- Page 1 EASYpure™ RO Reverse Osmosis System Series 742 INSTALLATION, OPERATION, SERVICE AND REPAIR MANUAL, AND PARTS LIST Model Voltage D7422-33 D7429-33 Low Pressure LT742X16 • 7/16/02...
-
Page 2: Table Of Contents
Table of Contents Safety Information ..............................3 Alert Signals..............................3 General Usage..............................3 Warnings ..............................3 General Specifications ............................5 Feedwater Requirements ..........................5 Product Water Specifications........................5 Membrane Rejection Rates ..........................5 Electrical Requirements..........................6 Environmental Conditions ..........................6 Declaration of Conformity ..........................6 Unpacking ................................7 Installation ................................8 Locating your EASYpure RO ........................8 Bench Mounting............................8 Wall Mounting ..............................9 Utility Connections ............................10... -
Page 3: Safety Information
Safety Information Your Barnstead EASYpure RO has been Alert Signals designed with function, reliability, and safety in mind. It is your responsibility to install it in conformance with local electrical codes. For Warning safe operation, please pay attention to the Warnings alert you to a possibility of per- alert signals throughout the manual. - Page 4 AFETY NFORMATION To avoid personal injury: 1. Do not use in the presence of flamma- ble or combustible materials; fire or explosion may result. This device con- tains components which may ignite such materials. 2. Ensure all piping connections are tight to avoid leakage of chemicals.
-
Page 5: General Specifications
General Specifications Dimensions 30.5 cm W x 46.7 cm W x 46 cm H. Feedwater Requirements* Max. Temperature: 48.8°C Min. Pressure (standard unit): 30 psig (2.1 bar) Min. Pressure (low pressure unit): 9 psig (0.62 bar) Max. Pressure (standard unit): 100 psig (6.8 bar) Max. -
Page 6: Electrical Requirements
Degree 2 in accordance with IEC 664. Altitude limit: 5,000 meters. Storage: -25°C - 65°C; 20% - 80% relative humidity. Declaration of Conformity Barnstead International hereby declares under its sole responsibility that this product conforms with the technical requirements of the following stan- dards: EMC: EN50081-1 Generic Emission Standard;... -
Page 7: Unpacking
Unpacking Carefully remove the unit from its shipping container. The following items are shipped separately and must be removed from the packaging prior to discarding the packaging: 1. EASYpure RO Ventgard air filter. 2. Power cord. 3. Pump interlock cord. 4. -
Page 8: Installation
Installation Locating your EASYpure RO Warning Your EASYpure RO must be located within six Do not mount the EASYpure RO feet of an electrical outlet appropriate for your directly over equipment that requires unit, within five feet of your feedwater supply electrical service. -
Page 9: Wall Mounting
NSTALLATION 2. Place the EASYpure RO on the Bench Stand so that the screw holes where the feet were attached line up with the holes in the Bench Stand. 3. Install the 4 screws removed in step 1 through the bottom of the Bench Stand and into the EASYpure RO. -
Page 10: Utility Connections
NSTALLATION 3. Place the EASYpure RO on the wall bracket swivel base so that the screw holes where the feet were attached line up with the holes in the wall bracket. There are guides on the wall bracket that will mate with the EASYpure RO. 4. -
Page 11: Reject Water Connection
NSTALLATION Reject Water Connection 1. Locate the reject water tubing. This is the piece of 3/8" O.D. tubing that has an adapter on one end and no con- nector on the other end. Remove the nut, grab ring, backup ring and o-ring from the reject water fitting located at Pump the lower right of the unit. -
Page 12: Tank Overflow Connection
NSTALLATION Tank Overflow Connection 1. Refer to Figure 3 and attach a customer supplied hose barb connector and 5⁄8" O.D. tubing to the tubing located at the lower right of the unit as you look at the rear of the unit. 2. -
Page 13: Installing The Prefilter And Membranes
NSTALLATION EASYpure unit and save it for future use. Plug the other end of the cord into the pump interlock on the other EASYpure unit. Installing The Prefilter and Membranes 1. Disconnect the unit from the power supply. 2. Pull the rear side of the door latch up and toward the front of the unit until the front of the door latch unhooks. -
Page 14: Membrane Installation
NSTALLATION the end cap slide down on each side of the keyway wall. (See Figure 7.) 4. Lower the prefilter and insert the lower end cap into the lower center socket until it is firmly seated. Membrane Installation 1. Remove the membrane bypass tubing from the EASYpure RO (see Figure 5). - Page 15 NSTALLATION 5. Wet the o-rings on the bottom of the membrane cartridge. Insert the RO Caution membrane cartridge into the right- Do not use a wrench on the tubing hand spring metal retainer. adapter connections. A sufficiently tight connection can be made by hand. 6.
