INSTRUCTIONS FOR USE

THERMAL WIRE STRIPPING - BDT3A & BDT3 TS

FTM Technologies thanks you for buying our thermal stripper.

1. Cautions for use........................................................p.2

2. Product description.................................................p.2

3. Safety instructions...................................................p.3

4. Installation...................................................................p.3

5. Starting.........................................................................p.3

6. Maintenance...............................................................p.4

7. Warranty .....................................................................p.5

info@ftm-technologies.com - +33 (0)1 40 86 00 09 - www.ftm-technologies.com

Table of Contents

Need help?

Do you have a question about the BDT3A and is the answer not in the manual?

Questions and answers

Summary of Contents for FTM Technologies BDT3A

Page 1 Soldering irons Specialized tools for wiring and tinning Hand tools, consumables and workshop equipment INSTRUCTIONS FOR USE THERMAL WIRE STRIPPING - BDT3A & BDT3 TS FTM Technologies thanks you for buying our thermal stripper. 1. Cautions for use…………….…………………………….…...p.2 2. Product description………………………………...……….p.2 3.
Page 2 Children should be supervised to ensure they do not play with the device. 2. PRODUCT DESCRIPTION The thermal stripper is composed of two parts : Power units BDT3A Technical data Reference L x W x H...
Page 3 Fume hoods Soldering irons Specialized tools for wiring and tinning Hand tools, consumables and workshop equipment PC4NC Plier for large diameter cable They are connected to the control box through a fast connector. Length of the connection cable is 1,05 m. Choice of electrodes The electrodes will be choosen according to the diameter of the wire and to the nature of insulation being stripped.
Page 4 The temperature reached will depend on the type of electrodes used. The chart below is made for new type EEDT2 electrodes. These values are indicative and it will be necessary to carry out a preliminary test. Graduation BDT3A Graduation BDT3 TS Stabilized temperature °C Insulation...
Page 5 Fume hoods Soldering irons Specialized tools for wiring and tinning Hand tools, consumables and workshop equipment If the electrodes temperature is wrong look first at the electrodes tightening. Periodically take a look to electrical contacts to reduce electric trouble. Temperature choice The temperature of use depends on the section and the insulation which has to be stripped.
