Supplied Equipment
• Sidekick Wi-Fi Router
• 12/24v - USB power adapter
• Micro USB power wire
(this connects to the
power input on the Sidekick)
• Ethernet Cable
• Optional - PRO version includes external antenna
Optional:
Sidekick PRO with External Antenna
Supplied Equipment testing
• Sidekick Wi-Fi Router
• 12/24v - USB power adapter
• Micro USB power wire
(this connects to the
power input on the Sidekick)
• Ethernet Cable
• Optional - PRO version includes external antenna
Optional:
Sidekick PRO with External Antenna
Supported Satellite Phones:
Iridium Certus, OpenPort / Pilot, 9500*, 9505*, 9505A*,
9555, 9575, including most docking stations
Inmarsat FleetOne, FleetBroadband, IsatPhone
Globalstar GSP-1700, GSP-1600* and 2900*
*Devices require additional Serial to USB adapters
Connections:
If you have the Sidekick PRO you will need to attach the
1.
included antenna before use.
2.
Connect the USB power cable between any USB power
source or the inculded power adapter and the "Power" port
Do not connect USB cable from the phone
on the Sidekick.
to the USB port on the unit at this time.
3.
The green Wireless light will come on when you power the
unit up. After a moment the red Ready light will illuminate
and be solid indicating the device is ready for use.
4.
Attach the USB cable from the satellite phone to the USB
port on the Sidekick. You will see the green USB light
illuminate if the device is recognized.
Supported Satellite Phones:
Iridium Certus, OpenPort / Pilot, 9500*, 9505*, 9505A*,
9555, 9575, including most docking stations
Inmarsat FleetOne, FleetBroadband, IsatPhone
Globalstar GSP-1700, GSP-1600* and 2900*
*Devices require additional Serial to USB adapters
Connections:
If you have the Sidekick PRO you will need to attach the
1.
included antenna before use.
2.
Connect the USB power cable between any USB power
source or the inculded power adapter and the "Power" port
Do not connect USB cable from the phone
on the Sidekick.
to the USB port on the unit at this time.
3.
The green Wireless light will come on when you power the
unit up. After a moment the red Ready light will illuminate
and be solid indicating the device is ready for use.
4.
Attach the USB cable from the satellite phone to the USB
port on the Sidekick. You will see the green USB light
illuminate if the device is recognized.