-
Page 16: Electrical Connections
NSTALLATION Electrical Connections Warning 1. Plug power cord into the unit's power Use a properly grounded electrical out- entry module. let of correct voltage and current han- dling capacity. 2. Connect your EASYpure RO to a prop- erly grounded outlet of correct voltage and current handling capacity. -
Page 17: Set "Replace Prefilter" Indicator
NSTALLATION 6. Turn unit power off. Reconnect the product water tubing to the other EASYpure unit. Reconnect the product water tubing to the accessory 30 Liter Reservoir. Reconnect the pump inter- lock cord to the other EASYpure unit. Set "Replace Prefilter" Indicator The extruded carbon prefilter both filters partic- ulates and absorbs free chlorine out of your feedwater supply. - Page 18 NSTALLATION you face the switch panel. Each switch has two possible positions: 1) top pressed in or 2) bottom pressed in. (See Figure 10.) Set the switches for your free-chlorine level as fol- lows: Free-Chlorine Range (ppm) Switch 1 Switch 2 Switch 3 Switch 4 0.05-0.80 ppm...
-
Page 19: Operation
Please ensure that the unit remains on — if you need to de-energize the system for longer then 48 hours contact Barnstead International customer service. If water is not drawn from the tank for 72 hours, empty tank and refill with new RO water before using. - Page 20 PERATION full. This light will illuminate, indicating the unit is in a standby mode. When the reservoir’s water level is lowered about five inches, the unit will re-energize and the light will turn off. 2. Low pressure: If the incoming water pressure at the pump drops below 5 psig, a switch will de-energize the pump.
- Page 21 PERATION membrane difficulty. In most cases re- placement of the membranes is called for. Refer to troubleshooting guide for further information. At times during operation the light may illuminate. This may be caused by feedwater variation or extended periods of non- use.
-
Page 22: Maintenance
Maintenance Caring For Your EASYpure RO Warning With proper care, your EASYpure RO will give Disconnect from the power supply you consistently pure water. To ensure contin- prior to maintenance and servicing. ued good service, regularly perform the follow- ing procedures. Refer servicing to qualified personnel. - Page 23 AINTENANCE 4. Disconnect the quick disconnect insert(s) and product water tubing attached to the EASYpure RO. 5. Remove the pretreatment cartridge and membrane cartridges. 6. Install the membrane bypass tubing on the top membrane connectors. 7. Install the bottom bypass into the two membrane inlets.
- Page 24 AINTENANCE 11. Allow the solution to sit in the system for 30-45 minutes. 12. Reconnect the quick disconnect insert(s) and product water tubing removed in step 4. Direct the tubing to drain and drain the storage reservoir. After the reservoir is empty, disconnect the quick disconnect insert(s) and prod- uct water tubing again.
-
Page 25: Ventgard® Filter Replacement
AINTENANCE ® Ventgard Filter Replacement The materials in the Ventgard have a limited capacity. The Ventgard should be replaced every 90 days or after 1,000 gallons have been drawn from the storage tank. A Ventgard may be stored in a cool, dry place almost indefinitely, provided the plastic bag has not been opened. -
Page 26: Service And Repair
Service and Repair General Cleaning Instructions Warning Wipe exterior surfaces with lightly dampened Disconnect from the power supply cloth containing mild soap solution. prior to maintenance and servicing. Refer servicing to qualified personnel. Normal Unit Operation Ensure all piping connections are tight Below is a brief description of the normal auto- to avoid leakage of chemicals. - Page 27 ERVICE AND EPAIR onds after the flush solenoid valve closes. During operation, the storage reservoir floats will: 1) switch the EASYpure RO into standby mode (pump off) when the storage reservoir is full, 2) switch the EASYpure RO back into water production mode (pump on) when the reservoir level drops approximately five inches, and 3) switch off any EASYpure unit con-...
