PHI 310 SERIES CONTROLLER

Operations & Maintenance Manual

1-800-641-1726

cs@phiwater.com

15 Oro Beach Drive

Oroville, WA 98844

www.phiwater.com

5/9/18

Table of Contents

Need help?

Do you have a question about the 310 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for PHI 310 Series

Page 1 PHI 310 SERIES CONTROLLER Operations & Maintenance Manual 1-800-641-1726 cs@phiwater.com 15 Oro Beach Drive Oroville, WA 98844 www.phiwater.com 5/9/18...
Page 2: Table Of Contents
INTRODUCTION Scope of Manual .................. 3 Safety Information ................4 GENERAL DESCRIPTION System Operation ................. 5 How the PHI System Mixes ..............6 Mixing Zones/Area of Influence ............7 INSTALLATION Bubble Forming Plate Mounting ............8-9 Piping ....................10 SYSTEM SET-UP & ADJUSTMENTS Electronics ..................
Page 3: Scope Of Manual
PHI 310 SERIES CONTROLLER SCOPE OF MANUAL This manual contains information concerning the installation, operation, and maintenance of the PHI 310 mixer. To ensure proper performance of the mixer, the instructions given in this manual should be thoroughly understood and followed.
Page 4: Safety Information
SAFETY INFORMATION WARNING DO NOT REMOVE VALVE OR DO ANY MAINTENANCE IN THE PHI VALVE ENCLOSURE OR ON ANY PART OF THE PHI MIXING SYSTEM UNTIL ELECTRICAL POWER IS TURNED OFF AND LOCKED OUT FOR BOTH THE COMPRESSOR AND THE VALVE PANEL.
Page 5: System Operation
SYSTEM OPERATION Simplicity in design, effective mixing, and the low power requirement makes the PHI 310 an ideal solution for any mixing application found in a wastewater and water treatment plant. The key to its effective mixing is achieved by proper sequencing of very large air bubbles.
Page 6 PHI 310 SERIES CONTROLLER HOW THE PHI SYSTEM WORKS The air pulse is approximately ½ second in duration and is injected through the forming plate. The forming plate distributes the air equally around its circumference creating a large flat bubble mass that rises at a rate of approximately four feet per second.
Page 7: Mixing Zones/Area Of Influence
PHI 310 SERIES CONTROLLER MIXING ZONES When mixing requires solids to be suspended, as found in wastewater treatment plants the effective mixing area is 1:1.2 ratio. This means for each foot of water depth the effective mixing zone is a 1.2’ radius from the center of the forming plate.
Page 8: Bubble Forming Plate Mounting
For a steel tank there are two ways to install the bubble forming plate: The first option is to purchase a PHI magnetic mounting kit. These powerful stainless steel magnets will hold the plate to the bottom of a...
Page 9 PHI 310 SERIES CONTROLLER BUBBLE FORMING PLATING MOUNTING — cont’d all-thread to the tank floor, being careful to match the hole pattern of the plate (See Addendum 4). If the surface is not flat, then use leveling nuts to square the plate and then bolt the plate in place (make sure to use all...
Page 10: Piping
For corrosive environments use only the material that will sustain in the environment. PVC piping is not recommended for compressed air; however, it can be used on the output side of the PHI controller as the bubble forming plate end is not sealed, so the air in the pipe is not compressed.
Page 11: Electronics
PANEL. AIR PRESSURE TO CONTROLLER AND ALL PIPING SHOULD BE AT 0 (ZERO) PSI TO PROCEED. The PHI controller is housed in a NEMA-4X enclosure. If the controller is mounted outside, it must have the optional heater. If it is not heated, the valves will freeze due to the moisture in the compressed air.
Page 12: Controller Overview
PHI 310 SERIES CONTROLLER CONTROLLER OVERVIEW The system has three parameters that control mixing efficiency: 1) Air Pressure 2) Pulse Duration 3) Pulse Frequency The system is shipped preset with the air regulator at 50 psi, pulse duration at 0.5 seconds, and pulse frequency of four pulses per minute.
Page 13 PHI 310 SERIES CONTROLLER CONTROLLER OVERVIEW — cont’d...
