J-Mini
User Manual v 1.0.1
Introduction
J-Mini
has been developed and designed for the efficient and productive identification of CVD and HTHP
Pro
laboratory grown diamonds, either as loose stones or in diamond-set jewelry. Laboratory grown diamonds
(LGD) are visually indistinguishable from natural diamonds and the supply pipeline is contaminated by the
undisclosed intrusion of LGD into every part of the jewelry industry.
Because all concerned interests in the jewelry industry desire to represent their products fairly and honestly, it
is necessary to have some type of device that detects laboratory grown diamondsto prevent any possible
confusion or misrepresentation. J-Mini
Consumers have a fundamental right to know about the origins of the products that they purchase. J-Mini
allows the Retailer, Wholesaler, and Manufacturer to verify the content of the merchandise that they sell.
J-Mini
is a machine that can facilitate the screening process for CVD and HTHP laboratory grown
Pro
diamonds to protect consumers from undisclosed LGD. This manual is a guide in the effective, efficient, and
safe use of this instrument. Please review it carefully before the use of the instrument.
Pro
©
Quick Start Guide
User Manual version 1.0.1
is the latest device designed to identify laboratory grown diamonds.
Pro
and
The information contained herein is the property of DRC.
Any reproduction, publication, or distribution to a third party is strictly forbidden.
Pro
CONFIDENTIAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J-Mini Pro and is the answer not in the manual?

Questions and answers

Related Manuals for DRC J-Mini Pro

Summary of Contents for DRC J-Mini Pro

  • Page 1 LGD. This manual is a guide in the effective, efficient, and safe use of this instrument. Please review it carefully before the use of the instrument. CONFIDENTIAL The information contained herein is the property of DRC. Any reproduction, publication, or distribution to a third party is strictly forbidden.

  • Page 2: Table Of Contents

    J-MINI PRO MANUAL Table of Contents Safety First ..................................3 Symbol Notations and Definitions ........................3 Caution – Laser Radiation ............................. 4 Physical Specifications, Designed Functions, Capabilities and Features ..............5 J-Mini and Included Accessories ........................... 5 Set Up (no tools are required for assembly) ......................... 7 Un-boxing ................................

  • Page 3: Safety First

    DRC to maintain or support the operation of J-Mini 1 Safety First At DRC, the safety of everyone who uses our instruments is important. We recommend reading the safety information and operating instructions before operating J-Mini .

  • Page 4: Caution - Laser Radiation

    This symbol indicates possible software damage or loss of data that may occur and result in a permanent loss of stored information. Attention is required by an authorized DRC technical specialist. This symbol indicates potential exposure to rays of invisible laser radiation.

  • Page 5: Physical Specifications, Designed Functions, Capabilities And Features

    Temperature Range: 5 – 35 degrees C The J-Mini manufactured by DRC has been designed and developed for the identification of CVD and HPHT laboratory grown diamonds. It has been created with the following functions. • Detection of both CVD and HTHP laboratory grown diamonds Diamonds of any shape, including rough or unfinished stones Diamonds from 0.003 carat in weight and larger, approximately .80 - .85 mm.,...
  • Page 6 J-MINI PRO MANUAL Integrated Mobile Phone/Computer Power Button Scanning Tray Slide-In Drawer Power Outlet USB Cable and Plug Jewelry or Ring Tray Loose Diamond Tray Silver Sample Pendant with three diamonds, each 0.003 carat Page 6 of 33...

  • Page 7: Set Up (No Tools Are Required For Assembly)

    Check them against the above itemization of components and trays Make note of any items that are missing or damaged Contact the DRC Support Team as noted on the laminated worksheet to arrange for replacements to be sent and possibly a claim request from the carrier. Report any shortage or damage to Support@DRCIndia.in.

  • Page 8: Mobile Device

    DO NOT remove it and try to use it for this purpose. b. The Nokia mobile device is shipped with a prietary DRC software application pre-installed. c. Do not remove the phone from its housing unless instructed to do so by the Support Team at DRC.

  • Page 9: System Setup

    • When the phone is on for the first time, choose your language and time. Select Settings/Menu >> Time & language > Date and time The DRC default language is English. • Follow the instructions shown on your phone. •...
  • Page 10 Select either the Loose Diamond Tray or the Jewelry tray, seat it on the Slide-In Tray, and push the tray into the machine. • The device will turn on and the home screen will display an icon labelled DRC. Tap this button and wait for the scanning program to load and display the DRC J-Mini home screen...

  • Page 11: Mini Pro Program Desktop

    Tap the J-Mini icon and The opening desktop for the DRC software program is arranged for easy operation. the introductory splash screen at the right will appear on the screen before the operating desktop for the J-Mini program will appear.

  • Page 12: Pro Desktop

    J-MINI PRO MANUAL 5.1 Navigating the J-Mini Pro Desktop The screen will appear like the graphic below. In this view, the loose diamond tray has been set onto the Scanning Platform.    1. Scan Mode: loose or mounted diamonds (the...

  • Page 13: Preparing For Merchandise Scanning

    J-MINI PRO MANUAL Preparing for Merchandise Scanning 5.2 Step 1 The J-Mini machine must be set to the right merchandise category so that the camera can accurately capture and diagnose the image of each item that it scans. Every scan is automatically archived. If you want to customize details of the merchandise that you scan, follow these directions.

  • Page 14: Preparing To Scan

    J-MINI PRO MANUAL Preparing to Scan 5.3.1 Before You Scan: when scanning either loose or mounted diamonds, the J-Mini depends upon light reflected from the stones. 5.3.2 Select the appropriate tray (supplied) that you want to use for your scan.

