COUNTERFOG® PILAR

USER MANUAL SEPTEMBER 2021

COUNTERFOG® IS A REGISTERED TRADEMARK OF COUNTERFOG EBT DE LA UAH S.L.

IT IS STRICTLY PROHIBITED TO DISTRIBUTE, COPY AND/OR MODIFY THIS DOCUMENT

Table of Contents

Need help?

Do you have a question about the PILAR and is the answer not in the manual?

Questions and answers

Summary of Contents for COUNTERFOG PILAR

Page 1 COUNTERFOG® PILAR USER MANUAL SEPTEMBER 2021 COUNTERFOG® IS A REGISTERED TRADEMARK OF COUNTERFOG EBT DE LA UAH S.L. IT IS STRICTLY PROHIBITED TO DISTRIBUTE, COPY AND/OR MODIFY THIS DOCUMENT...
Page 2: Table Of Contents
ROOM DISINFECTION ......................15 PAUSE ............................. 15 END OF OPERATION ....................... 16 OTHER CAUTIONS ....................... 22 TROUBLESHOOTING ......................22 WARRANTY ......................... 24 DISCLAIMER ........................26 DISPOSAL AND DECOMMISSIONING .................. 27 14.1 DISPOSAL IN EU COUNTRIES ..................27 COUNTERFOG® EBT de la UAH S.L.
Page 3: Introduction
Disregarding can damage the device or produce underperformance. 1.2 DESCRIPTION COUNTERFOG® PILAR is a Fog-generating device for the rapid disinfection of buildings, indoor facilities, offices, vehicles, goods or objects. It provides a dynamic fog cone composed of sub-micrometric droplets of liquid which, when projected into the air, catch air-borne matter (dust, aerosols, spores, etc.).
Page 4: Use
Follow the safety instructions of the manufacturer of the liquid to be fogged. • Users should familiarize themselves with Counterfog® PILAR operation by reading the User Manual prior to first use. It is essential that Counterfog® PILAR users follow all safety warnings as detailed in this operating manual.
Page 5: Liquids Suitable To Be Fogged
ATEX index (DIRECTIVE 94/9/CE -ATEX 137- ) or mixing liquids if manufacturers do not recommend it. Be sure that the nozzle, hose and pipes of the Counterfog® PILAR are empty and clean before filling the container with liquid.
Page 6: Authorized Persons
Avoid splashing or overfilling which could harm the user and the device. • COUNTERFOG EBT de la UAH S.L is not responsible for any injury or damage caused by using this device other than using the specific parameters detailed in this manual.
Page 7: Components
COUNTERFOG® PILAR User Manual 2.1 COMPONENTS Part Name Compressor Pressure tank “FILL” (Filling valve) “EMPTY” (Drain valve) Filter COUNTERFOG® EBT de la UAH S.L.
Page 8 COUNTERFOG® PILAR User Manual “LIQUID” (Liquid valve) “AIR” (Air valve) Check valve Safety valve Pressure gauge “VENT” (Vent valve) Filling Coaxial hose Counterfog® F1/6 Nozzle for massive nanometric fog generation COUNTERFOG® EBT de la UAH S.L.
Page 9 COUNTERFOG® PILAR User Manual COUNTERFOG® EBT de la UAH S.L.
Page 10 COUNTERFOG® PILAR User Manual COUNTERFOG® EBT de la UAH S.L.
Page 11: Recommended Personal Protection Equipment (Ppe)
Earplugs or other ear protectors. 4. ROOM PREPARATION Counterfog® PILAR can disinfect air, clothes and surfaces with a scarce amount of disinfectant liquid. Surfaces must be exposed to air. For a full disinfection remove bed covers. Clothes and objects that should be disinfected separately.
Page 12: Operating Instructions
Check all valves (3 “FILL”, 4 “EMPTY”, 6 “LIQUID”, 7 “AIR” and 11 “VENT”) are closed. o The two switches at the top of Counterfog® PILAR must be OFF. o Carefully open the vent valve (Open 11 “VENT”). o Wait until pressure in the tank is the atmospheric (no air flows out at that time).
Page 13: Power Connection
(3 “FILL”, 4 “EMPTY”, 6 “LIQUID”, 7 “AIR” and 11 “VENT”) are closed. o Double check the two switches at the top of Counterfog® PILAR are OFF. Plug the equipment to the 120 V/60 Hz supply line. 5.4 SWITCH ON AND PRESSURIZATION OF TANK...
Page 14: Operation
COUNTERFOG® PILAR User Manual o Wait until the pressure gauge (check pressure gauge 10) indicates Counterfog® PILAR has been pressurized to 11 bar. Counterfog® PILAR is programmed to automatically provide a pressure of 11 -Check pressure gauge (check 10)-. 5.5 OPERATION •...
Page 15: Room Disinfection
This device jets fogged chemical substances Do not inhale these substances. 6. ROOM DISINFECTION Counterfog® PILAR disinfects both air and surfaces. For an effective operation, the user must gently aim corners from one side to the other, from the upper to the lower parts.
