Version 1.0 / 202201
DPM-IP71R
7 inch Guard Station
COLOR TFT TOUCH SCREEN WITH HANDSET
OPERATION MANUAL
• Please read this manual carefully before using the product you purchase,and keep it well for future
use.
• Please note that images and sketch maps in this manual may be different from the actual product.
Advertisement
Table of Contents
Summary of Contents for XtendLan DPM-IP71R
- Page 1 Version 1.0 / 202201 DPM-IP71R 7 inch Guard Station COLOR TFT TOUCH SCREEN WITH HANDSET OPERATION MANUAL • Please read this manual carefully before using the product you purchase,and keep it well for future use. • Please note that images and sketch maps in this manual may be different from the actual product.
- Page 2 PRECAUTIONS • Slots or openings in the back of the monitor, are provided for ventilation and to ensure reliable operation of the video monitor or equipment and to protect if from overheating. These openings must not be blocked or covered. The monitor should never be placed near or over a radiator or heat register and should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided.
-
Page 3: Table Of Contents
CONTENTS PARTS AND FUNCTIONS ..................4 Part Names......................4 Mounting ......................... 5 Screen ........................6 BASIC OPERATIONS .................... 7 Answering a call ..................... 7 Basic operation based on Namelist ................ 8 Namelist configured ................... 8 Select a user or a Guard Station to be called ............ 8 Select a video door station to be monitored ............ -
Page 4: Parts And Functions
PARTS AND FUNCTIONS Part Names LCD Screen Handset Power/No Disturb Indicator Microphone Unlock Button Handset Line Speaker Talk/Mon Button Connection port Lan connector Key functions Item Description • See the menu details LCD screen • Display videos and images Handset •... -
Page 5: Mounting
PARTS AND FUNCTIONS Mounting The installation height is suggested to 145~160cm. 1. Use screws to fasten the mounting bracket to the wall with mounting box. 2. Connect the 2 wire cables to the unit. 3. Mount the unit to the mounting bracket, make sure the unit is absolutely attached to the mounting bracket. -
Page 6: Screen
PARTS AND FUNCTIONS Screen Main screen The Main menu is your starting point for using all the applications on your monitor. Touch anywhere of the screen on monitor in standby mode, the Main menu will appear as fol- low: Monitor Touch it to enter video resource page. -
Page 7: Basic Operations
BASIC OPERATIONS Communication screen Shows status of talking, unlocking ect. Displays which door station is calling. Red while recording. Displays talking time. 00:10 Door Station1 Answering a call • When receiving a call, the call tone sounds, video will be displayed on the 00:10 Door Station1 screen if the source is a Video Door... -
Page 8: Basic Operation Based On Namelist
2.Select a Name by touching it,calling is activated immediately.No image will be dis- played on screen. 3.Select BD_Nbr/GL_Nbr. Call_Nbr IP address Input... BD_Nbr 0000 Call_Nbr IM 00990001 GL_Nbr IM 00990002 Parameter Name DPM-IP71R IM 00990003 Global_Nbr Upgrade IM 00990005 Local_Nbr Onsite tools... -
Page 9: Select A Video Door Station To Be Monitored
BASIC OPERATIONS 3.If nobody answers the call within 30 sec- 3.The image of outdoor condition will be onds,it will stop calling automatically and displayed on screen,see as follow: shut off the screen.Or touch icon to stop calling directly. 00:10 [9002]CDS2 4.During monitoring, these operations are available: 4.If the call is answered,communication... -
Page 10: Basic Operation By Input Code
BASIC OPERATIONS Basic operation by Input code The another way to activate the functions of calling, monitoring, unlocking is by inputting code via the keypad on screen. 1.Call a User or a Guard Station On Functions menu, select [Namelis], Search by name: touch [Input] to display Search screen. -
Page 11: Release A Door Lock
BASIC OPERATIONS 3.Release a door lock 1.On Functions menu, select [Monitor], touch [Input] icon to display Search screen. 2.The inputting method is the same as the section of Calling User or Guard Station. [Unlock] button to open the corresponding 3.Select the Door Station you want, then press door. -
Page 12: Divert Calls
BASIC OPERATIONS Divert Calls The calling from door station can be diverted to your smart phone. please note that this func- tion should be supported by SIP network. 1. From the Functions menu, select "Call scene" item. 2. Select the desired tap. - Divert call if no answer: If nobody answers the call in 30s when receives call from door station, diverts the call to the smart phone.At this mode,the monitor will always open the screen and show image from door station during... -
Page 13: Viewing Videos
BASIC OPERATIONS Controlling Records The following controls are available by tapping the screen while playing a record. • Plays the record. • Plays the next record. • Plays the previous record. • Delete record. • Delete confirm. View Videos Videos are possible to be recorded, and both automatic recording and manual recording are available. -
Page 14: Playback
BASIC OPERATIONS The recorded videos are stored in SD card directly. * Max. 32G Micro SD card is supported. Note: * Automatic recording function cannot be cancelled. * Automatic recording does not available while monitoring a door station. To save videos while monitoring, see manual recording below. -
Page 15: Setup Instructions
SETUP INSTRUCTIONS Setting date and time You can correct the current date at and time any time by following the procedure below. [Setting] icon ->[General] ->[Date&Time], to enter Clock 1.On main menu page, touch setting page(or Click on the lower right corner of the screen ). 2.Touch the setting target of Date mode, Time mode, Date, Time to adjust. -
Page 16: Setting Ring Tone&Ring Volume
SETUP INSTRUCTIONS Setting ring tone&ring volume The ring call tone can be set individually to distinguish different calling source. Total 22 tones can be selected. 1.On main menu page, touch [Setting] icon ->[Ring volume]/[DS ring]/[CDS ring]/[OS ring]/[Message ring]/[Doorbell ring]/[Intercom ring]/[Innercall ring]/[Alarm ring]. Call tune Call tune Select message ring... -
Page 17: Delete Ip Camera
SETUP INSTRUCTIONS Delete IP Camera [Setting] icon ->[Ext.Unit]->[IPC camera]->[Delete]. On main menu page, touch Call tune Ext.Unit Items 01/02 Ring volume [01] Call tune IPC camera Call tune [192.168.1.172] IP-CAM1 Items Ring timing [35s] General General [192.168.1.227] IP-CAM2 DS ring [01] Installer Installer... - Page 18 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
