Cashino LP-56 User Manual

Thermal label printer

Advertisement

Quick Links

Audit:
Approved:
Tel:0592-5517253 Fax:0592-5231815
Add:4/F,No.318,Tongji South Road, Jimei District, Xiamen, China. 361021
If there is any change in this specification and will not be further notice. Please kindly contact with
Xiamen Cashino Electronic Technology Co., Ltd. for the the latest version.
www.csntek.com
Xiamen Cashino Technology Co., Ltd.
LP-56 Thermal Label Printer
Draw up:
ZhuChunyan 2021.10.11
LanQuanGuo 2021.10.18
Standardization: LiPeiYun 2021.10.19
WangHuanyong 2021.10.20.
Supply Company:Xiamen Cashino Technology Co., Ltd.
User manual
LP-56 Thermal Label Printer
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP-56 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cashino LP-56

  • Page 1 Supply Company:Xiamen Cashino Technology Co., Ltd. Add:4/F,No.318,Tongji South Road, Jimei District, Xiamen, China. 361021 If there is any change in this specification and will not be further notice. Please kindly contact with Xiamen Cashino Electronic Technology Co., Ltd. for the the latest version. www.csntek.com...
  • Page 2 LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. Revised records Change the Date Modify the content Draw up Review Page number 20211011 The first draft ZhuChunyan LanQuanGuo www.csntek.com...
  • Page 3: Table Of Contents

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. Contents Contents................................3 Safety instructions..............................4 1.Overview................................5 2.Product Specifications:.......................... 6 3.Appearance and size..........................7 3.1 Appearance and related components....................7 3.2 Structure size............................8 4. Basic usage..............................8 4.1 Print self-test page..........................8 4.2 Printer status description........................
  • Page 4: Safety Instructions

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. Safety instructions Before operating the printer, please read the following precautions carefully: 1.Safety warning (1) The print head is a heat-generating part. Do not touch the print head and surrounding parts during and at the end of printing.
  • Page 5: Overview

    Xiamen Cashino Technology Co., Ltd. 1.Overview LP-56 is a thermal label printer with label peeling and backing paper recycling functions. It can support thermal label paper with a maximum printing width of 56mm. This product is mainly used for printing labels or receipts for electronic scale products, and can also be applied to other occasions where labels or receipts need to be printed.
  • Page 6: Product Specifications

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. 2.Product Specifications: Print method Thermal-line dot method Print speed Max:120mm/s Printing Resolution 203dpi(8dots/mm) Effective printing area 56mm Paper width 30-62mm paper roll diameter Max:100mm paper roll inner diameter Min:25mm Paper Roll Paper thickness 0.06-0.14mm...
  • Page 7: Appearance And Size

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. conditions Operating humidity 20%RH ~85% RH Storage temperature -20°C~60°C Storage humidity 5% ~90%RH 3.Appearance and size 3.1 Appearance and related components www.csntek.com...
  • Page 8: Structure Size

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. 3.2 Structure size 4. Basic usage 4.1 Print self-test page Method 1: under the shutdown state, hold down the FEED key, boot up, and print out a self-test page, which contains serial transmission rate, language and other information.
  • Page 9: Printer Status Description

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. 4.2 Printer status description The printer has three indicator lights, namely the power indicator light, the error indicator light, and the Bluetooth indicator light. POWER indicator STATUS indicator buzzer Printer status...
  • Page 10 LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. roller and the backing paper backing shaft as shown in the figure below, and fix the backing paper on the backing shaft with the recycling paper clip, and then as shown in the following figure. Rotate the recovery shaft in the direction shown to make the backing paper in a taut state.
  • Page 11: Interface Description

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. 5.Interface Description Power Serial Serial Power XH2.5mm/4Pin Terminal No. Signal Name Description Ground Ground Power supply Power supply www.csntek.com...
  • Page 12: Daily Maintenance

    LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. Serial(RS232/TTL)XH2.00/4Pin Terminal No. Signal Name Description Request to send (Data terminal ready) Transmission data Receive data Ground USB PH2.0 mm/4Pin Terminal No. Signal Name Description VUSB +5V Power supply Data line negative...
  • Page 13 LP-56 Thermal Label Printer Xiamen Cashino Technology Co., Ltd. ■ Clean the print head, sensor and rubber roller *Turn off the power of the printer, slide the upper cover limit block, and open the upper cover assembly of the printer to the 90 degree position;...