Page 16: End Of Operation
(green arrow in the figure) which deactivates the compressor. o Deactivate the switch on the left (deactivate switch (yellow arrow in the figure) which deactivates the fan. Please, follow the steps in the correct order COUNTERFOG® EBT de la UAH S.L.
Page 17 The tank will remain pressurized. Unplug the equipment from the 120 V/60 Hz supply line. To end the operation, unplug the Counterfog® PILAR device, move it to a safe place and proceed to depressurization: o Double check all valves (3 “FILL”, 4 “EMPTY”, 6 “LIQUID”, 7 “AIR” and 11 “VENT”) are...
Page 18 (green arrow in figure) which deactivates the compressor. o Deactivate the switch on the left (deactivate switch (yellow arrow in figure) which deactivates the fan. Please, follow the correct order of activation of the switches. COUNTERFOG® EBT de la UAH S.L.
Page 19 Check all valves (3 “FILL”, 4 “EMPTY”, 6 “LIQUID”, 7 “AIR” and 11 “VENT”) are closed. o The two switches at the top of Counterfog® PILAR must be OFF. o Carefully open the vent valve (Open 11 “VENT”). o Wait until pressure in the tank is the atmospheric (no air flows out at that time).
Page 20 COUNTERFOG® PILAR User Manual o Tilt the Counterfog® PILAR slightly to both sides so as to drinkable water is being mixed with the remaining disinfectant in the walls of the device. o To evacuate the remaining liquid from Counterfog® PILAR, place a...
Page 21 (yellow arrow in the figure) which deactivates the fan. Please, follow the steps in the correct order Counterfog® PILAR can be then unplugged, moved to another room and plugged again. Unplug the equipment from the 120 V/60 Hz supply line.
Page 22: Other Cautions
Keep out of reach of children • Carefully read all instructions, warnings, cautions and first aid statements prior to use. • Do not enter room while Counterfog® PILAR is in use. Keep door and windows closed. • Use only as directed. •...
Page 23 Device leaks activating / instructions in this manual. Let device completely from the cap deactivating the dry. Wipe the outer parts of the device with a valves cloth. If device still leaks call technical service COUNTERFOG® EBT de la UAH S.L.
Page 24: Warranty
(i) Call COUNTERFOG EBT de la UAH S.L (ii) Prepare the shipment of the device back to COUNTERFOG EBT de la UAH S.L and the original invoice .Please note that the device should be packed in the original shipping box. Should this not be the case the device will not qualify for the above explained warranty service and will be repaired or replaced at customers’...
Page 25 Buyer's premises), assembly/disassembly, decontamination, and installation/re- installation. - COUNTERFOG EBT de la UAH S.L and its authorized Dealers assume no liability for any damage, accident, injury, death, loss or other claim related to or resulting from the use of the device. In no event shall they be held liable for incidental or consequential damages relating to or resulting from the use of the device, any of its parts or accessories.
Page 26: Disclaimer
State authority or Buyer or Buyer's contractors or suppliers. -COUNTERFOG's total liability for all claims of any class arising out of or relating to the conclusion, performance or breach of the Contract, or for any Product or Service shall not exceed the Contract Price.
Page 27: Disposal And Decommissioning
Within the European Union the devices marked with the symbol below may therefore not be disposed of together with unsorted municipal waste Please check with your local authorities for proper disposal. COUNTERFOG® EBT de la UAH S.L.
Page 28 (List of Viricides authorized in Spain for environmental use (TP2) and food industry (TP4) Air conditioning Commercial name Surfaces Equipment Fabrics equipment and conducts RELY+ON VIRKON OX-VIRIN SANITAS PROCSAN SANYTOL HOME AND FABRIC DISINFECTANT OX-VIRIN READY TO USE SANOSIL S010 AMBIDOX 25 OXA-BACTERDET PLUS DD 4112 COUNTERFOG® EBT de la UAH S.L.
Page 29 BIOQUELL HPV-AQ Vaprox ® Hydrogen Peroxide Sterilant Vaprox ® 59 Hydrogen Peroxide Sterilant DUROX LRD DYBAC NT2G WA 520 BF DESCOL BIOFILMSTOP CLEANER DEXACIDE SB7 SANOSIL S010 HC VAPROX SANYTOL MULTI-PURPOSE CLEANER SANYTOL KITCHEN DISINFECTANT COUNTERFOG® EBT de la UAH S.L.
