  • Page 1 Instruction Manual Metal-cutting manual circular HKS 230 HKS 230...
  • Page 2: Table Of Contents

    10 Spare Parts ............14 Copyright © 2021 Stürmer Maschinen GmbH, Hallstadt, 10.1 Ordering spare parts........14 Germany. 10.2 Spare parts drawing........15 11 EC Declaration of Conformity ......18 12 Notes ..............19 Subject to technical changes and errors. HKS 230 | Version 3.06...
  • Page 3: Introduction

    Safety instructions in this operation manual have been Repair service: highlighted with symbols. Safety instructions are indi- cated by signal terms that express the degree of risk in- Fax: +49 (0) 951 96555-111 volved. email: service@stuermer-maschinen.de HKS 230 | Version 3.06...
  • Page 4: Operator Responsibility

    In this process, the following shall apply in particu- ers, users under the influence of alcohol or medication. lar: These operating instructions specify the following per- sonal qualifications for the different tasks: HKS 230 | Version 3.06...
  • Page 5: Personal Protective Equipment

    - Use only genuine spare parts and accessories to avoid potential risks and risk of accident. Respiratory protection Respiratory protection serves to protect the respira- tory tract and lungs against absorbing dust particles. HKS 230 | Version 3.06...
  • Page 6: Safety Labels On The Metal Cutting Circular Saw

    (e.g. magnesium or similar). - Use of the metal hand-held circular saw for materi- als other than aluminium, PVC or wood materials (e.g. machining of hard metal or similar, plastic, etc.). HKS 230 | Version 3.06...
  • Page 7: Technical Data

    Dimensions 620 x 320 x 270 mm Electrical data Voltage 230 V/50 Hz Output 1700 W Fig. 2: Type plate HKS 230 Fuse min. 10 A Transport, packaging, storage Connecting cable length 2.8 m 5.1 Delivery and transport Cutting data...
  • Page 8: Machine Description

    Only use saw blades that are permissible in terms of 10 Cutting depth adjustment (hidden) dimension and maximum rotational speed. For your own safety, only use original Metallkraft saw blades. 11 Hand grip 12 On/off switch 6.2 Scope of supply...
  • Page 9: Setting The Cutting Depth

    If other angles are required, clamp the clamping screw at the desired position Saw blade outside the detents. Step 3: Firmly tighten the clamping screw on the back. Fig. 4: Saw blade assembly HKS 230 | Version 3.06...
  • Page 10: Using The Cutting Guide Display

    90 ° cuts for 45 ° cuts piece with your free hand. Fig. 7: Cutting guide display Step 1: Insert the rip fence into the mounting straps pro- vided on the machine support. HKS 230 | Version 3.06...
  • Page 11: Saw Blade Guard Function

    Before using the manual cir- cular saw, always ensure that the saw blade guard can move freely and does not jam at any point. Make sure that the guard quickly and fully snaps back into the closed original position. HKS 230 | Version 3.06...
  • Page 12: Securing Workpieces

    Clamp the workpiece correctly on a suitable and stable support and using suitable aids. Support long work- pieces to prevent them dropping or tilting. HKS 230 | Version 3.06...
  • Page 13: Cleaning The Machine

    In other words, the motor will no longer run after reaching the wear limit. For this reason, the carbon brushes first need to be checked and possibly replaced if the machine unexpectedly fails to start. HKS 230 | Version 3.06...
  • Page 14: Disposal, Recycling Of Used Device

    - Address of dispatch Example The handle for the HKS 230 metal hand-held circular saw must be ordered. The saw blade has the number 42 in the spare parts drawing. When ordering spare parts, send a copy of the spare...
  • Page 15: Spare Parts Drawing

    Spare Parts 10.2 Spare parts drawing Spare parts drawing HKS 230 The following drawing is intended to identify the required spare parts in the event of service. If applicable, submit a copy of the parts drawing including the highlighted components to your authorised retailer.
  • Page 16 Bevel gear (M1.0x46T) Electromagnet (164x80x48) Parallel key (4x4x7) Panhead machine screw- Input shaft (M1.25x9T) washer (M4x12xP0.7) Panhead tapping screw-b Cable clip (M5x25) Power supply cable Panhead tapping screw-b (M5x30) Motor switch Gear housing Magnet switch HKS 230 | Version 3.06...
  • Page 17 Female spade terminal Spade terminal boot Crimp cab connector (C4) Zip tie (2.5x100MM) O-Ring (Ø12x4) E-Clip(E-3) Panhead tapping screw(M4x12) Bracket top Bracket bottom Panhead tapping screw-b (M4x16) Hex nut (M5xP0.8 Socket set screw (M4x8xP0.7) Flat washer (Ø6xØ13x1) HKS 230 | Version 3.06...
  • Page 18: Ec Declaration Of Conformity

    Risk assessment and reduction of risks (ISO 12100:2010) EN 60204-1:2007-06 Safety of machinery - Electrical equipment of machines – Part 1: General requirements Responsible for documentation: Kilian Stürmer, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 15 April 2014 ______________________ Kilian Stürmer Managing Director HKS 230 | Version 3.06...
  • Page 19: Notes

    Notes 12 Notes HKS 230 | Version 3.06...
  • Page 20 www.metallkraft.de...
