Quick Guide Filon FUTURE charger

Purpose of the operating instructions

The operating instructions are intended to explain the functions, safety regulations and displays

of the charger.

Further information can be found at www.ieb.de.

To ensure the safe handling of the charger, the operating instructions must in any case be read

by each person using the charger.

The charger is intended exclusively for charging rechargeable batteries.

The battery data (voltage, capacity and type) for these chargers are stated on the name plate.

The charger is not suitable for non-rechargeable batteries.

The charger is short-circuit-proof and protected against inverse polarity.

This product is covered by the implied warranty within the framework of our general terms and

conditions. Prerequisite for the allowance of warranty claims is in any case the intended use of

the charger.

Quick Guide Filon FUTURE charger

Rev. 1.05

Table of Contents

Do you have a question about the Filon FUTURE and is the answer not in the manual?

Page 1 The operating instructions are intended to explain the functions, safety regulations and displays of the charger. Further information can be found at www.ieb.de. To ensure the safe handling of the charger, the operating instructions must in any case be read by each person using the charger.
Page 2 The charger must not be connected to the mains supply in case of a defect or must be discon- nected immediately by pulling the mains plug. Unplug the unit when not in use. Quick Guide Filon FUTURE charger Rev. 1.05...
Page 3 The charger automatically starts the charging process and executes the charge independently. Equalizing charge Filon FUTURE chargers use the patented Filon FUTURE charging characteristic to charge flooded batteries. This charge profile consists of a main charging phase followed by a dynamic pulse charge phase with a dynamic dU/dt switch-off that does not require additional equaliza- tion.
Page 4 Temperature sensor of the charging phase LED O (red) battery defect or not connected lights up additionally charging phase LED EC pressure loss lights up additionally X = permanent light, O = flashing light Quick Guide Filon FUTURE charger Rev. 1.05...
