USER MANUAL

ENGLISH

Odin CL-4 Connect

Product code: D3915

Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Table of Contents

Need help?

Do you have a question about the Odin CL-4 Connect and is the answer not in the manual?

Questions and answers

Summary of Contents for DAPAudio Odin CL-4 Connect

Page 1 USER MANUAL ENGLISH Odin CL-4 Connect Product code: D3915 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
Page 2 Odin CL-4 Connect Preface Thank you for purchasing this DAP product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
Page 3: Table Of Contents
Odin CL-4 Connect Table of contents Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 Text Conventions ..............................3 Symbols and Signal Words ..........................3 Symbols on the Information Label ........................4 Safety ..................................4 Warnings and Safety Instructions ........................4 Requirements for the User ..........................
Page 4: Introduction
Odin CL-4 Connect Introduction Before Using the Product Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual.
Page 5: Symbols On The Information Label
Odin CL-4 Connect Indicates important information for the correct operation and use of the Attention product. Important Read and observe the instructions in this document. Electrical hazard Provides important information about the disposal of this product. Symbols on the Information Label This product is provided with an information label.
Page 6 Odin CL-4 Connect ● Do not wrap the power cable around the power adapter or any other object. This can damage the internal wires. ● Do not cover the power adapter with anything when it is plugged into the socket-outlet. This may cause overheating.
Page 7: Requirements For The User
Description of the Device The Odin CL-4 Connect is an Ethernet hub used to create a network between a computer and the Odin Line Array System. The hub has 4 RC NET ports to which you can connect up to 12 Odin speaker units per port and one uplink port to connect the device to a computer or a router.
Page 8: Product Specifications
The Odin CL-4 Editor is a free software program developed by Highlite International. You can download the software from the Odin CL-4 Connect product page on the website of Highlite International. The software allows you to configure the editable DSP presets of the Odin Line Array System.
Page 9: Dimensions
Odin CL-4 Connect Dimensions Fig. 03 Installation Safety Instructions for Installation Attention Make sure there is enough space for ventilation around the device. Do not install near equipment that produces heat, for example amplifiers. Installation Site Requirements ● The device must be installed only indoors.
Page 10: Setup
Setup Before setting up a network with the Odin CL-4 Connect you need first to configure the device. You can connect the device via Wi-Fi or via LAN to a computer or a laptop and configure its settings via the web browser.
Page 11: Configuration Via Web Browser
Odin CL-4 Connect Configuration via Web Browser The Odin CL-4 Connect can be configured via a web interface. To connect the device to a web browser follow the steps below: 01) Connect the Odin CL-4 Connect to a laptop/computer. Refer to 5.1. Connecting to a Computer via Wi-Fi or to 5.2.
Page 12: Ap Interface Settings
Odin CL-4 Connect AP Interface Settings In this section you can configure the following settings: ● Wireless network: network mode, SSID, frequency channel ● CL-4: security mode ● WPA: WPA algorithms, pass phrase ● LAN Setup: IP address, Subnet mask, DHCP type...
Page 13: Application Settings
Odin CL-4 Connect Application Settings In this section you can configure the following settings: ● UART Settings: baud rate, data bits, parity, stop, CTSRTS ● UART AutoFrame Settings ● Network Settings: mode, protocol, port, max TCP number, TCP time out...
Page 14: Connecting Speaker Units
Odin CL-4 Connect Connecting Speaker Units To connect the speaker units to the device, follow the steps below: Use a UTP CAT-5/CAT-5E/CAT-6 cable to connect one of the 4 RC Net ports (06) of the device to the RJ45 data connector IN on the Odin speaker unit.
Page 15: Network Setup Examples
Odin CL-4 Connect Network Setup Examples With the Odin CL-4 Connect you can create a network between a computer/laptop and the Odin Line Array System. You can connect up to 12 Odin speaker units per port to the device. The network allows configuration of the editable DSP presets of the Odin Line Array System with the Odin CL-4 Editor software.
Page 16: Network Setup Via Lan
Network Setup via LAN In a network setup via LAN the Odin CL-4 Connect is connected via a router to the computer/laptop. Use a UTP CAT-5/CAT-5E/CAT-6 cable to connect the LAN port (07) of the device to one of the RJ45 ports on your router.
Page 17: Connecting The Software
For more information about installing the software and working with the program refer to the user manual of the software. You can download the user manual of the Odin CL-4 Editor from the Odin CL-4 Connect product page on the website of Highlite International.
Page 18: Troubleshooting
Odin CL-4 Connect Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage.
Page 19: Deinstallation, Transportation And Storage
Odin CL-4 Connect Deinstallation, Transportation and Storage ● Use the original packaging to transport the device, if possible. ● Clean the device before storing. Follow the cleaning instructions in chapter 7.1.1. Basic Cleaning Instructions on page 17. ● Store the device in the original packaging, if possible.
