Sono Ekoflex Series Installation Manual

Item No.: 205897
Installation guide
Specification
Width Range 870-1470mm
Desktop dimension
1100-1700mm
Component list
Qty
No. Part
A 1
Cable Management Tray 1
Qty
No. Part
B 1
Cable Management Tray 2
Qty
No. Part
C
2
Hook
Tools list
Please note the drawings below are only for reference which might be
slightly different from the actual object and please be subject to actual
object. Any tools missing or installation problem, please contact customer
ervice first.
No. Image Spec
1
ST4.2
Allen key
2
5x5
3
M8
C
A
B
STEP 1
Install hook
3
x2
2
5x5
1
x4
1
Qty
4
1
2
Alternative 1 Installation Guide
1
x4
1
C
1
x4
The distance between the hook and the
edge of the desktop is 200 mm.
Supporting
beam
3
C
Supporting
beam
Fix the hook (C) on the side of supporting beam with
screw (3) and use 5 x 5 allen key (2) to tighten. Then
use hand drill to fix it on the tabletop.
Supporting
The distance between the hook and the
beam
edge of the desktop is 200 mm.
Tabletop
1 C
If there is no hole in the supporting beam, install the
hook (C) on the tabletop and use hand drill to tighten.
Alternative 2 Installation Guide
Tabletop
If there is no hole in the supporting beam, install the
hook (C) on the tabletop and use hand drill to tighten.
Ekoflex series Installation Guide
Tabletop
3
2
C
Tabletop
C
1
C
Supporting
beam
C
1
