What's in the Box
Lewitt MTP 940 CM Condenser Performance Handheld Microphone
MTP 40 MCs Shock Mount
DTP 40 LB Pouch
Limited 2-Year Warranty
Specs
Lewitt MTP 940 CM Specs
Operating Principle
Directional Pattern
Frequency Range
Sensitivity
Signal to Noise Ratio
Equivalent Noise Level
Dynamic Range
Maximum SPL for 0.5% THD
Pad
Lewitt MTP 940 CM Condenser Performance Handheld
Microphone
For Live Sound and Recording
20 Hz to 20 kHz Frequency Response
3 Switchable Polar Patterns
48V Phantom Power
3-Step High-Pass Filter
3-Step Pre-Attenuation Pad
LED Indicators for Microphone Status
Gold-Plated 3-Pin XLR Connector
Shock Mount is Included
Carrying Pouch is Included
Acoustical: Pressure gradient transducer, externally polarized
Cardioid, wide cardioid, supercardioid
20 Hz to 20 kHz
10 mV / Pa (-40 dBV), cardioid
85 dB-A
9 dB-A, cardioid (IEC 61672-1)
Mic Amp: 135 dB-A
144 dB, 0 dB pre-attenuation
150 dB, 6 dB pre-attenuation
156 dB, 12 dB pre-attenuation
Pre-Attenuation: 6 dB, 12 dB, switchable
Advertisement
Related Manuals for Protel Lewitt MTP 940 CM
Summary of Contents for Protel Lewitt MTP 940 CM
- Page 1 LED Indicators for Microphone Status Gold-Plated 3-Pin XLR Connector Shock Mount is Included Carrying Pouch is Included What's in the Box Lewitt MTP 940 CM Condenser Performance Handheld Microphone MTP 40 MCs Shock Mount DTP 40 LB Pouch Limited 2-Year Warranty Specs...
- Page 2 Bass Cut Filter Slope: 12 dB / octave at 80 Hz 12 dB / octave at 160 Hz Impedance Rated: < 150 Ω Rated Load Impedance: > 1000 Ω Supply Voltage 48 V +/- 4 V (IEC 61938) Current Consumption 5.5 mA (IEC 61938) Connector Gold-plated 3-pin XLR...