  • Page 15: Scanning

    J-MINI PRO MANUAL 5.4 Scanning From the top menu bar, select the correct scanning mode on the screen. One mode is for loose diamonds and one mode is for diamonds set into mounted jewelry. • The home scanning screen is set for loose diamonds as it is indicated with the diamond icon in the Mode position.

  • Page 16: Scanning Results Analysis

    Whether they are loose diamonds or mounted into jewelry, the results of J-Mini scanning are displayed in a similar manner. The intelligent, automated software that has been developed by DRC draws a colored box around detected laboratory grown diamonds. While this system is highly accurate, it is now possible to achieve a heightened level of accuracy by means of additional examination of light performance features for the operator to examine.

  • Page 17: Observing And Interpreting Scanned Results

    7 Observing and Interpreting Scanned Results 7.1 Understanding Scan Results 7.1.1 After Jewelry or Loose Stones are scanned, J-Mini Pro software automatically identifies laboratory grown diamonds or stones that may be LGD but require further investigation with alternate viewing screens.

  • Page 18: Basic Scanning Diamond Identification

    J-MINI PRO MANUAL 7.2 Basic Scanning Diamond Identification This mark indicates a confirmed CVD or HTHP laboratory grown diamond. No further examination is required. This mark identifies a diamond that requires review under an internal or external fluorescent lamp. If this stone glows from faint to intense fluorescent color as the examples that are shown below, it can be considered natural.

  • Page 19: Advanced Scanning Interpretation

    J-MINI PRO MANUAL 7.3 Advanced Scanning Interpretation 7.3.1 Those diamonds whose scan displays a ‘Recheck’ box can often be identified through advanced scanning interpretation. Only utilize these techniques if a diamond is indicated with the ‘Rescan or Re-check’ box surrounding it.
  • Page 20 J-MINI PRO MANUAL Automatic Scanned View Photoluminescent View Phosphorescent View Fluorescent View Page 20 of 33...

  • Page 21: Stage Two Advanced Analysis

    7.5.2 Examples of blue fluorescence in natural diamonds 8 Additional Features and Viewing Options If the user is experiencing problems with scanning, they are welcome to contact DRC Support for assistance. See section 10. Contact Support Icon Download Scanned Data in *.PDF Format...

  • Page 22: Split-Screen Analysis

    J-MINI PRO MANUAL 8.1 Split-Screen Analysis Original Result & As- Scanned Views As Scanned & Photoluminescent Views As Scanned& Phosphorescent Views As Scanned & Fluorescent Views Page 22 of 33...

  • Page 23: Additional Features

    J-MINI PRO MANUAL 8.2 Additional Features Screen Rotation Manual Focus Focus Bar J-Mini software will The viewing screen can be rotated automatically focus for viewing by a customer or other merchandise;however, the user can person opposite you by tapping this further refine the focus for better icon.

  • Page 24: Archived Scans And Reports

    J-MINI PRO MANUAL 8.3 Archived Scans and Reports Archived Scans Archived Scans The lot number and the date of the The archive of scans can be viewed scan are shown in the default view. by tapping on the ‘fille’ icon...
  • Page 25 J-MINI PRO MANUAL Reports: Search & Download Search Download Print Search for specific archived data by lot number or date by clicking the search icon. Download the specific lot# by clicking the Download icon (In PDF format). Conveniently print the downloaded PDF format report.

  • Page 26: Maintenance And Support

    Shown below is contact information and procedures for speaking with someone on our Support Team. We will assist you, at no charge, in learning how to operate your J-Mini Pro and in answering your questions about laboratory grown diamond identification.
  • Page 27 Service Contact Information DRC is a manufacturer of highly technical instruments. They come with a one year, all inclusive Warranty. After one-year optional service and warranty programs are available on a subscription basis. To initiate your warranty, register it at www.drcindia.in/register.
  • Page 28 Swipe from the bottom and tap on the Team Viewer icon Tap the OPEN QUICKSUPPORT bar Send the 10-digit number to DRC Support Be prepared to provide a full description of the problem or issue to the service engineer. Stay available if they require your hands-on intervention.

  • Page 29: Warranty

    J-mini Pro as a result of any one or more of the following: (I) normal wear and tear, (ii) accident, disaster, or event of force majeure, (iii) misuse, fault, or negligence of or by any user or other person, (iv) use of the J-mini Pro in a manner for which it was not...
  • Page 30 • Delivery is strictly based on First come First Serve bases and sole discretions of DRC . 10.3.2.5 RISK Risk in the Goods shall pass to the Buyer upon receipt of the goods. Where the Buyer chooses to collect the Goods itself, risk will pass when the Goods are entrusted to it or set aside for its collection, whichever happens first.
  • Page 31 J-MINI PRO MANUAL • Any returns must be authorized by a representative of the Seller before any credit will be given. • Credit of amount due or paid-in will only be given for goods that are in saleable condition. 10.3.2.8 LIMITATION OF LIABILITY& WARRANTY Warranty is void if the device is tampered / physically damaged / dispersed or dissipated by other than the authorized technician;...
  • Page 32 • DRC will not take the responsibility of the accidental data loss, due to a third party product that has stopped or malfunctioned. (i.e. Corrupted MS Windows and HDD and accidental data loss.) We always recommend you backup your data for safety and security.
  • Page 33 About DRC DRC is a privately held, not-for-profit company based in Surat, India. The company’s principal focus is on technological advancements for use in the diamond industry. In addition to a variety of instruments designed for the detection of laboratory-grown diamonds, DRC has created a variety of instruments to photograph gemstones or jewelry, uniquely identify diamonds, and assist in the evaluation of their qualities for the trade.
