User Guide
The NebuTech 8660 consists of 4 components:
The 8660 Jet Nebulizer kit is individually packaged with a
1. Reservoir tower with one-way inspiratory valve.
2. Medication chamber (connects to the reservoir tower).
3. Mouthpiece has a built in one-way exhalation valve.
4. 3-Channel supply tubing, 7 feet.
Instructions for use
1. Wash your hands. Use an aseptic technique to
assemble the nebulizer.
2. Remove the NebuTech Nebulizer from the package.
3. Ensure that the medication chamber is connected tightly
to the reservoir tower (A).
4. Insert the mouthpiece into the side elbow on
the Reservoir Tower (B).
• Ensure that the exhalation valve is facing upward.
5. Attach the gas supply tubing to the connector port
at the bottom of the medication chamber (C).
• Ensure connections are on tight and secure.
6. Attach the gas supply tubing to the connector port
at the bottom of the medication chamber (C).
Nebutech® 8660 Reusable Nebulizer
Inspiratory
Valve
Reservoir
Tower
Gas Supply
Tubing
B
A
C
800-433-2797
Exhalation
Valve
Mouthpiece
Medication
Chamber
www.Sun-Med.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SUNMED Nebutech 8660
Summary of Contents for SUNMED Nebutech 8660
- Page 1 User Guide Nebutech® 8660 Reusable Nebulizer The NebuTech 8660 consists of 4 components: Exhalation Valve The 8660 Jet Nebulizer kit is individually packaged with a 1. Reservoir tower with one-way inspiratory valve. Inspiratory 2. Medication chamber (connects to the reservoir tower).
- Page 2 User Guide Nebutech® 8660 Reusable Nebulizer Instruction for use, continued 7. To add prescribed medication, do not unscrew medication chamber. Remove the inspiratory valve and instill medication through the top (D). • Maximum medication volume is 5 mL. • Do not instill medication through the side elbow because medication can be caught in the drool catcher.
- Page 3 User Guide Nebutech® 8660 Reusable Nebulizer To Use the Nebulizer with a Mask 1. Remove the mouthpiece and place in respiratory equipment bag, in case you need it later. 2. Remove the inspiratory valve and place on the side elbow port.
- Page 4 User Guide Nebutech® 8660 Reusable Nebulizer Suggested Cleaning Instructions WARNINGS/CAUTIONS for Home Use 1. This product is disposable and is not intended for The NebuTech Nebulizer is for single-patient use prolonged or extended use. and should be replaced every 6 months or after 2.
