- Page 1 PROXIMITY ACCESS CONTROL AUTONOMOUS PROXIMITY READER DESFIRE INSTALLATION MANUAL...
- Page 2 Technical information booklet published by FERMAX ELECTRONICA. As part of its policy for constant improvement, FERMAX ELECTRONICA reserves the right to modify the content of this document and the characteristics of the products referred to therein at any time and without prior notice.
- Page 3 INSTALLATION MANUAL TABLE OF CONTENTS Introduction ..............4 Wiring Diagrams .............. 6 Connection Grid............... 7 Technical Features /Default Values ......... 7 Autonomous System Operating Modes ......8 - Activating the Card Reader ........8 • MASTER Card Reset ........8 -Activating Personal Cards .........
- Page 4 (there are no two cards with the same code). FERMAX Desfire readers include an encryption system to guarantee the security of the installation (please consult with the Technical Service). Reader encryption is done by the distributor and the following equipment...
- Page 5 1. No Power. 2. Reader Deactivated. The MASTER card has not been activated as yet. 3. Changing MASTER Card Mode 4. Card Activation Mode: 5. Card Deactivation Mode: 6. Lock-Release Activation Time Configuration Mod. 7. Door Open Time Configuration Mode 8.
-
Page 6: Auxiliary Output
CONNECTION DIAGRAM FOR AUTONOMOUS READER (Class I) DATA/CLOCK STAND ALONE MODULO DESFIRE WIEGAND-26 DESFIRE MODULE MDS-AC PLUS FERMAX ELECTRONICA, SAU AV TRES CRUCES, 133 46017 VALENCIA - SPAIN MADE IN SPAIN REF: Auxiliary Output (Alarm C NC 7463 Sa Sb... - Page 7 CONNECTION GRID o + , - / ~, ~: Power Supply o CN2: Connector for PC (12 Vdc / 12 Vac). connection or clone drive. o C, NO, NC: Lock-release relay o B, - : Lock-Release Button. o S, - : Open Door Detector. output (potential free).
- Page 8 AUTONOMOUS SYSTEM OPERATING MODES Activating the card reader To activate the reader the MASTER card must be programmed. This is the card which is subsequently used to access the programming functions. The system will take the first card swiped after powering up the system to be the MASTER card.
- Page 9 1. Disconnect the power supply. 2. Press and hold the Exit Button (if installed) or make a shortcut between <<B>> and <<->> terminals on the reader controller. Then power on. 3. The reader goes into «Changing MASTER Card Mode». All the reader’s indicators start to flash for 5 seconds.
- Page 10 Activating personal cards Up to 400 cards can be activated, following the steps below. Beep! Beep! PROXIMITY ACCESS CONTROL PROXIMITY ACCESS CONTROL Beep! Beep! Beep! Beep! Beep! PROXIMITY ACCESS CONTROL PROXIMITY ACCESS CONTROL 1. Swipe the MASTER card . The indicators show the user is in «Card Activation Mode».
- Page 11 Deactivating personal cards To deactivate a card on the system you must have the physical card in your possession. The procedure is the following: Beep! Beep! Beep! PROXIMITY ACCESS CONTROL PROXIMITY ACCESS CONTROL Beep! Beep! Beep! Beep! PROXIMITY ACCESS CONTROL PROXIMITY ACCESS CONTROL You can deactivate cards without having them on your person using the PROGRAMMING KEYPAD Ref.2306.
- Page 12 Beep! Beep! Beep! Beep! Beep! PROXIMITY ACCESS CONTROL PROXIMITY ACCESS CONTROL Beep! Beep! PROXIMITY ACCESS CONTROL 2. Swipe any card (except the MASTER card) once for every second you want the lock-release to be activated for. Once: 1 second Twice 2 seconds. 3.
- Page 13 Beep! Beep! Beep! Beep! Beep! Beep! PROXIMITY ACCESS CONTROL PROXIMITY ACCESS CONTROL PROXIM Beep! PROXIMITY ACCESS CONTROL 1. Swipe the MASTER card (four times). The indicators show we are in «Open Door Timing Configuration Mode». 2. Swipe any card (except the MASTER card) once for every second you want the open door detection to be set up for.
- Page 14 1. Connect the reader as indicated in the diagram. It can also be connected via the CN2 connector, with the appropriate cable. DATA/CLOCK DATA/CLOCK STAND ALONE STAND ALONE MODULO DESFIRE MODULO DESFIRE WIEGAND-26 WIEGAND-26 DESFIRE MODULE DESFIRE MODULE MDS-AC PLUS...
- Page 15 PC Management Programming (activation, deactivation) of cards can also be done from a PC with the help of the WINPROX programme developed by FERMAX. You can only manage a reader via a serial port. See the corresponding installation manual.
