User Manual
Part A
NESTLE
Satellite Positioning System
Model no. 26032001
In order to use the System well, please read this instruction manual
carefully and keep it cautiously for consulting in the future.
Gottlieb
Nestle
GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten
| www.g-nestle.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 26032001 and is the answer not in the manual?

Questions and answers

Summary of Contents for NESTLE 26032001

  • Page 1 User Manual Part A NESTLE Satellite Positioning System Model no. 26032001 In order to use the System well, please read this instruction manual carefully and keep it cautiously for consulting in the future. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten...

  • Page 2: Table Of Contents

    5. Switch on the controller ...................... 6 6. Switch off the controller ...................... 7 7. Controller basic settings ...................... 8 8. Install, register and extend license of NESTLE on2go ............10 9. General operation of the system..................12 System elevation and location reference ..............12 General measurement preparations GNPS-42 ...............

  • Page 3: Introduction

    1. Introduction 1.1 Intro This document describes various basic settings for working with the real-time satellite system NESTLE GNPS-42. This document consists of Part A and Part B. Part A: a step by step guide on setting up and working with the system Part B: Description of the different on2go screen shots.

  • Page 4: Warning And Safety Instructions

    Implementation of modifications or changes to the product. • Use of the product with visible defects or damage. • Use of accessories from other manufacturers that are not expressly approved by Gottlieb Nestle GmbH. • Inadequate protective measures on site. •...

  • Page 5: Insert The Mobile Phone Card And Battery

    Pull out the holding frame and insert the SIM card (nano) as shown. • Push the holding frame back into the compartment. • Insert the battery: • close the back cover careful, • place the controller in the outdoor cover. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 6: Charge The Battery

    Press and hold the Power button for 5 seconds, • Controller starts, • this screen appears as soon as the start process is complete, • swipe the screen to start Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 7: Switch Off The Controller

    To switch off, double tap on the “Power off” symbol. • Note: The power off menu can also be assigned to the power button. Settings / Extended functions / Function key Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 8: Controller Basic Settings

    Android device was not successful, you can set up Internet access manually. • Insert the mobile phone card, see chapter 3 • Switch on the controller, • Swipe once upward on the Android-Main screen, • tap on the icon, Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 9 On2go always uses Android's language settings. The scope of delivery is current German, English, French and Dutch. If other languages are selected in the language settings of Android, on2go starts in English. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 10: Install, Register And Extend License Of Nestle On2Go

    8. Install, register and extend license of NESTLE on2go 8.1 Installation • Connect to the Internet via mobile data or WiFi. • tap on icon, • enter NESTLE on2go in the search field, • choose • tap on install and wait until the installation is complete.
  • Page 11 If you already have a coupon Select from the main menu of the app, and then Enter the number in the "Coupon" field and confirm the process with Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 12: General Operation Of The System

    2.00 m above from the tip of the pole. The antenna height is, when using the original antenna pole, 2.00 m. Enter this value in the software app on2go as height. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 13: General Measurement Preparations Gnps-42

    = FIX GPS – Connector to antenna 11.3 Mount the antenna • Screw the helix antenna on the top of the top pole segment - hand-tight. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 14 Connect the base holder to the pole and • fix with the screw (green arrow). • Put in the Controller holder in the base holder and fix with the second screw (green arrow). Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 15 Push the controller into the holder (yellow arrows) until it sits securely in the holder. • Insert the GNPS sensor cable on the controller into the USB port (green arrow). Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 16: Software App Nestle On2Go

    • To close, tap the menu button on the tablet and "swipe" the on2go app upwards. 12.2 Controls of the NESTLE on2go main screen 1 Program bar with icons of the main menu 2 Status bar display depending on your choice...

  • Page 17: Basic Setting For Correction Data Service

    7. Password of correction data service 8. Select this button to download the mount points. 9. After the download, select the desired mount point. 10. Press this button to make the connection. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 18: Basic Setting Of The Coordinate System

    During the development of the app, special emphasis was placed on the fact that the operation is particularly simple and intuitive. In addition to these instructions for use, the Nestle on2go app offers a learning guide. Call up this learning guide and let the app show you important controls.

