PROTEAM ix

Installation & Operation Manual

Full Inverter Swimming Pool Heat Pump

iX30T iX35

Thank you very much for purchasing our product, please keep and read this manual carefully before

you install the heat pump.

- 1 -

Table of Contents

Need help?

Do you have a question about the PROTEAM iX30T and is the answer not in the manual?

Questions and answers

Summary of Contents for AES PROTEAM iX30T

Page 1 PROTEAM ix Installation & Operation Manual Full Inverter Swimming Pool Heat Pump iX30T iX35 Thank you very much for purchasing our product, please keep and read this manual carefully before you install the heat pump. - 1 -...
Page 2 Packing List Thank you very much for purchasing our please keep and read this manual carefully Name Qty. Remark Installation & Operation Manual Wire-controller Wire controller box and sponge pad (to be installed on the heat pump shell) Drain pipe (2 m) Drain-pipe connector Rubber shock absorber Heat Pump Unit...
Page 3: Table Of Contents
Please keep installation manual properly, and read it carefully before using. The unit must be installed by qualified technicans according to the instructions in this manual. WARNING: if the unit is installed in locations that are at risk of lightning strikes, lightning protection measures must be provided.
Page 4: Accessories
1. Accessories Each unit produced by our factory comes with the following accessories: Name Qty. Installation & Operation Manual 1 PC User Guide to install the unit Wire Controller 1 PC Used for the machine operation interface Drain-pipe 1 PC Used for draining the condensate water Drain-pipe connector 1 PC...
Page 5: Safety
2. Safety Range of application: 1.Power supply: 380~415V/3N~50/60Hz. 2.Ambient temperature: -10°C 43°C：〜 3.Working water temperature: Min. inlet water temperature 8°C. Max. outlet Water Temperature 40°C. If the system is planned to be used with water temperatures that are outside this range, please contact Proteam.
Page 6 When installing the heat pump in a small room, make sure it is well ventilated. Don't put fingers or objects into the air inlet or outlet as the rotating fan could cause serious injuries. ● If you smell anything burning, turn off the manual power switch immediately, stop operation and contact ●...
Page 7: Heat Pump Working Principle
3.Heat pump working principle 3.1 Heat pump operation Heat pumps use heat from the sun by collecting and absorbing energy from the outside air. This energy is then compressed and transferred to the pool water. Your existing water pump circulates the water through the heat pump, which is normally installed next to the pool filtration system, and the water warms up.
Page 8: Installation Of The Unit
Developments in heat pump technology mean that today heat pumps can efficiently collect heat from the outside air even when the temperature is as low as 7-10°C. This means that for tropical and subtropical climates the pool can be maintained between 26°C and 32°C. 3.2 Air source heat pump working principle 4 way valve Water inlet...
Page 9 ● Do not install in locations where the air contains salt or other corrosive gases. ● Do not install in locations with serious power supply voltage fluctuation. ● Do not install in unstable places (without a firm supporting base), such as a car or cabin. ●...
Page 10 Figure 2. Horizontal installation space requirements (mm） 4.4 Heat pump dimensions Figure 3. Heat pump dimensions : iX-30/ix-30T/iX-35 1084 iX-30T/iX-35 - 10 -...
Page 11 Exploded view Parts Parts Protection grill for fan Water flow switch Front panel Titanium heat exchanger Fan blade Right frame/support Fan motor Manometer/Pressure Gauge Left panel Right panel Left frame/support Controller Evaporator Electrical terminal cover Electrical terminal block Fan-motor mounting bracket Upper frame Electrical cable support Electrical box...
