Surewerx Strongarm 806B Operator's Manual

1 ton heavy-duty hydraulic low-profile transmission jack
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

OPERATOR'S MANUAL
1 Ton Heavy-Duty Hydraulic
Low-Profile Transmission Jack
! !
IMPORTANT
For your safety, read, understand, and follow the information provided with and on this jack.
The owner and operator of this equipment should understand this jack and the safe operating
procedures before attempting to use. The owner and operator should be aware that use and
repair of this product may require special skills and knowledge.
Inspect before each use. Do not use if broken, bent, cracked, or damaged parts are noted.
Any jack that appears damaged in any way or operates abnormally should be removed from
service immediately. If the jack has been or suspected to have been subjected to a shock load
(a load dropped suddenly or unexpectedly on it), immediately discontinue use until the jack
has been checked by a factory authorized service center. It is recommended that an annual
inspection be performed by qualified personnel.
PROD. NO. 030546
MOD. NO. 806B
M20-SA030546-FA
