Summary of Contents for Trumpf Marker Mini
- Page 1 Operator's manual Marker Mini Edition 2022-02-01 TRUMPF GmbH + Co. KG, Technische Redaktion Johann-Maus-Straße 2, D-71254 Ditzingen Fon: +49 7156 303 - 0 Internet: http://www.trumpf.com E-Mail: docu.th@de.trumpf.com...
- Page 2 TRUMPF (whether or not TRUMPF or its licensors knew or should have known of the pos- sibility of any such Injuries) even if a remedy set forth herein is found to have failed of its essential purpose.
- Page 3 Good to know 2022-02-01 B1250en...
-
Page 4: Table Of Contents
Table of contents Introduction Safety and compliance information FCC - safety and compliance EU Declaration of Conformity Battery Technical Data Hardware overview Support B1250en 2022-02-01 Table of contents... -
Page 5: Introduction
Introduction omlox Marker Mini is a TRUMPF product which can be used in the core zone of any omlox compatible real-time locating system (RTLS) which uses Ultra-Wideband (UWB) pulses for real-time 3D location of objects in buildings in various industries. - Page 6 Overview omlox core zone RTLS Overview omlox core zone RTLS Fig. 116079 This document includes regulatory information, as well as a detailed hardware specification and a description of its features. Note For detailed features and user instructions regarding the com- plete system, please refer to the documentation of each product you are using in the omlox core zone.
-
Page 7: Safety And Compliance Information
Changes or modifications CAUTION Any changes or modifications not expressly approved by Ø TRUMPF could void the user's authority to operate this equipment. The Satellites only operate (i.e. receive and transmit UWB sig- nals) within a complete UWB real-time location system TRUMPF RTLS, which must be professionally installed. -
Page 8: Eu Declaration Of Conformity
Improper use of the battery may cause heat, fire, rupture, dam- age or capacity deterioration of the battery. In order to ensure a safe and efficient use of omlox Marker Mini´s battery, read the following information and apply the following instructions care- fully. - Page 9 Capacity recovery rate should be more than 80% of initial Capacity. ■ Please note, that the temperatures mentioned above only apply to the battery. For omlox Marker Mini there are other temperature ranges divergent from the ones stated above (see "Technical Data", pg. ■...
-
Page 10: Technical Data
Technical Data Data connections Bluetooth, UWB Housing material ABS/PC, PC Weight 160 g h: 24 mm, ∅ : 84.2 mm Dimensions Operating temperature 0°C +40°C range Do not operate outside this ambient temperature. Charging temperature 0°C +35°C range Do not charge outside this ambient temperature. Max. - Page 11 Equipment needs ■ Charging station ■ To use marker mini in a working system there is the need for an operating omlox core zone including all the parts men- tioned in .(see "Introduction", pg. 2) Technical Data 2022-02-01...
-
Page 12: Support
We offer standardized as well as customized solutions. Please note that all documents may be updated without notice to individ- ual customers beforehand. We provide remote assistance by e-mail at info@trumpf.com. In case of support request, please indicate your system referen- ces. - Page 13 Support 2022-02-01 B1250en...