Page 12 4.6 Installation base for heat pump Please refer to Figure 4. A n c h o r b o lt Anchor bolt Screw nut/washer Drainage tray Heat Pump Heat Pump Shock absorb Installation base Drainage tray Concrete Figure 4 Installation base 4.7 Lifting ●...
Page 13: Installation Of The Pipeline
5.Installation of pipes 5.1 Attention ● Prevent air, dust and other material from going into the water pipes. ● Fix the whole system before installing and connecting the water pipes. ● Water inlet and outlet pipes should be protected by an insulation layer. ●...
Page 14 5.2.2 Pipeline installation diagram Water temp sensor wire Feeding water Swimming Pool Controller Drainage Pump signal wire Heat Pump Pump Drainage Figure 7 Diagram（Single unit for reference） ● It is recommended to install a one-way valve for each unit to prevent water back flow. ●...
Page 15: Installation Of Optional Accessories
●The water quality should be analyzed before operating the unit: PH value, conductivity, chloride ion concentration and sulphate ion concentration should be checked. ●Acceptable water quality shown below: PH value Total hardness Conductivity Sulphate ion Chlorine ion Ammonia ion < 50ppm <200μV/cm(25℃) None <...
Page 16: Installation And Operation Of Electric Devices
of the pipe diameter on either side of the flow switch (see Figure 8 below). The direction of fluid must follow the arrow on the controller. The terminal block should be installed in a position that is easy to operate. Figure 8 7.Installation of electrical devices 7.1 Electrical wiring...
Page 17 Figure 9 7.3 Circulation pump installation The heat pump only provides a signal for the circulation pump, A separate A.C. Contactor is required to connect the circulation pump. NOTE: If pump power is less than 250w, connect the pump according to this drawing. Figure 10 - 17 -...
Page 18 NOTE: If pump power > 250w, connect the pump according to this drawing Figure 11 7.4 Electric wiring diagram COMP : COMPRESSOR GND : GROUND AMBT: AMBIENT TEMPERATURE SENSOR WFS: WATER FLOW SWITCH LOW : LOW PRESSURE SWITCH HIGH : HIGH PRESSURE SWITCH COIL: EVAPORATOR COIL TEMPERATURE SENSOR OWT/INWT: INLET / OUTLET WATER TEMPERATURE SENSOR...
Page 19 Figure 12 Electrical wiring diagram - 19 -...
Page 20: Operating Instructions
8.Operating Instructions Wire controller (Buttons and Icons) 8.2 Start up & Locking Attention: Before you start the machine, please make sure the filtration pump is running and there is water flowing through the heat pump. Hold the button for 3 seconds to switch the heat pump ON or OFF. - 20 -...
Page 21 On the main interface, hold for 3 seconds to lock or unlock the controller. When the controller is locked, the icon appears. 8.3 Mode Selected Hold the button for 3 seconds to change the below three operating functions each time: Heating function Cooling function Auto function...
Page 22 Press button to change the below two running modes each time: Silent mode: Choose this mode that the heat pump operates silently. Powerful mode: Choose this mode that the heat pump operates powerfully. 8.4 Set the required temp. On the main interface, press to adjust the required water temp.
Page 23 for 3 seconds to enter Clock setting interface. Hold Clock display on left bottom flashes. Change the Hours using , press to save the Hours, the Minute flashes, press to adjust the Minute. Press to save the data. 8.6 Timer setting Hold the button for 3 seconds to enter the setting of Timer ON &...
Page 24 8.7 Definition of other icons : Defrosting when it flashes : WiFi connected. It will flash under WiFi connecting. : It will flash when there is Error code or system protection. 8.8 Manual defrosting Hold for 5 seconds, and when the Piping temp. is below than Exit defrosting temp., the system can enter into Manual defrosting.
Page 25 Code Description Range Default Desired water temp. in Heating mode 8℃~40℃ 27℃ Desired water temp. in Cooling mode 8℃~28℃ 27℃ Desired water temp. in Auto mode 8℃~40℃ 27℃ Adjustment of water temp. difference before restart 1℃~18℃ 1℃ Stop once the temperature is reached 0=Non stop, 1=Stop 8.10 Running Parameter checking On the main interface, hold...