  • Page 19: Measure In The Field

    Select to delete a marked layer Select to save the marked layers in a file Select to open a saved file with layers. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 20 Creates a polyline over two or more points. For the starting point of the polyline tap on activate a point by tapping in the graphic. Tap for each additional point of the polyline. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 21 Creates a perpendicular line to an activated line. Activate it in the graphic by tapping a line. Position the system and tap . The point is captured and In addition, a vertical line is drawn on the activated line. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 22 Measure points and lines that describe the terrain well. See 17.4 Record / measure the ring • Measure the circumference as the area that surrounds the terrain. see 17.4 Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 23 (ring) so that it becomes active, • the result is displayed in cubic meters. For a short video, scan the following QR code and select the corresponding video. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 24 4. Distance to the selected point, in meters. 5. Direction to the selected point. • Move the system in the shown direction. • The selected point has been reached (Distance and height difference = 0). Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 25 Click on this box, a dialog for sending the data via e-mail or cloud storage opens. 5. Select the format sequence. (View depending on the selected file type under 2) Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 26: Gis Module

    Projects with GIS properties can only be opened with the gis functionality switched on. • * .agp projects can only be opened, * .agp projects are not intended for Import. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 27: Check The Settings And Positions

    So you have a simple check with regard to your data, at least with regard to the coordinate system, zone, etc. The comparison provides an approximation of a few decimetres. 20. Compliance with national regulations Gottlieb Nestle GmbH hereby declares that the product complies with the applicable European directives and therefore bears a CE marking. 21. Electromagnetic compatibility (EMC)

  • Page 28: Storage And Cleaning

    We recommend a storage temperature of 0 ° C to + 30 ° C, do not leave it in vehicles. • Avoid strong vibrations and impacts during transportation. • Do not expose the device to extreme temperature fluctuations. < 40°C Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 29: Technical Data

    25. Disclaimer Gottlieb Nestle GmbH COMPANY PROVIDE WITH REGARD TO THIS MATERIAL NO WARRANTIES OF ANY KIND, EITHER CONTRACTUAL OR BY LAW. EXCEPT AS PROVIDED HEREIN, INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MARKETABILITY, COMMERCIAL QUALITY, ABILITY FOR A PARTICULAR PURPOSE OR PATENT INFRINGEMENT.
  • Page 30 User Manual Part B NESTLE Software-App In order to use the System well, please read this instruction manual carefully and keep it cautiously for consulting in the future. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 31 1.2. Actual Version ........................4 Warning and safety instructions ..................5 Checking the settings and positions ................6 App starting, App closing ....................6 NESTLE on2go Welcome ....................7 5.1. Login screen ........................7 5.2. Register screen ......................... 8 5.3.
  • Page 32 11.2. Change password ......................55 11.3. Log off / Log on ......................56 Info Menu ........................56 12.1. Walk through guide ....................... 57 12.2. About screen ........................58 Disclaimer ........................59 Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 33: Introduction

    Introduction 1.1. About the document This document describes the full range of functions of the NESTLE on2go software app. 1.2. Actual Version • Version 2.12 Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 34: Warning And Safety Instructions

    Implementation of modifications or changes to the product. • Use of the product with visible defects or damage. • Use of accessories from other manufacturers that are not expressly approved by Gottlieb Nestle GmbH. • Inadequate protective measures on site.

  • Page 35: Checking The Settings And Positions

    To do this, press the lower button to the right of the display on your tablet, a list of currently active programs will appear. Swipe the symbol above to close the app. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 36: Nestle On2Go Welcome

    5. NESTLE on2go Welcome 5.1. Login screen When you start the on2go app for the first time, the login screen is displayed. 1. Enter the e-mail address with which you registered for on2go Wizard. 2. Enter the password you have for on2go here.

  • Page 37: Register Screen

    2. If you click this button, an email with the password will be sent to the email address you entered in number [1]. 3. Click this text to return to the login screen. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 38: Main Screen

    On this screen in the upper right corner you will find the main menu. 1. File Menu. 2. Task Menu. 3. Connection Menu. 4. Toolbox. 5. Profil Menu. 6. Info Menu. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 39: File Menu

    3. Saves the current data in a project, see Save screen. 4. Data import for special format, see import screen. 5. Data recovery (in the event of a power failure, software interruption). 6. See Other Settings Screen. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 40: Open Screen

    After selecting the file, depending on the file type, a dialog appears with further settings corresponding to the selected file type. The following dialog differs depending on the file type. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 41: Open A File In Csv Format

    5. Ellipsoid selection field. 6. Coordinate system selection field. 7. Multiplication factor. 8. Selection field for column order in the file, see also "User-defined". 9. Preview the columns in the file. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 42: Open A File In User Defined Format

    10. X coordinate column selection. 11. Y coordinate column selection. 12. Z coordinate column selection. 13. Layer name column selection. 14. Preview the columns in the selected file. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 43: Open A File In Dxf Format