-
Page 28: Fuse Replacement
ERVICE AND EPAIR Fuse Replacement 1. Disconnect the EASYpure RO from its Warning Replace fuses with those of the same power source. Remove the outer cover. type and rating. 2. Locate the fuse holder, part of the power entry module (see Figure 13 for location), and remove. -
Page 29: Prefilter Replacement
ERVICE AND EPAIR Prefilter Replacement It is impossible to exactly predict prefilter life Note The RESET button is a two position in the EASYpure RO. Due to varying amounts button; up or down. Press it once to of particulates and chlorine in feedwater, life change its position. -
Page 30: Parts List
Recommended Spare Parts Consumables: Consumable parts are those required to support the day-to-day operation of this equipment. Barnstead International establishes two types of consumables; those items that must be periodically replaced to maintain performance (filters, resin cartridges, etc.) and other items of limited service life (indicator lights, fuses, etc.) that you can expect to replace on a more or less random basis. - Page 31 Barnstead International recommends that you maintain a local stock of those parts listed under “General Maintenance” and “Safety Stock.” In the event of component failure, this safety stock can be drawn upon by you or Barnstead International technicians, thereby, avoiding unnecessary delays in delivery of replacement parts.
-
Page 32: Troubleshooting
Troubleshooting Problem Possible Causes Solutions EASYpure RO No electrical power to Ensure EASYpure RO completely inactive. EASYpure RO. power cord is installed (Controls not operating.) and connected to live power. Blown fuses. Check/Replace fuses. Refer to “Fuse Replacement” for procedure. No water flowing (low Feedwater supply valve Open feedwater supply valve. -
Page 33: Ordering Procedures
All parts listed herein may be ordered from the Barnstead International dealer from whom you purchased this unit or can be obtained promptly from the factory. When service or replacement parts are needed we ask that you check first with your dealer. -
Page 34: Wiring Diagrams
Wiring Diagrams POWER ENTRY MODULE WITH LINE FILTER, DPST SWITCH AND FUSE DRAW WHITE BLUE RETURN 3.0 A FLOAT SWITCHES MIDDLE BROWN BLACK LINE BOTTOM 3.0 A GRN/YLW PRESSURE SWITCH GROUND CORDSET 100/120 VAC Easypure RO TRANSFORMER GREEN BLACK NANO COMPARATOR PROD FEEDWATER... - Page 35 IRING IAGRAMS POWER ENTRY MODULE WITH LINE FILTER DPST SWITCH AND FUSE DRAW BLUE RETURN 3.0 A FLOAT SWITCHES MIDDLE BROWN LINE BOTTOM 3.0 A GRN/YLW PRESSURE SWITCH GROUND CORDSET Easypure RO GREEN BLACK NANO COMPARATOR PROD FEEDWATER FEED SOLENOID PUMP INLET CELL ORANGE...
- Page 36 IRING IAGRAMS POWER ENTRY MODULE WITH LINE FILTER, DPST SWITCH AND FUSE DRAW BLUE RETURN 2.0 A FLOAT SWITCHES MIDDLE BROWN LINE BOTTOM 2.0 A GRN/YLW PRESSURE SWITCH GROUND CORDSET Easypure RO GREEN BLACK NANO COMPARATOR PROD FEEDWATER FEED SOLENOID PUMP INLET CELL ORANGE...
-
Page 37: Exploded View
Exploded View Part # Description PU742X1A Pump, 120 Volt PU742X2A Pump, 230/240 Volt PU742X3A Pump, 100 Volt & 120 Volt Low Pressure PU742X4A Pump 230/240 Volt Low Pressure PC742X2A Main PC Board 01407 Pressure Switch RY631X1A Solenoid Valve 100/120 Volt RY631X3A Solenoid Valve 230 Volt 02280... -
Page 40: One Year Limited Warranty
BARNSTEAD will provide warranty replacement. As a condition to the return of any product, or any constituent part thereof, to BARNSTEAD’s factory, it shall be sent prepaid and a prior writ- ten authorization from BARNSTEAD assigning a Return Goods Number to the product or part shall be obtained.