Page 26 Code Description Scope Inlet water temp. ℃ Outlet water temp. ℃ Ambient temp. ℃ Exhaust temp. ℃ Gas return temp. ℃ Outer piping temp. ℃ Inner piping temp. ℃ EEV aperture Compressor current Radiator temp. Voltage value Frequency Fan motor speed r/min Fan motor speed r/min...
Page 27: Wireless/Remote Control
9.Wireless / remote control 1. Download the ‘Tuya Smart’ App Scan the QR code below to download the mobile APP. Or search ‘Tuya Smart’ in App Store (IOS) or Google play (Android) 2. Sign up for the first time - 27 -...
Page 28 3. Press ‘+’ to add a device 4. Choose ‘Others’ and ‘Other Wifi’ on the interface - 28 -...
Page 29 5. Put your mobile phone close to the pool heat pump, which must be under the same WiFi area 6. Make sure the device (controller/display) is reset (Hold for 3 seconds to make the reset), then using your App to enter the WIFI account and password to connect WIFI. Reset the Wifi function: Hold the for 3 seconds.
Page 30 7. Press ‘Confirm’ to start the connection after completing. The device is successfully added if it’s connect, then press ‘Finish’. - 30 -...
Page 31 8. Functions Remark: The heat pump APP function includes: Turn On/Off the machine Temperature setting and display Mode Selection Failure status display - 31 -...
Page 32: Adjusting And Initial Operation
10.Adjusting and Initial operation 10.1 Attention ● Do not make any adjustments until after the electrical safety inspection has been carried out. ● After the power has been connected, start the test running of heat pump to see if it is working properly. ●...
Page 33: Operation And Maintenance
11. Operation and maintenance 11.1 The heat pump should be installed and operated by qualified professionals. To ensure the continued correct functioning of the system, regular checks and maintenance are recommended. During maintenance, please pay attention to the points below: ●...
Page 34 ● Turn off the power supply ● Remove the refrigerant from the low pressure end; make sure you reduce the exhaust speed, and avoid leakage of frozen oil. ● Remove the compressor air suction and exhaust pipe. ● Remove the compressor power cables. ●...
Page 35: Fault Analysis And Elimination Method
12.Fault analysis and elimination method Code Description Potential reasons Solutions Check the water circuit system, the opening of Insufficient water flow by-pass kits, the running of water pump Water flow protection Check the wiring and reconnect water flow Water flow switch disconnected switch Water flow switch defective Change a new one...
Page 36 motor has damaged EEV blocked or piping system Check the piping system jammed Bad wire connection Check the wiring Connection failure between PCB Defective controller Change a new controller and controller Defective PCB Change a new PCB Bad wire connection Check the wiring Communication failure between Defective PCB...
Page 37: Technical Parameters
Outlet water temp. sensor Sensor disconnected or defective Reconnect or replace sensor failure Suction piping temp. sensor Sensor disconnected or defective Reconnect or replace sensor failure Check the water circuit system/ water flow Insufficient water flow switch Overheating protection under heating mode Outlet water temp.
Page 38 7.63～4.99 7.62～4.98 Cooling Capacity at Air 35℃, Water: 29℃ in, 27℃ out Cooling Capacity (kW) 15.89～3.93 20.11～4.67 Power Input（kW) 4.17～0.56 5.28～0.67 6.98～3.81 6.97～3.81 Power supply 380～415V / 3/ 50 Hz 220～240V / 1/ 50 Hz Max. Power Input (kW) 6.16 7.98 Max.
Page 39: After-Sale Service
14.After-sale service If your heat pump does not operate normally, please turn off the unit and cut off the power supply at once, then contact our service center or technical department. Automated Environmental Systems Ltd. Unit 1, 1 Wimbledon Avenue, Brandon, Suffolk, IP27 0NZ 01842 819130 sales@automatedenvironmentalsystems.co.uk...