    Select this check box to overwrite current symbol files used for DXF files. Checkbox for overwriting the line types. Checkbox to overwrite the text style. Country selection field. Ellipsoid selection field. 10. Selection field coordinate system. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 44: Save Screen

    10. Check box to send the file immediately after saving via email or to save it in the cloud, depending on the apps installed on the device. 11. Selection field for the column order and column separator. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 45: Save In Pdf Format

    6. Check box to send the file immediately after saving it via email or to save it in the cloud, depending on the apps installed on the device. 7. Selection field, for selecting the map content. 8. Selection field for sheet size. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 46: Save In Dxf Format

    11. Selection field Storage in 2D or in 3D. 12. Selection field for length unit. 13. Checkbox for the visibility of point numbers. 14. Checkbox for visibility of point accuracy in DX, DY, DZ. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 47: Save Other Formats

    6. The maximum number of pixels to be used for the file in relation to the device's memory. Depending on the file type selected under [3], this line may be missing. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 48: Other Settings Screen

    12. Select here to switch GIS data on or off. 13. Option to choose whether you can use your phone for the survey. 14. Click here to go to the Quick Button Settings. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 49: Quick-Button Screen

    4. Number of quick buttons (there is a total of 10 quick buttons) 5. Method selection for quick button (measurement, line, arc, polyline, polygon, comment, block). 6. Layer for the specific quick button. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 50: Task Menu

    1. Button to open the recording module. 2. Button to open the stakeout module. 3. Button to open the drawing module. 4. Button to open the calculation module. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 51: Recording Modul - Land Survey

    15. Your position in the map view. 16. The current position is displayed as you selected it in the Settings screen. 17. Deviation of the current position in meters. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 52: Comment Screen

    2. Cancel button. 3. Place where you can add your comment. 4. Selection of the font for the output in DXF. 5. Font size for the output in DXF. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 53: Symbol Or Block Screen

    8.2.2. Symbol or block screen 1. Confirmation button. 2. Cancel button. 3. Pull-down menu for selecting existing symbols / blocks. Further fields depend on the selected symbol. 4. Scaling factor. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 54: Layermanager Screen

    10. Menu item for deleting the selected Layer. 11. Button to go to the Export Layers screen to export layers. 12. Button for importing layers brings you to the Import Layers screen. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 55: Add Layer Screen

    8.2.4. Add Layer screen 1. Confirmation button. 2. Cancel button. 3. Location to add the layer name. 4. Colour selection for this layer. 5. Line type selector. 6. Line weight selector. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 56: Layer Export Screen

    Select the path to your layer file with ending "LYL") here and tap on the file. The layer file is imported. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 57: Stake Out Screen

    7. Confirmation button that this point has been staked out. A square is added around the point. 8. Create snap points of the line element if a line has no snap points. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 58: Draw Screen

    1. Method selection (here Enter Point). 2. Layer selection. 3. Button to go to the Layer Manager screen. 4. Draw button that takes you to the “Input point screen”. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 59 3. These first four line fields are for information only - cannot be changed here. 4. Input field for the X coordinate. 5. Entry field for Y coordinate. 6. Input field for Z coordinate (height). Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 60: Draw Method Point With Distance And Angle

    2. Display of data of the selected reference point. 3. Distance from the reference point to the new point. 4. Angle (East = 0, counter-clockwise, angle unit decimal degrees). 5. Button to draw the point. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 61: Draw Method Line

    4. Type of point to choose: start point of the line, or end point of the line. 5. Start point data. 6. Endpoint data. 7. Key to draw the line. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 62: Draw Method Arc

    4. Type of item to choose from. Activate starting point, middle point, end point and then select in the graphic. 5. Start point data. 6. Middle point data. 7. Endpoint data. 8. Button for drawing the arc. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 63: Draw Method Polyline

    5. Display of the snap-points as they were selected one after the other on the map. 6. Button to delete the snap-points in [5]. 7. Button for creating the polyline from the snap-points in [5]. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 64 10. Data of the point selected in the map (see arrow), to be added to the polyline. 11. Button to add the snap point [10] to the selected polyline. * Make sure a polyline is selected. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 65: Draw Method Area

    5. Display of the snap-points as they were selected one after the other on the map. 6. Button to delete the snap-points in (5). 7. Button for creating the area from the snap-points in [5]. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...
  • Page 66 10. Data of the point selected in the map (see arrow), to be added to the area. 11. Button to add the snap-point (10) to the selected area. * Make sure an area is selected. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 67: Draw Method Adjust Point