Page 30 • Contact disinfection: Surfaces and PROCSAN 05489 ammonium chloride: Staff 300 ml/m equipment by spraying, immersion or 6.9% brushing of the product diluted in water with a contact time of 15 s. Recommended safety period: 24 hours. COUNTERFOG® EBT de la UAH S.L.
Page 31 Hydrogen peroxide: 5%, -Professional • Contact disinfection for use: Surfaces and 09514 Silver: 0.00415% staff equipment by spraying, scrubbing, brushing, wiping or immersion with the pure product. Contact time 30 min. Safety period of 24 hours. COUNTERFOG® EBT de la UAH S.L.
Page 32 Safety period of 3 hours. size of the area to • Disinfection in air conditioning equipment be treated) and ducts: spraying or fogging of the pure product respecting contact times. Safety period of 12 hours. COUNTERFOG® EBT de la UAH S.L.
Page 33 Glutaraldehyde: 5% • Disinfection of air conditioning equipment and ducts. In air conditioning equipment, use will be only punctual with subsequent recycling of clean air for at least 1 hour in the COUNTERFOG® EBT de la UAH S.L.
Page 34 Apply in absence of people. Safety period of Isopropyl alcohol:9.99% 24 hours • Disinfection of air conditioning equipment and ducts. Micronebulization with the pure product, the mode of use will be only of COUNTERFOG® EBT de la UAH S.L.
Page 35 Peroxide Sterilant staff for direct contact with food or animal feed, within a sealed enclosure or in enclosures Industrial, Commercial and Institutional environments. • Disinfection by a vaporized hydrogen peroxide (VHP) unit COUNTERFOG® EBT de la UAH S.L.
Page 36 10 gr product/ 1 l of • Air disinfection. Fogging with the product professional water for 50-75 m³ diluted in water, it is recommended a safety staff period of 12 hours without people, properly ventilated before entering the enclosure. COUNTERFOG® EBT de la UAH S.L.
Page 37 1 hour without people, then comply with the safety period of 24 hours. It should not be used continuously by mechanical application with a dispenser. COUNTERFOG® EBT de la UAH S.L.
Page 38 Isopropyl alcohol: 9.99% 24 hours. • Disinfection of air and of air conditioning's equipment and ducts: Micronebulization with the pure product. This product is obtained by adding the SOLUCION FORTE SR to the SOLUCION TERMINAL SR. COUNTERFOG® EBT de la UAH S.L.
Page 39 • Disinfection of air conditioning ducts by spraying or fogging WA 520 BF 15-20/40/90- Didecyldiemethylammo - Professional Undiluted • Contact disinfection: Surfaces and 07590-HA nium chloride: staff equipment by spraying, with the pure product. COUNTERFOG® EBT de la UAH S.L.
Page 40 20 min. Benzyl chloride C12-C16 Security period: minimum 4 hours. alkyldimethyl ammonium: 5% COUNTERFOG® EBT de la UAH S.L.
Page 41 (depending on the Safety period of 12 hours. characteristics and • Disinfection in air conditioning equipment requirements of and ducts: spraying or fogging of the pure each installation) COUNTERFOG® EBT de la UAH S.L.
Page 42 User recommended Number procedure concentration SANOSIL S010 HC 987-DES Hydrogen peroxide: -Professional Undiluted at the rate • Contact disinfection: surfaces and 5,0% staff of 80 ml/m equipment by spraying, immersing, wiping or Silver: 0,005% COUNTERFOG® EBT de la UAH S.L.
Page 43 Undiluted at the rate • Contact disinfection: surfaces and staff of 12 min/100 m equipment by fogging with the pure product Apply in absence of people. Safety period of - Specialized 24 hours professional staff COUNTERFOG® EBT de la UAH S.L.
Page 44 SARS-CoV-2 is also an enveloped virus and considering the active substances, concentrations of the same that are included in the biocide products listed in this document as well as the information available to date. COUNTERFOG® EBT de la UAH S.L.
Page 45 4.5%, • Air disinfection: Fogging of the product Biphenyl-2-ol: 7%, previously diluted in water. Glutaraldehyde:4.25% National Register of products for the disinfection of surfaces in contact with food and feed (food industry) COUNTERFOG® EBT de la UAH S.L.
Page 46 Manufacturer's recommended Active Substance User recommended name Number application procedure concentration SANYTOL MULTI- 12-20/40- Didecyldimethyl - Professional Undiluted • Contact disinfection: Surfaces by PURPOSE 05237 ammonium chloride: staff spraying with the pure product. CLEANER 0.5% COUNTERFOG® EBT de la UAH S.L.
