- Page 1 Wireless AC1200 Wave 2 Industrial Indoor Access Point DIS-2650AP DIS-2650AP 5G 2.4G AL ARM PW R2 PW R1 ST ATU S SIGN AL CONSOLE RESET LAN 2 LAN 1/ PO E Additional documentation is also available on the D-Link website...
- Page 2 Contents English...
-
Page 3: Before You Begin
DIS-2650AP Package Contents 5G 2.4G ALARM POE PWR2 PWR1STATUS SIGNAL CONSOLE RESET LAN2 LAN1/ POE Figure 1: Front Panel This DIS-2650AP package includes the following items: Feature Description Console port which is used to • DIS-2650AP Console connect to the device using an •... -
Page 4: Hardware Installation
Side Panel Features Attach the External Antennas The DIS-2650AP requires two external antennas to function correctly. The included antennas are interchangeable Attach the two included antennas to the RP-SMA connectors on the side of the DIS-2650AP. Turn clockwise to fasten the antennas. -
Page 5: Grounding The Device
Installing the Device on a DIN Rail The DIS-2650AP can be mounted on a standard DIN rail using the included DIN mounting kit. Use the following instructions to install the... -
Page 6: Powering The Device
Use a flat head screwdriver to unscrew the terminal connections that you wish to use. Insert the wires into the terminal The DIS-2650AP can be powered with an 802.3at connectiosn and use the screwdriver to PoE source or by using the built-in terminal tighten the screws to secure the wires. -
Page 7: Manual Configuration
Additional help is available online. To find out more about D-Link products or marketing Note: The management computer, DHCP server information, please visit the D-Link support and DIS-2650AP must be in the same subnet. website at http://dlink.com/support/. Use one of the following methods to Warranty Information... - Page 8 Appendix - Statements ErP Power Usage This device is an Energy Related Product (ErP) that automatically switches to a power-saving Network Standby mode within 1 minute of no packets being transmitted. It can also be turned off through a power switch to save energy when it is not needed. Network Standby: 3.12 watts Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device,...
- Page 9 RF Frequency Requirements This device is for indoor use only when using all channels in the 5.15 to 5.25 GHz frequency range. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands.
- Page 10 Install and use the equipment according to the instruction manual. 電波法により 5GHz 帯は屋内使用に限ります。 Product and Warranty Information To find out more about D-Link Nuclias product or marketing information, please visit the website http://www.dlink.com or https://www.nuclias.com. The D-Link Limited Lifetime Warranty information is available at http://www.dlink.com/warranty...
- Page 11 Industry Canada statement: This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d’...
- Page 12 Notes...
- Page 13 Notes...
- Page 14 Notes...
- Page 15 Notes...
- Page 16 Ver. 1.00(WW)_130x183 2020/12/07 5300-00007836-01W...
