- Page 2 WARNINGS The Draganflyer helicopter is not a toy. This is a precision machine that is vulnerable to misuse and can prove to be dangerous if not properly maintained or used in an inappropriate manor. Throughout this manual, look for this symbol, which will be used to remind you about safe operating procedures.
-
Page 3: Table Of Contents
The Draganflyer SAVS Congratulations on your purchase of the new Draganflyer Stabilized Aerial Video System (SAVS). Following these instructions can help you rapidly add aerial video to your list of val- ued production services. CONTENTS The Essentials The Essentials Safety First - Always A Priority Used correctly, the Draganflyer SAVS will provide Safety First - Page 3 excellent aerial video production. -
Page 4: Pre-Flight - The Helicopter
Pre-flight - The Helicopter Check the packing list enclosed with your Draganflyer to ensure that you have received all of the necessary components and that none are broken or damaged. If anything is amiss, immediately contact Draganfly Innovations. Your Draganflyer was fully assembled and test flown before being packed and shipped to you. For this reason, it is possible to take it right out of the box and begin flying. -
Page 5: First Flights
First Flights If you can answer yes to the following checklist questions, then you are ready for your first flight: Have you checked that you have all the components of your system? Have you completed simulator training, including the four practice lessons? Have you charged both the transmitter and helicopter batteries? Have you chosen an appropriate flying location based on our recommendations? Have you removed and carefully stored the video system? - Page 6 • Teach the Draganflyer what level is. Place the helicopter on a level surface. Stand in front of it 10-15 feet away and hold the left control stick full down and right for a couple of seconds. The two green LED’s will blink to confirm that the level position has been saved.
-
Page 7: Safety Precautions
Details We gave you the essentials first because we know the last thing you want to do is spend time reading through a long boring manual. But as you become familiar with the Draganflyer, we know you will want to know more details about its operation and care. CONTENTS Safety Precautions The Essentials... -
Page 8: Battery System Care
Battery System Care Your Draganflyer helicopter kit comes with a digital peak, lithium polymer and NiCad battery charger. There are two components to this charger, one is the yellow charger itself and the other is a power adap- tor that plugs into a 110 volt wall outlet. To fully charge the Lithium Polymer battery for the Draganflyer it will take between 1 and 2 hours, once completed the charger will turn off. -
Page 9: The Camera System
The Camera System Your Draganfly Eyecam SAVS comes with the components listed below. Please check the package con- tents against the list and if you feel that any items are missing please contact Draganfly Innovations be- fore use. 1 – 1/3 inch CCD camera with white balance 1 –... - Page 10 Uninstalling/Installing the SAVS Camera System Your Draganflyer SAVS comes complete with the Eyecam SAVS pre-installed. However, for training purposes we recommend that you remove the camera system. Once you are comfortable flying the Dra- ganflyer you can easily mount the camera using the following steps.
- Page 11 Eyecam SAVS Technical Specifications Video Camera: Effective Picture Element: 1/3" High Resolution CCD 768(H)x494(V) Horizontal Resolution: 480 Lines Sync System: Internal Minimum Illumination: 0.5 Lux @F1.2, 50 IRE Gamma: 0.44 White Balance: manual or full auto Electronic Shutter: 1/60 to 1/100,000 sec Operating Temperature: 14°F to 113°F (-20°C to 45°) Power Supply:...
- Page 12 Dimensions(L x W x H): 5.4” x 7.2” x 1.6” (13.5cm x 18.0 cm x 4.0 cm) Reciever patch antenna: -right and left circular polarized Operating Frequency: 2.4 to 2.5 GHz Gain: 8 dBi Horizontal beam width: 65 degrees Vertical beam width: 65 degrees Impedance: 50 Ohm...
-
Page 13: Videography Tips
Videography Tips Creating great video with the Draganflyer is much like creating great video with any other tool. Every type of shot, be it a boom shot or dolly shot, requires skill and practice. So, the first step to good video is to become an experienced pilot. The fastest way to do this is to start by using the Draganflyer simulator program. -
Page 14: Flight Controls
Flight Controls and Flight Training The flight controls used on the Draganflyer operate independently of one another and effect the helicop- ter in different ways. In order successfully fly the Draganflyer, all of the controls will need to be used simultaneously. - Page 15 Lesson 1: Familiarization and trimming: Start with the Draganflyer on a smooth, flat surface such as a paved driveway, patio or linoleum floor. Slowly increase the throttle until the Draganflyer just starts to get light and slightly comes off the ground, do not increase the throttle any further at this point.
- Page 16 ing able to take off and land, as well as perform many other maneuvers. Most people will take 1-2 hours of practice to be able to hover steadily, so don’t get discouraged if you do not pick up the skill immedi- ately.
- Page 17 tating further until you have spun it 90 degrees from the starting position and maintain a hover with this orientation. It will help if you turn so you are facing in the same direction as the front of the Draganflyer and watching it over your shoulder.
-
Page 18: Pre-Flight Checks
Select a large, open area, away from anything or anybody that the Draganflyer might cause damage to. Prepare for flight and trim the helicopter. Begin by establishing a hover just above your head and at least 25-30 feet away from yourself. Turn 90 degrees and start moving forwards. -
Page 19: Thermal Intelligence
Thermal Intelligence Thermal Intelligence is a technology developed by Draganfly Innovations that makes use of the princi- ple that the earth and the sky are usually different temperatures. Your helicopter recognizes that differ- ence and uses the information to help it maintain level flight. -
Page 20: Maintenance
Draganflyer Maintenance Unlike a traditional helicopter, the Draganflyer requires very little maintenance, however there are some simple tasks which must be performed on a regular basis. Prior to each flight, you should check the following: • Insure the rotor screws have not loosened. •... -
Page 21: Troubleshooting
Troubleshooting Below are some common problems that you may experience and some suggested solutions. If these don’t solve you problem, contact Draganfly Innovations Technical Support. Problem Cause Solution One or more of the motors is Main wire harness may be... - Page 22 Problem Cause Solution Draganflyer has no/little lift Motors may be worn out Motors will need to be replaced (Continued) usually every 80 full flights, pos- sibly soon if they are run harder. Worn motor will feel rough when turned by hand. When running they will smell like burning elec- tronics and may make a squealing noise...
- Page 23 Problem Cause Solution The rotor blades may be Replace any broken or chipped damaged or loose rotors, ensure all mounting bolts are tight. Draganflyer tries to flip over Rotor blades not mounted The rotor blades labeled “A” are correctly for the front and back while the rotors labeled “B”...
- Page 24 Problem Cause Solution The Trim Tabs may be set Set the trim tabs to neutral and re- too far in one or more trim the helicopter directions The magnets in one or more This is normally cause by a rough motors may have “dropped”...
- Page 25 Problem Cause Solution Low transmitter battery voltage Fully charge the transmitter. You can check the voltage on a volt- meter, it should be about 9.6 volts for flying. The circuit board may be posi- Ensure that the front of the circuit tioned incorrectly board (green lights) is facing the motor with red and black wires...
-
Page 26: Ordering Parts & Accessories
Ordering Parts & Accessories Replacement parts for your Draganflyer SAVS can be ordered from the Draganfly Innovations website. Secure payment via credit card is available. Please check the website, www.rctoys.com for the latest information.
