- Page 1 NOOK ASSEMBLY INSTRUCTIONS Aust. Design Reg. no 201711369...
- Page 2 STEP 1 Attach (T1) Back panel to (T2) RHS Back panel (5x M6-16 screws) STEP 2 Attach STEP 1 to (T3) LHS Back panel (5x M6-16 screws) STEP 3 Attach (T4) RHS Front panel to (T2) RHS Back panel (5x M6-16 screws) STEP 4 Attach (T5) LHS Front panel to (T3) LHS Back panel (5x M6-16 screws)
- Page 3 STEP 5 Insert (T6) Floor Brace to (T4 and T5) LHS and RHS panels at ground level STEP 6 Attach (T7) Rear Top panel to (T2 and T3) RHS and LHS Rear panels (10x M6-16 screws) STEP 7 Attach (T8) Front Top panel to (T4 and T5) RHS and LHS Front panel (8x M6-16 screws)
- Page 4 STEP 8 Attach x4 Corner Brace Brackets (8x M5-12 screws) Fasten x4 self drilling screws to each of the (T6) Floor Brace to the corner flaps pre-aligned hole points STEP 9, 10 & 11 9. Put locker in place and mark 12 prefered hole locations 10.
