Summary of Contents for Seagull 2C-LP427B
- Page 1 XP-DT325B 2C-LP427B 4B-2053A Thermal Barcode Printer User’s Manual Please keep the user’s manual properly for reference...
-
Page 2: Table Of Contents
Contents Copyright statement..........................１ I. Product............................. ２ II. Receiving............................３ 2.1 Unpacking and checking accessories....................３ 2.2 Printer components........................４ 2.2.1 Front view..........................４ 2.2.2 Rear view........................... ４ III. Installation.............................５ 3.1 Install the printer........................... ５ 3.2 Install the label..........................６ 3.3 Install the external label holder - optional..................７ IV. -
Page 3: Copyright Statement
Copyright statement Information in this subject to change without notice and does not represent a commitment on the part. No part of this manual may be reproduced or transmitted in any form by any means, for any purpose other than the purchaser’s personal use, without the expressed written permission. １... -
Page 4: Product
I. Product Thank you for purchasing our 4B-2053A series thermal barcode printer. This desktop printer will provide you with safe, reliable and efficient printing at a reasonable price. By using it, the roll labels can be printed in a wide range of texts or graphic formats. Meanwhile, its superior function and easy operation make it your best choice among the thermal barcode printers of the same level. -
Page 5: Unpacking And Checking Accessories
II. Brief 2.1 Unpacking and checking accessories This printer is specially packaged to protect against possible damage in transit. However, since the printer may still be subjected to unexpected damage during transportation, you are kindly required to check the packaging and all units carefully when receiving the printer. In case of obvious damage, please contact the sales dealer directly and indicate the severity of the damage. -
Page 6: Printer Components
2.2 Printer components Transparent lid 2.2.1 Front view Pause Printer cover Feed Hook for cover Paper exit 2.2.2 Rear view 1. Power switch 2. USB interface 3. Power interface Note: The transmission interfaces of the printer in the picture will vary depending on the model of machine you purchase. -
Page 7: Installation
III. Installation 3.1 Install the printer 1. Place the printer on a smooth surface and make sure the power is off. 2. Plug one end of the parallel port cable, serial port cable or USB cable into the slot on the back of the printer, and connect the other end of the cable to the appropriate slot of your computer. -
Page 8: Install The Label
3.2 Install the label 1. Insert the paper roll shaft into the paper roll and insert it into the paper roll shaft bushing.(*If the paper roll you are using has a core of 1 inch, remove the 1.5" paper roll shaft bushing, and simply use the paper roll shaft only.) Paper roll 1.5”... -
Page 9: Install The External Label Holder - Optional
5. Close the printer cover. Note: To avoid poor printing quality, make sure the printer cover is closed tightly. 3.3 Install the external label holder - optional 1. Fix the external label holder on the bottom of the printer. 2. Place the label roll on the external label holder. External label holder ７... - Page 10 3. Push Hook for cover forward with both hands to open the printer cover. 4. Route the label from the external paper feed through the external paper guide and into the printer. External paper feed 5. Pass the label through the paper guide and pull the label over the rubber roller. 6.
-
Page 11: Led Indicator And Button Functions
IV. LED indicator and button functions This series of models is equipped with 2 sets of gear drive motors that can handle 300 printers. It has one button and one indicator that can display three colors. Pressing the button in conjunction with different colors or collaborating with the power switch will enable the printer to start multiple functions, such as: feeding paper, pausing the printer, calibrating the label, printing the self-test value, initializing the printer, etc., Details are described as follows. -
Page 12: Gap/Black Mark Sensor Detection
4.3.1 Gap/black mark sensor detection This test aims to determine the sensitivity of the label paper sensor after the printer is turned on. When the user installs a new paper roll of a different specification or initializes the printer and restores it to the factory default value, the label paper gap sensor needs to be re-measured. - Page 13 4.3.2 Gap/black mark sensor detection, printing self-test value and entering the debugging mode This test aims to determine the sensitivity of the label paper sensor after the printer is turned on. When the user installs a new paper roll of a different specification or initializes the printer and restores it to the factory default value, the label paper gap sensor needs to be re-measured.