    1. Method selection (here Adjust Point). 2. Select what the point should be (survey point, comment, symbol or block). 3. Data of the selected point. 4. Key to change the point. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 68: Draw Method Adjust Height

    2. Draw button to change the height of the selected point. The fill value screen will be displayed. Enter the new height and confirm with the confirmation button. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 69: Draw Method Extend

    4. Draw button to expand the selected line element. * The element is extended to the new end point, the previous end point becomes a point that is independent of the element. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 70: Draw Method Offset

    4. Enter the distance by which the element is to be moved. 5. Select the side to which the element should be moved (left or right). 6. Button for moving the selected line element. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 71: Task Calculate

    1. Selection of the calculation method. 2. Select point in the graphic. 3. Calculation button for displaying the X, Y and Z coordinates of the selected point. Result Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 72: Calculate Count

    3. Button to go to the Layer Manager screen. 4. Selection of the type of elements to be counted (points, line, arcs, polylines, areas or all). 5. Calculation button for counting the elements. Result Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 73: Calculate Method Distance

    2. Type of point to select start or end point. 3. Start point data (see arrow a). 4. Endpoint data (see arrow b). 5. Button to calculate distance. Result Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 74: Calculate Method Height Difference

    2. Type of point to choose, start or end point. 3. Start point data (see arrow a). 4. Endpoint data (see arrow b). 5. Button for calculating the height difference. Result Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 75: Calculate Method Length

    You can use this calculation method to calculate the length of a line or a polyline. 1. Selection of the calculation method. 2. Select the element in the graphic. 3. Button for calculating the length of a selected line element. Result Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 76: Calculation Method Area

    You can use this calculation method to calculate the area of a closed polyline. 1. Selection of the calculation method. 2. Select the area in the graphic. 3. Button for calculating the area of a selected area element. Result Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 77: Calculate Method Volume

    3. If From height is selected in [2], a field for entering the reference height appears here. 4. Activate the area in the graphic. 5. Button for calculating the volume of a selected polygon. Result Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 78: Connection Menu

    Connection Menu 1. Menu item that leads you to the connection screen. 2. Disconnect button with a GNSS receiver. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 79: Connection Screen

    Field for filling in the user name. (This entry is only an example) Place where the password must be entered. (This entry is only an example) 10. Button for updating the mount points. 11. Mountpoint selector switch. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 80: Toolbox Menu

    4. Button for removing a in the graphic selected element. 5. Option for more precise measurement. This option can be used during recording and stakeout. All recorded measurements are averaged for 20 seconds. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 81: Add Photo Screen

    10.1. Add Photo screen 1. Confirmation button. 2. Cancellation button. 3. Menu item to take a photo of the item. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 82: Auto Land Survey Screen

    5. Select the distance according to the unit under 4 (if 4 = m, then the storage distance in meters; if 4 = s, then the storage distance is in seconds). Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 83: Profil Menu

    1. Confirmation button. 2. Cancellation button. 3. Place where you can enter your voucher number. 4. Button that takes you to our webshop where you can buy the license. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 84: Change Password

    3. Second place where you have to enter your new password. This must be the same as what you entered in number [2]. 4. Button for changing your password. 5. Option to go back. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 85: Log Off / Log On

    2. Menu item to start the tutorial: Walk though guide. 3. Button to open the "About" screen. 4. Option to open the "Release Note" file. You need an internet connection. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 86: Walk Through Guide

    1. Confirmation button. 2. Cancel button. 3. Selection of the step-by-step learning unit. 4. The step-by-step guide for learning and understanding the on2go app. 5. Guide closing button. Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 87: About Screen

    1. OK button to go back. 2. Name of the software package. 3. Version number. 4. Android ID of your device. 5. Service of the „Google Play Store“. 6. Copyright claim Gottlieb Nestle GmbH | Freudenstädter Str. 37-43 | 72280 Dornstetten | www.g-nestle.de...

  • Page 88: Disclaimer

    13. Disclaimer Gottlieb Nestle GmbH COMPANY PROVIDE WITH REGARD TO THIS MATERIAL NO WARRANTIES OF ANY KIND, EITHER CONTRACTUAL OR BY LAW. EXCEPT AS PROVIDED HEREIN, INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MARKETABILITY, COMMERCIAL QUALITY, ABILITY FOR A PARTICULAR PURPOSE OR PATENT INFRINGEMENT.
