Cautions and Warnings
Overview
In This Publication
2000 Simplex Time Recorder Co., Westminster, MA 01441-0001 USA
All specifications and other information shown were current as of publication, and are subject to change without notice.
DO NOT INSTALL ANY SIMPLEX PRODUCT THAT APPEARS
DAMAGED. Upon unpacking your Simplex product, inspect the contents of the
carton for shipping damage. If damage is apparent, immediately file a claim
with the carrier and notify Simplex.
ELECTRICAL HAZARD - Disconnect electrical power when making any
internal adjustments or repairs. Servicing should be performed by qualified
Simplex Representatives.
STATIC HAZARD - Static electricity can damage components. Therefore,
handle as follows:
1.
Ground yourself before opening or installing components (use the 553-484
Static Control Kit).
2.
Keep uninstalled component wrapped in anti-static material at all times.
The 4190-9006 Remote CRT/Keyboard provides a remote visual indication of
system events for the 2120 Multiplex System, 4010/4020 Fire Alarm Control
Panel (FACPs), and 4100+/4120 Fire Alarm System. The terminal also provides
for remote communication with each system's CPU.
The following topics are covered in this publication:
Topic
Connections
Cable Terminations
2120 Remote Terminal Connections
Terminal Configurations
Programming the 2120 Function Keys
4010 Front Panel Programming for an RS-232 Port
firealarmresources.com
4190-9006
Remote CRT/Keyboard
Installation Instructions
Page Number
2
3
5
6
9
10
574-830
Rev. B
Advertisement
Summary of Contents for Simplex 4190-9006
- Page 1 Cautions and Warnings DO NOT INSTALL ANY SIMPLEX PRODUCT THAT APPEARS DAMAGED. Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify Simplex.
- Page 2 Connections Connecting to a 2120, 4010, Follow Steps 1 through 3 to connect to a 2120, 4010, 4020, or 4100+/4120 4020, or 4100+/4120 System system. The DB-25F end of the 733-812 cable must be connected into the back of the CRT (as shown in Figure 1). Note: Use Tables 1 and 2 to terminate the loose ends of the 733-812 cable to a DB-25F connector.
-
Page 3: Cable Terminations
Cable Terminations 733-812 Cable Terminations Use the information in Tables 1 through 5 to connect the 4190-9006 Remote for 2120 Systems CRT/Keyboard. Table 1. Connecting to the RS-232 Port of a 2120 BMUX Wire Lead Connection Red lead (XMIT) Pin 2 of a DB-25F connector... - Page 4 Cable Terminations, Continued 733-812 Cable Terminations for 4010, 4020, and 4100+/4120 Systems Table 4. Connecting to the RS-232 Motherboard of a 4020, 4100+/4120 (continued) Wire Lead 4100+/4120 Connection 4020 Connection Red lead (XMIT) TB1-6 or TB2-3 TB1-1 or TB1-6 Black lead (RCV) TB1-8 or TB2-1 TB1-3 or TB1-8 White lead (CTS)
- Page 5 The 4010, 4020, and 4100+/4120 systems do not support a remote monitor. The Aux Port is capable of having ten 4190-9006 terminals connected to it as long as the wiring distance to any terminal does not exceed 2,500 feet and the total capacitive load of the circuit wiring does not exceed 1.25 mfd.
-
Page 6: Terminal Configurations
Terminal Configurations Configuring the Terminal Press the Setup Directory key <F3> to enter the terminal’s configuration mode. for 2120, 4010, 4020, and 4100+/4120 Systems Setup Directory <F3>: For <F1> through <F14> select menus, use arrow keys to select field. Press the Return key to change parameter. Quick Setup <F1>... - Page 7 Terminal Configurations, Continued Configuring the Terminal (Continued) Host Setup <F7> Keys Setup <F5> Command Specification Command Specification Enter Key <cr> Comm Mode Full Duplex Return Key <cr> Local Null Suppress Backspace <BS>/<DEL> Compose Key Compose Break 250 ms Disconnected Shift-F5 Modem Control ,,and..
- Page 8 Terminal Configurations, Continued Configuring the Terminal (Continued) Emul Setup <F9> Command Specification Numeric Kpd Numeric Cursor Kpd Cursor Send Data ANSI-ID VT320 Function Key Lock Feature Lock Char set National Status Line WP-Graphics Tabs Setup <F10> Command Specification Auto Init Tabs Default Tabs Ansbk Setup <F11>...
- Page 9 Programming the 2120 Function Keys Programming the 2120 To program the function keys of a 2120 Multiplex for the Acknowledge (ACK), Function Keys Signal Silence (SIG SIL), and Detector Reset (DET RST) commands, follow the steps below. IMPORTANT: These configurations are for the 2120 Multiplex function keys ONLY.
- Page 10 4010 Front Panel Programming for an RS-232 Port Introduction This section describes programming a printer port on a 4010 RS-232 card from the front panel of the 4010 FACP. Note: Login to the system at Access Level 4 before attempting to program the port.
- Page 11 4010 Front Panel Programming for an RS-232 Port, Continued Configuring RS-232 Port Press <NEXT> or <PREVIOUS> until <CONFIGURE CARDS> is Settings (continued) displayed and then press <ENTER>. Press <NEXT> or <PREVIOUS> until <MODIFY 4010 CARD> is displayed and then press <ENTER>. Press <NEXT>...
- Page 12 4010 Front Panel Programming for an RS-232 Port, Continued Configuring RS-232 Port 12. Choose which events are sent to the printer when they occur, as follows: Settings (continued) Send All Events to Printer. Press <ENTER> to send all of the events listed in Table 6 (below) to the printer.
