2.5- 5.0 GALLON
GAS CAN HOLDER
INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gas can holder 2.5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Jungle Jim’s Gas can holder 2.5

  • Page 1 2.5- 5.0 GALLON GAS CAN HOLDER INSTRUCTIONS...
  • Page 2 HARDWARE ITEM # PART # DESCRIPTION QUANTITY 2.5 gallon frame 3/8” wire frame BH-AS Adjustment bracket 3/8” – 16 x 1” carriage bolt 3/8” – 16 nylon lock nut Tri-glide fasteners (not shown) Snap buckle male/female (not shown) shown 1” x 45” web straps (not shown) ***PLEASE NOTE THAT ON THE 5.0 GALLON GAS CAN HOLDER, AN ADDITIONAL HARDWARE KIT IS INCLUDED FOR ADDED STABILITY OF TALLER GAS CANS.
  • Page 3 ASSEMBLY *** NOTE*** Gas can holder may be mounted in an enclosed trailer, on the floor, using the same instructions. Additional holes are provided on the rear side of the holder allowing you to secure the holder to the wall AND the floor, however you will need to purchase additional hardware according to your trailer wall. We do not recommend mounting on the wall due to the weight of the can when filled with gas.
  • Page 4 Take 1 of the 45” straps & thread one end through both sides of a tri-glide fastener as shown: 2 Loop the end through the bottom of the gas can holder exactly as shown: 3 Thread the end back through the tri-glide on top of the strap you inserted in step 1.
  • Page 5 7 Using the female section of the buckle, thread the end of the strap through the buckle and back through the tri-glide as in step 3. To adjust the strap length, first place the desired can in the holder and connect the buckle. Adjust the straps to fit the gas can snugly.
  • Page 6 Dimensions 2.5 gas can holder 5.0 gas can holder JUNGLE JIM’S ACCESSORY PRODUCTS www.junglejimsap.com1-888-844-5467 REV 3-9-20...

This manual is also suitable for:

Gas can holder 5.0
