Summary of Contents for Micron Security Products IM4TB
- Page 1 MICRON HOME INTERCOM SYSTEMS 7-Inch Touch Button Monitor IM4TB / IM4TBW USER MANUAL...
- Page 2 USER MANUAL Micron 7 Inch Touch Bu�on Monitor IM4TB – Touch Screen IM4TBW – Touch Screen – WiFi Informa�on & specifica�ons contained in this manual maybe changed for the benefit of product development and improvements.
-
Page 3: Table Of Contents
Table of Contents 1. Features and Functions ................... 2 2. Packing Contents ..................... 2 3. Indicators and Connection details ................3 3.1 Front & Side ....................3 3.2 Rear & Bottom ....................4 4. Connection Diagram ....................5 4.1 Wiring Diagram ..................... 5 5. - Page 4 WARNING AND CAUTION Please make sure to follow the instructions to prevent any product danger or product failure. Do not attempt to disassemble or repair. This product requires a qualified technician Do not install this product in a hot or humid place Do not place heavy objects on this product Do not use solvents or detergents to clean the product Do not attempt any connections whilst the power to the system is on...
-
Page 5: Features And Functions
1. Features and Functions Micron 7 inch touch button monitor Features: •Built-in WIFI, support IOS & Android APP remote control (IM4TBW only) • 1080P/720P/CVBS display & record • Connect up to 2 door stations, 1 master monitor + 3 slave monitors •... -
Page 6: Indicators And Connection Details
3. Indicators and Connection details 3.1 Front & Side Part Name Description Micro SD Card Slot Micro SD Card Slot Power / Do-not-disturb White led – Monitor power is on Indicator Led flashing -- Mute function is enable Microphone Microphone to talk to the door station Unlock Button Touch button for releasing door lock Talk Button... -
Page 7: Rear & Bottom
3.2 Rear & Bottom Part Name Description CCTV Input Connection for CCTV 1 & CCTV 2 Connection for home router (IM4TBW only) Video Input Connection for door station 1 & door station 2 Intercom Output Connection In for additional Monitor Intercom Input Connection Out for additional Monitor CCTV Output... -
Page 8: Connection Diagram
4. Connection Diagram 4.1 Wiring Diagram Wiring Example of Intercom with one monitor and optional 2nd door station. -
Page 9: Monitor Installation
Wiring Example of Intercom with one monitor, 2 Slaves and optional 2 door stations. MAXIMUM CABLE DISTANCE IS 100 METERS Note： 1. Normally Open Contact can only switch 100mA and only operates from the gate unlock button. 5. Monitor Installation Standard monitor installation height is about 1,500mm where screen center is at eye level;... -
Page 10: Operation Description
6. Operation Description 6.1 Visitor Call When door station calls in, the visitor’s image will be shown on the monitor screen and you can touch to talk with the visitor and touch it again to terminate the talk. ※ Icon Definition Short touch for capturing a picture;... -
Page 11: Monitor Function
conversation will be terminated. • You can touch to transfer the current call to other extension monitors. 6.2 Monitor Function Touch when device is on standby, the system will enter monitor mode, and will show image from the corresponding door station. 6.3 Memory 6.3.1 Image &... -
Page 12: Intercom Function
Note: • Micro SD card must be formatted by the monitor to function correctly. • Micro SD card is excluded in the package. • The videos include both the video recorded during monitoring and recorded during motion detection. •In standby mode will flash when has new photo/video. -
Page 13: Scheduled Do Not Disturb Function
6.6 Scheduled Do Not Disturb Function The monitor supports scheduled do not disturb function. You can enable/disable the mute function and set the time range of do not disturb mode in setting page. 6.7 Screensaver Function The monitor supports screensaver function (date & time display in standby mode). -
Page 14: Customization Of Mp3 Melody - Sd Card Required
You can enable/disable screensaver function in setting page. 6.8 Customization of MP3 melody – SD Card Required The Intercom supports 16 preprogrammed melodies and will support a customized an extra MP3 melody for Door 1, Door 2 and Internal intercommunication by SD card. You can customize MP3 as the following: 1. -
Page 15: Setting Page
If the SD card is not recognized, please format it on the device. 7. Setting Page Touch when the device is on standby, and then the screen will enter main setting page. IM4TBW IM4TB • In the WiFi setting page, you can turn WiFi on or off and set call forwarding... - Page 16 latency for the monitor,you can also reset WiFi setting. • In the Motion detection setting page, you can turn Motion detection on or off, set one camera as default for motion detection, setsensitivity,motion detectionframe rate and time range of motion detection. Enable or disable the motion detection notification.
-
Page 17: Specifications
unavailable. • Once a moving object is detected, the monitor will record a video automatically(the duration of recording video is 60s). When monitoring door station or CCTV, motion detection will pause until the monitoring ends. 7.1 Specifications Category Specification Input power DC: 15V. - Page 18 7. After the device configure successfully, you can set device name and save. ① ② ③ ④ ⑤ ⑥ Note: • The home router must be connected to external networks if the call from door station needs to be transferred to your mobile phone; •...
-
Page 19: Control The Monitor Through The App
3. If the device is online, you can input the password and add it. 8.2 Control the Monitor through the APP 1. Select the device you want to connect to and enter the monitor page(when you first use it, it will remind you to modify the default password); 2. -
Page 20: Call Forwarding Latency
play/pause record a video unmute/mute capture a picture change preview frame change display size rate Multi-device preview talk record playback release door lock release the electric lock open the automatic door Switch preview channel full-screen display 8.3 Call Forwarding Latency In the monitor WiFi setting page, the "call forwarding latency"...
