OPERATOR'S MANUAL
MODEL VM10C
Micro Seven, Inc.
th
1095-K N.E. 25
Hillsboro, OR 97124 U.S.A.
phone: 503-693-6982
fax: 503-693-9742
sales@microseveninc.com
www.microseveninc.com
Copyright, © © © © 2013 by Micro Seven, Inc. All right reserved.
Contents of this publication may not be reproduced in any form without the written
permission of Micro Seven, Inc.
All requests for repairs should be directed to the factory.
This instrument is warranted against defective workmanship and materials for a period
of six months. There will be no warranty when the instrument is misused, or when the
factory seal on the instrument is broken.
Printed in U.S.A.
Specification and price change privileges are reserved.
1
broch15f.doc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM10C and is the answer not in the manual?

Questions and answers

Summary of Contents for Micro Seven VM10C

  • Page 1 503-693-9742 sales@microseveninc.com www.microseveninc.com Copyright, © © © © 2013 by Micro Seven, Inc. All right reserved. Contents of this publication may not be reproduced in any form without the written permission of Micro Seven, Inc. All requests for repairs should be directed to the factory.
  • Page 2 Introduction Micro Seven, Inc. ®'s model VM10-C provides voiced measurement data output in your own voice in any language. The measurement includes DC Volt, AC Volt, and resistance. The measurement mode includes voice-trigger mode for starting A/D with audio input through a built-in microphone, value-change mode for starting A/D automatically for input exceeding certain value, continuous mode, and computer interface mode.
  • Page 3 Inputs may be elevated up to +/- 500VRMS input with respective to the earth ground while maintaining data communication at RS232 interface. Front-panel controls: J4: not available for VM10C J5: not available for VM10C Built-in microphone SW 1, Mode switch, short push for announcing current mode, longer push to change to next mode SW 2, Range switch, short push for announcing current range, longer push to change to next mode Note: Pushing SW1 and SW2 simultaneously will place VM10-Cinto mode-programming.
  • Page 4 Calibration: calibration procedure and software is provided. Power On Indicator: green LED display on front panel Dimensions: 19 cm (4") W x 4.5 cm (1.75") H x 10 cm (7.5") L Weight: 500g (1.1 lbs.) Environmental: Operating temperature: 0 to 35 degree C, Humidity: 85% RH at 35 degree C Warranty/Service: 6 months limited warranty.
  • Page 5 The control software provides the following: Measurement mode and range selection Measurement start (trigger) mode selection (continuous, voice trigger, and value trigger mode) Recording voice data into VM10C Calibration Saving/loading measurement set-up data and VM10-C programmed data, factory default programmed data is also provided.
  • Page 6 Rts/CTS hardware handshake Trigger command to start voiced measurement data and receive data over RS232: T Mode register programming: M930n where n is 0 for Volt DC, 1 for Volt RMS, or 2 for resistance Mode inquiry: to find mode setting: Q93 Data output: 00 for volt DC, 01 for volt RMS, or 02 for resistance Range register programming: M940n where n is 0 for the lowest range like 200mVDC or 2k ohm.
