Genexis FiberXport OCG-16m User Manual

User manual
FiberXport ® OCG-16m data/voice module
and optional OCG-12m CATV receiver module
Contents

1. Introduction

2. General warnings and remarks
3. Module user specification
4. Installation instructions
5. Powering the module
6. Overview of the information provided by the various LED indicators
7. Connecting external equipment to the module
1. Introduction
The OCG-16m is equipped with 2 RJ-11 ports to which conventional telephone sets can be
connected. Additionally the OCG-16m is equipped with 4 RJ-45 10/100 Mbit/s ethernet ports to
which external equipment can be connected.
Furthermore an optional OCG-12m CATV receiver module can be added to the OCG-16m
data/voice module in the FXP-10 housing.
In order to help the end-user and/or installer to monitor the correct functioning, a set of LED-
indicators is present on the front of the OCG-16m module.
The OCG-16m data/voice module is specifically designed to be mounted in a FiberXport
housing. For this housing separate installation instructions are available.
2. General warnings and remarks
For adequate performance of the OCG-16m module, the mounting instructions for the
FiberXport ® FXP-10 housing (available separately) must be followed.
As noted in the FXP-10 installation instructions, the housing should have been mounted at a
location:
with sufficient room (at least 10cm) at the right hand side of the FiberXport
•
connection of input/output cables
with at least 10 cm of free space above the housing
•
with at least 5 cm of free space at the left hand side of the housing
•
NOT in positon where the sun will be able to shine on the housing
•
NOT next to a radiator or behind a curtain.
•
The FiberXport ® OCG-16m is a Class 1 Laser Product according to IEC 60825-1.
This classification implies that the FiberXport
Nov 2005, Genexis B.V., Lodewijkstraat 1A, 5652 AC Eindhoven, The Netherlands, www.genexis.nl
® is completely safe for purposes of eye safety.
Genexis Genexis
® FXP-10
® to allow easy
