FEATURES
 2 555 timers
 BLINK/SOLID switch
 ON/OFF switch
 Battery included
 Magnets and adhesive pin for "pinning"
and making it wearable
APPLICATIONS
 A gift that keeps giving
 Improving your soldering skills
 An easy way to tell someone how you
really feel
 PCB badge collections
DESCRIPTION
It's a surface mount solder-it-yourself kit
that drives 4 LEDs in a heartbeat-style blink
pattern by cascading two 555 timers. It also
is a terrible, terrible, awful layout. Especially
if you like things to be straight and 45 and
90 and neat and tidy. Give it to yourself as a
positive affirmation that you really do kick
ass despite your oddities or give it passive-
aggressively to your "favorite" person. It
also has an on/off switch and blink/solid
switch and includes a CR2032 battery. If
that's not enough we also included 2 super-
strong
neodymium
adhesive pin.
San Luis Obispo, CA
www.alpenglowindustries.com
Instagram: @AlpenglowInd
magnets,
and
an
Angry Storm Cloud
PCB Blinky Badge Solder Kits
After assembly:
Irreverent Electronics That Spark Delight!
ASC-0001
1 of 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the ASC-0001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alpenglow Yarn ASC-0001

  • Page 1 ASC-0001 Angry Storm Cloud PCB Blinky Badge Solder Kits FEATURES  2 555 timers  BLINK/SOLID switch  ON/OFF switch  Battery included  Magnets and adhesive pin for “pinning” and making it wearable APPLICATIONS  A gift that keeps giving ...
  • Page 2 ASC-0001 San Luis Obispo, CA Irreverent Electronics That Spark Delight! www.alpenglowindustries.com 2 of 9 Instagram: @AlpenglowInd...
  • Page 3 ASC-0001 San Luis Obispo, CA Irreverent Electronics That Spark Delight! www.alpenglowindustries.com 3 of 9 Instagram: @AlpenglowInd...
  • Page 4 ASC-0001 4 of 9...
  • Page 5 ASC-0001 INSTRUCTIONS: 1. Unpack Your Kit & Download/Print 3. Solder All of the Resistors Assembly Diagram Back of board with resistors: Full kit: 4. Solder All of the Capacitors 2. Solder 555 Timers Back of board with capacitors: Back of board with 555 timers:...
  • Page 6 ASC-0001 7. Flip Board Over, Solder LEDs 5. Solder All of the Diodes Front of board with LEDs: Back of board with diodes: 8. Flip Board Over, Solder Battery Holder 6. Solder the Switches Back of board with battery holder:...
  • Page 7 ASC-0001 9. Attach the Adhesive Pin 11. Insert the battery and turn it on! Back of board with adhesive pin: One switch is ON/OFF, the other is BLINK/SOLID. In the above photo in step 9, the ON/OFF switch is on the left and in the OFF position.
  • Page 8 ASC-0001 • The first one minute may in fact have 12. Troubleshooting a slightly different pattern, there can One of the LEDs don't light up: be a small "break-in" period. (It's an • Check the direction of your LEDs! interesting effect due the initial Did you solder them on in the proper voltage &...
  • Page 9: Connect With Us

    ASC-0001 YOU MAY ALSO LIKE SPC-0001 Spooky Coffin PCB Blinky Badge Solder kit CONNECT WITH US! We love to see what you do with our products! Tag us in your posts and use #AlpenglowInd or #alpenglowindustries. Instagram: @AlpenglowInd YouTube: Alpenglow Industries Email: info@alpenglowindustries.com...
