING Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read the
installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified
Brands suggests that if you are suspicious of damage to make a notation
on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
EQUIPMENT DESCRIPTION
The Groen NEB/1 steam boiler generates low pressure steam for use with HyPlus
cabinet-mounted steamers and steam jacketed kettles. The NEB-1 Boiler may
be used for a variety of applications in a variety of combinations.
The boiler is housed in a stainless steel cabinet. Various combinations of steam
operated kettles and steamers can be mounted on the top. The boiler is small
enough to fit in a 24-1/8" (613 mm) wide by 34-3/16" (868 mm) deep by 29-
3/16" (741 mm) tall (maximum) cabinet.
The boiler is constructed of 1/4" thick steel, which is certified by the American
Society of Mechanical Engineers (ASME) for pressure vessels. All welds are
hydrostatically tested.
The boiler is also equipped with all required instruments, fittings, and controls.
Heating elements with low watt density ensure longer life for the unit. The
boiler is available for three phase 60 Hertz service in the following voltage and
power combinations: * A single phase configuration is available in the 24KW
combinations.
This manual provides information for:
STEAM BOILER
MODELS NEB/1
REFERENCES
NFPA/70 The National Electrical Code
NATIONAL FIRE PROTECTION ASSOCIATION
60 Battery March Park
Quincy, Massachusetts 02269
NSF INTERNATIONAL
798 N. Dixboro Rd.
P.O. Box 130140
Ann Arbor, Michigan 48113-0140
208 Volts
24 Kilowatt
36 Kilowatt
48 Kilowatt
SEE OM-HY-6CAV FOR STEAMER CAVITY OPERATION AND/OR OM-TD FOR
KETTLE OPERATION.
The information in this document is Confidential and shall not be disclosed to any third party without the express written
consent of Unified Brands. Information contained in this document is known to be current and accurate at the time of printing/
creation. Unified Brands recommends referencing our product line websites, unifiedbrands.net, for the most updated product
information and specifications. © 2022 Unified Brands. All Rights Reserved.
PART NUMBER 148669, REV. G (01/22)
UNDERWRITERS LABORATORIES, INC.
333 Pfingsten Road
Northbrook, Illinois 60062
NOTE: A RETROFIT KIT IS AVAILABLE FROM
THE FACTORY FOR THOSE AREAS IN WHICH
COMPLIANCE WITH CSD-1 STANDARDS IS
REQUIRED.
240 Volts 480 Volts
24 Kilowatt 24 Kilowatt
36 Kilowatt 36 Kilowatt
48 Kilowatt 48 Kilowatt
