- Page 1 Apex Negative Pressure Wound Therapy Owners and Operators Manual...
-
Page 2: Table Of Contents
Negative Pressure Wound Therapy Owners and Operators Manual Table of Contents DANGER ......................4 WARNINGS ......................4 ADDITIONAL PRECAUTIONS ................4 CAUTIONS 4 INTRODUCTION ....................5 INDICATIONS FOR USE ..................5 CONTRAINDICATIONS FOR USE ................5 PATIENT RISK FACTORS/CHARACTERISTICS TO CONSIDER ........6 PRECAUTIONS ..................... -
Page 3: Danger
Federal (U.S.) law restricts this device to sale by or on the order of a physician. Service work is to be done by Accuro Medical authorized personnel only. Do not immerse or spray any type of liquid directly onto the WoundPro® Apex control unit. -
Page 4: Introduction
Patients with chronic, acute, traumatic, subacute and dehisced wounds, partial-thickness burns, ulcers (such as diabetic or pressure), flaps and grafts may benefit from the use of this device. The WoundPro Apex is intended for use in a healthcare facility only. -
Page 5: Patient Risk Factors/Characteristics To Consider
Patient Risk Factors/Characteristics to Consider Patients at high risk for bleeding and hemorrhage: Certain patients are at high risk of bleeding complications with or without the use of the Apex NPWT System. Patients that are at an increased risk of bleeding (which, if uncontrolled, could be potentially fatal) include the following: Patients with weakened or friable blood vessels or organs in or around the wound as a ●... -
Page 6: Precautions
Negative Pressure Wound Therapy Owners and Operators Manual Precautions Standard Precautions: Implement standard institutional protocol to reduce the risk of transmission of bloodborne pathogens. Continuous vs. Intermittent Apex Therapy: Research is constantly revealing the benefits of both types of therapy in different cases. The patient’s treating physician should decide which therapy mode is appropriate for the wound and the circumstances. -
Page 7: Power Supply
Apex control unit. Dressing Kits A variety of dressing kits are available for use with the WoundPro Apex. Select the dressing kit based on the wound that is being treated. All dressing kits come with all required materials to properly apply the dressing. -
Page 8: System Specifications
Negative Pressure Wound Therapy Owners and Operators Manual System Specifications Weight: Control Unit - 3.8 lbs. (1.7 Kg) Dimensions: Control Unit – 6 ¾ (W) x 8 ½ (H) x 3 ½ (D) in. (17 x 21 x 9 cm) Electrical Specifications 18VDC, 25W Switching Power Adapter... -
Page 9: Electromagnetic Emissions
IEC 60601-1-2 Table 201 Electromagnetic Emissions The following Electromagnetic Emissions information is provided for healthcare facilities where the use of this device around other devices could result in electromagnetic interference. All WoundPro Apex NPWT Systems are designed so that they can be used in ®... -
Page 10: Electromagnetic Immunity
Negative Pressure Wound Therapy Owners and Operators Manual IEC 60601-1-2 Table 202 Electromagnetic Immunity The following Electromagnetic Immunity information is provided for healthcare facilities where the use of this device around other devices could result in electromagnetic interference. All WoundPro Apex NPWT Systems are designed for use in electromagnetic ®... - Page 11 IEC 60601-1-2 Table 204 Electromagnetic Immunity (continued) The following Electromagnetic Immunity information is provided for healthcare facilities where the use of this device around other devices could result in electromagnetic interference. All WoundPro Apex NPWT systems are designed for use in electromagnetic environments. ®...
-
Page 12: Safety Instructions
6. Do not attempt to service the Control Unit except as explained in this guide. Always follow installation and servicing instructions closely. WARNING: SERVICE AND REPAIR MUST ONLY BE PERFORMED BY AN AUTHORIZED Accuro Medical Products, LLC Technician. -
Page 13: Instructions For Use
Instructions For Use CAUTION: These instructions are general guidelines. Refer to the instructions in the dressing kit for dressing changes. The physician should set the rate of dressing changes. The physician should set the expected amount of fluid that the system will remove in 24 hours. Coming into direct contact with bodily fluids is potentially dangerous. -
Page 14: Programming Changes
Negative Pressure Wound Therapy Owners and Operators Manual Programming Changes: Enter the programming mode by pressing and holding the Power button and then pressing the Menu button . The mode that is currently selected (either continuous or intermittent) will be flashing on the display screen. To change between continuous and intermittent modes press either the up or down arrow keys. -
Page 15: Runtime Hours Display
Runtime Hours Display: To enter the “runtime hours” display press the menu key when the unit is in standby ● mode. The display show the total number of hours the Apex NPWT system has been providing therapy to the patient, both in continuous and intermittent modes. To reset the hour counter press and hold the up or the down arrow and then press the ●... -
Page 16: Dressing Changes
Negative Pressure Wound Therapy Owners and Operators Manual Dressing Changes Determine the proper dressing based on the diameter, depth, location and caregivers ● preferences. Generally speaking dressings should be changed every 48 hours unless directed otherwise by physician. Verify that all kit components are accounted for and that there is no damage to the ●... - Page 17 Step 6 – Apply a thin strip of stoma paste (approximately 1” ● long X 1/8” thick) on the periwound area where the drain leaves the wound. Taper the ends of the stoma paste down to a paper thin thickness. Lay the drain tube across the strip of stoma paste. Apply a second thin strip of stoma past (approximately 1”...
- Page 18 Negative Pressure Wound Therapy Owners and Operators Manual Step 6 – Remove the protective backing on the Suction Bell. ● Apply the suction bell over the hole cut in the transparent fill in step 4 above. Make sure that the hole is completely covered with the suction bell.
-
Page 19: Detailed Explanation Of Keypad
Detailed Explanation of Keypad 1. Power 4. Down Arrow 2. Menu 5. Canister Light 3. Up Arrow 6. Alarm Mute Keypad Functions 1. Power Button 4. Down Arrow Button This key turns the Apex on The Down Arrow is used to and off, and also to save any decrease the setting of the programming changes and exit... -
Page 20: Lock Out
The Apex NPWT system monitors several functions and will alarm if it detects a change in normal operation. There are both visual and audible alarms. Refer to the following explanation of alarm conditions to correct the issue. If the problem persists contact Accuro Medical’s customer service department. -
Page 21: Vacuum Leak
Vacuum Leak (3 beeps every 5 seconds) The unit continues to run for the first 30 minutes of a vacuum leak alarm. If the alarm cause is not fixed within 30 minutes, the pump will stop and the alarm will continue to sound. To correct this alarm condition, Check to insure the canister is properly attached to the control unit ●... -
Page 22: General Cleaning Guidelines
Negative Pressure Wound Therapy Owners and Operators Manual General Cleaning Guidelines 1. Cleaning dirty patient care equipment should take place in a designated area. It should be done away from clean or sterile supplies and food preparation areas. 2. Detergent/disinfectants should not be mixed with other germicides or detergents. Using the proper mix insures the most effective killing power of the disinfectant. -
Page 23: Warranty
$45 will be charged and your product will be sent back C.O.D. using your shipper. Warranty service in the United States can be obtained during the warranty period from Accuro Medical Products LLC Please 800-669-4757 to obtain a return authorization number (RA number). - Page 24 Accuro Medical Products, LLC 2854 Hitchcock Avenue Downers Grove, IL 60515 Phone: 800.669.4757 www.accuromedical.com 6/12 Rev D UPC 84635400180...
