4
SPECIFICATIONS
Model No.
MS69
Woofer
6"x 9" PP Cone with Cloth Edge
Tweeter
0.75" PEI Dome
RMS Power
60W
Nominal Impedance
4Ω
Sensitivity
90dB
Frequency Response(±3dB)
80Hz-20kHz
IP Level
IP66
Product Dimensions
276x206x116
(10.9"x8.1"x4.6")
Cutout Diameter
228x155mm (9"x6.1")
CARE AND MAINTENANCE
Cleaning
Make sure to turn all equipments off before cleaning. The cabinet
only needs occasional dusting. Please do not touch the drive units.
Do not attempt to clean the speakers with chemical solvents as this
may damage the paint surface. Clean with a dry cloth.
mm
IN-CEILING
SPEAKER
MS69
Advertisement
Table of Contents
Related Manuals for AMPLITUDE MS69
Summary of Contents for AMPLITUDE MS69
- Page 1 SPECIFICATIONS Model No. MS69 IN-CEILING Woofer 6"x 9" PP Cone with Cloth Edge Tweeter 0.75" PEI Dome RMS Power SPEAKER Nominal Impedance 4Ω Sensitivity 90dB Frequency Response(±3dB) 80Hz-20kHz IP Level IP66 MS69 Product Dimensions 276x206x116 (10.9"x8.1"x4.6") Cutout Diameter 228x155mm (9"x6.1")
- Page 2 SAFETY INSTRUCTIONS INSTALLATION CONNECTIONS Speakers per Channel Connected in Parallel When the speakers are installed in the boats, ensure the boat structure is reliable and that the speakers are firmly attached. 2-CHANNEL AMPLIFIER WITH 8Ω OUTPUT Install the speaker in a location that can structurally support Observe correct the weight of the speaker and its mounting hardware.