Page 14: Mixing Mode Functional Description
PHI 310 SERIES CONTROLLER MIXING MODE FUNCTIONAL DESCRIPTION The PHI 310 controller is a Unitronics Model V 120 PLC. It provides a simple method for operating personnel to change parameters of the mixing system without the need to learn computer codes or follow complicated programming maps.
Page 15 Main screen. Escaping from any function screen always returns to the Main screen The main screen provides a quick overview of the PHI 310’s operational status.  In the upper right corner, is a space where either “VLV 1” or “VLV 2”...
Page 16 PHI 310 SERIES CONTROLLER PROGRAMING — TIME/MODE SCREEN Once you have navigated to this screen from the Main screen by depressing the numbre “1” key, you can set the current time on the PLC, set the “intermittent time” or select between operating the mixing...
Page 17 PHI 310 SERIES CONTROLLER PROGRAMING — TIME/MODE SCREEN — cont’d In the continuous mode, the mixing system will operate as configured 24 hours per day / 7 days per week. In the intermittent mode, the mixing system will only start mixing at the time set and for the amount of time set for each start time.
Page 18 PHI 310 SERIES CONTROLLER PROGRAMING — TIME/MODE SCREEN — cont’d When entering the start time, you need to enter values for a 24-hour clock. For example, a start time for 3 am would be entered as 0300 and a start time for 3 pm would be 1500. It is possible program 24 start times during the course of one day.
Page 19 PHI 310 SERIES CONTROLLER PROGRAMING — VALVE SELECT SCREEN The PHI 310 can have one or two pulsing valves. In order to determine if one or both pulsing valves are to operate, you navigate to this screen by depressing the number “2” when in the Main Screen. Once the Valve Select Screen is displayed, you need to place a number (1, 2 or 0) in the boxes SEQ1 and SEQ2.
Page 20 Pulse durations from 0.2 seconds to 0.8 seconds can be selected. There is one other control line in this screen and this is named SWITCH (1-0). This is only applicable to existing models of PHI 300 mixers that have hand switches on the outer door of the mixing valve enclosure.
Page 21 PHI 310 SERIES CONTROLLER SYNTESI REGULATOR & FILTER SERVICE Syntesi pressure regulator is based on the rolling diaphragm principle, which offers numerous advantages compared to systems using a flat diaphragm.  Increased stroke, allowing wider valve aperture and hence greater flow rate.
Page 22 PHI 310 SERIES CONTROLLER — SYNTESI REGULATOR & FILTER SERVICE cont’d The job of the filter is to retain liquid or solid impurities present in the compressed air. The incoming air is moved by the centrifuge unit, so that liquid particles, which are heavier, are projected against the walls of the container and force to adhere to it.
Page 23: Regulator & Filter
PHI 310 SERIES CONTROLLER — cont’d REGULATOR & FILTER SERVICE Pressure Regulator: Pressure adjustment—turning of the handle of the regulator clockwise will increase the secondary pressure; turning counterclockwise will decrease the pressure. Before turning the handle, pull the handle up to unlock the turning mechanism, then turn it;...
Page 24 PHI 310 SERIES CONTROLLER ROSS POPPET VALVE(S) SERVICE SERIES 360 CONTROLLER...
Page 25 — cont’d ROSS POPPET VALVE(S) SERVICE WARNING DO NOT REMOVE VALVE OR DO ANY MAINTENANCE IN THE PHI VALVE ENCLOSURE OR ON ANY PART OF THE PHI MIXING SYSTEM UNTIL ELECTRICAL POWER IS TURNED OFF AND LOCKED OUT FOR BOTH THE COMPRESSOR AND THE VALVE PANEL.
Page 26 PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE Make sure air pressure gauge reads “0” psi. Relieve any remaining pressure by depressing the brass manual activation button. Remove solenoid power plug.
Page 27 PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE Pull plug off solenoid. Depress red lock ring and pull air tube off fitting. Air tube is off fitting.
Page 28: Ross Poppet Valve(S)
PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE Remove four hex screws on valve head. Remove valve head from manifold. Remove valve from head.
Page 29 PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE Remove spring. Use cloth to clean valve and replace worn “O” rings. Use cloth to clean manifold.
Page 30 PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE Reinstall spring. Reinstall valve into valve head.
Page 31 PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE Reinstall valve head into manifold. Replace and tighten screws.
Page 32 PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE Reinstall solenoid power plug. Reinstall air tube. Turn system on; adjust air to 50 psi; check for any air leaks; correct as required. Manually activate valve three or four times before...
Page 33 PHI 310 SERIES CONTROLLER — cont’d ROSS POPPET VALVE(S) SERVICE...
Page 34: Troubleshooting Guide
Note: There should be no filter or dryer between the receiver tank and the PHi enclosure. The only filter that can be in the feed air line is the filter in the PHi enclosure. All air lines to the PHi system from the receiver must be at least 1-inch ID.
Page 35  If the power supply is operational and PLC is not functioning, contact PHi Service. PLC could have failed. Note: If the system is known to be used in areas of extremely low temperatures, insulation is normally factory installed.
Page 36: Maintenance Log
PHI 310 SERIES CONTROLLER MAINTENANCE LOG...
Page 37 Pulsed Hydraulics, Inc. Model # PHI300 Maintenance Log Check air filter every 90 days Replace filter if dirty or after 12 months of use. Date Checked/Replaced Signature...
Page 38: Warranty
PHI 310 SERIES CONTROLLER WARRANTY...
Page 39 PHI's warranty shall be for a period of eighteen (18) months after the date of shipment to the original purchaser or one (1) year after start-up by the original purchaser, whichever date occurs first, during which time nonconforming products shall be repaired or replaced at PHI's option.
Page 40: Drawings
PHI 310 SERIES CONTROLLER DRAWINGS...
Page 41 REMOTE CONTROL OF PULSING VALVES IN THE PHI 310 CONTROLLER The PHI 310 can have up to two pulsing valves installed. The pulse rate, pressure, and turn on time of the valves are set inside the enclosure by the PLC and regulator.
Page 45: Major Parts
PHI 310 SERIES CONTROLLER MAJOR PARTS...
Page 47 Switching Power Supply Type SPD 60W DIN rail mounting • Universal AC input full range • Installation on DIN rail 7.5 or 15mm • Short circuit protection • Overload protection • Class 2 output • High efficiency • LED indicator for DC power ON •...
Page 48 TOUCH-S FE HE TER 50 TO 150 W Low Surface Temperature Quick Mounting Due to DIN Rail Mountable Double Insulated (Plastic) Wide Voltage Range Small Size Touch-safe heater for the use in enclosures with electrical/electronic components. The design of the heater supports the natural convection which results in a high air- current of warm air.
Page 49 Heater CS 060 Heater CS 060 Thermostat FTO 011 Dimensions: mm (in) Heater CS 060 90 (3.5) Thermostat FTO 011 Example of connection Leistungs-Umgebungstemperatur-Diagramm CS 160 Heating Capacity/Ambient Temperature 150W Art. Nr. 16000.0-0 Art. Nr. 16010.0-0 100W Art. Nr. 16020.0-0 Temperature (°C) Umgebungstemperatur (°C) To Order...
Page 50 52 TECHNICAL DATASHEET REGULATING PRODUCT CATALOGUE - STEGO SMALL COMPACT THERMOSTAT KTO 011 / KTS 011 > Large setting range > High switching performance > Small size > Simple to mount KTO 011: Thermostat (normally closed); contact breaker for regulating heaters. The contact opens when temperature is rising.
Page 53 Roxtec EzEntry UL/NEMA 12,13 and IP 55 EzEntry 4 mini - Kit Diameter range and number of Weight Art No. cables/pipes (kg) (lb) 0+3.5-10.5mm 0+3.5-16.5mm 0+0.138-0.413” 0+0.138-0.650” (GM 13.3w40) (GM 20w40) EzEntry 4 mini/4 4 cables/pipes 0.100 0.220 EZ00000000440 EzEntry 4 mini/9 9 cables/pipes 0.100 0.220...
