Ozone ZX-05B User Manual

Ozone Sterilizing Machine ZX-05B
Feature & Technical Information
• Ozone generator is a compact machine with PCB controller in the body of the unit,
also can generate ozone to sterilize the air by its oxidation and be deoxidized into
oxygen without secondary pollution.
This unit is made of ceramic place as a discharge part.
•
Power Supply Unit is the core technique of the unit, included frequency conversion
•
and boost converter. It adopts soft start to make the unit to operate stably with high
load capacity and highly efficient.
• The unit should operate together with a clean air intake.
Discharge compartment is cooled by wind cooling system. The unit will produce
•
electric discharge sound and ozone output stably without damaging components.
Model ZX-05B
Rated Power 100 W
Effective Area 50-80 m
Cyclic Timer
Function
Plate Size 225×185×165 mm
Packing
1× Ozone generator, 1× Power cord, 1× User's manual, 1× Service card
2
Auto ON-OFF
indicator light
Input Power AC 220V
Working
50/60 Hz
Frequency
Ozone Output 5000 mg/H
Timer 120 minutes
Product
270×240×200 mm
Dimensions
timer
power switch