- Page 14 Self test When the sensor calibration is completed, the printer prints out the self-test value. Before connecting the printer to your computer, you can use self-test to confirm that the printer is functioning properly. The printed self-test value can be used to check the printing quality of the print head and to know the internal settings of the printer.
- Page 15 Debugging mode After the self-test is printed, the printer system enters the debugging mode. In the debugging mode, all roll labels will be printed in machine code. The ASCII strings on the left are the data received by the system. The data on the right are printed from the strings on the left, in hexadecimal values. This function is provided for users or engineers to debug programs.
-
Page 16: Printer Initialization
Note: A 4"wide label paper is required to print all debugging mode data Turn off and on the power to leave the debugging mode and return to the normal printing mode, or press the FEED button to return to the standby state. 4.3.3 Printer initialization The printer initialization function is to clear the downloaded files in the memory (DRAM) and restore the print parameters to the factory default settings. -
Page 17: Skip The Auto.bas Program
4.3.4 Skip the AUTO.BAS program The TSPL2 command language allows the user to load an auto-execute file (AUTO.BAS) into the flash memory. When the printer is turned on, it will be automatically executed according to the file loaded by the user. When you want to skip the AUTO.BAS after power-on, you can use this boot function to ignore this auto-execute file. -
Page 18: Printer Diagnostic Tool
V. Printer Diagnostic Tool Diagnostic Tool is an easy-to-use window-type utility program that allows you to check the current status and settings of the printer, download graphic files, programs, font files, etc., and complete firmware updates according to the actual need. Moreover, it supports creation and download of dot-matrix fonts, transmission of commands or files and so on. -
Page 19: Printer Settings
5.2 Printer settings 1. Select the connection interface between your computer and the printer. The default communication interface of this printer diagnostic tool program is USB, so if the computer is connected through USB cable for transmission, no changes need to be made to the settings 2. -
Page 20: Calibrate The Paper Sensor With The Printer Diagnostic Tool
5.3 Calibrate the paper sensor with the printer diagnostic tool 5.3.1 Auto correction 1. Make sure the paper is installed correctly and the print head is closed. Note: The paper sensor of this model is adjustable. Please make sure that the gap or black mark of the paper will pass through the triangle symbol of the gap sensor (gap sensor position) or the black mark sensor Gap sensor... -
Page 21: Troubleshooting
VI. Troubleshooting 6.1 Common problems The table below shows the common problems the printer operators normally meet and the solutions to them; if you have tried the troubleshooting in the ways we suggest but the printer is still not working properly, please contact the customer service of the vendor for more assistance. - Page 22 Problem Possible cause Solution * Re-connect the transmission line * If you are using a serial port cable - Replace the serial port cable. The pin of the cable must be a 1 to 1 type - Make sure the transmission rate of the printer is set to 9600,n,8,1 * If you are using an Ethernet cable - Make sure the Ethernet RJ-45 blue/purple light...
- Page 23 Problem Possible cause Solution * There is dust or adhesive * Reinstall the consumables buildup on the print head * Clean the print head * The printing density is not * Clean the rubber roller set properly * Adjust the printing density and * The print head is damaged printing speed of the printer * The print head pressure...
- Page 24 Problem Possible cause Solution * The label sensor setting is * Re-calibrate the label sensor incorrect * Set the correct roll label size and roll * The label size setting is label gap size incorrect * If the BarTender software is used, set * The vertical offset setting of the roll label style in the printer driver is...
-
Page 25: Simple Maintenance Procedures Of The Printer
VII. Simple maintenance procedures of the printer The simple maintenance procedures aim to ensure the printing quality and extend the life of the printer. Below are some of our recommended maintenance procedures. 1. Clean and maintain your printer by using the tools listed below: Cotton swab Cotton cloth Vacuum cleaner or air brush... -
Page 26: Update History
Update history Date Content Editor 15.04. 2019 Official release Hu Xiang ２４...
