PATIO HEATERS
ITM./ART.#: FOP-210021/ FOP-210022/ FOP-210023
FOP-210024/ FOP-210025/ FOP-210026
MODEL#: F210017-B2 / F210017-C3
F210017-D4 / F210017-E5
F210017-F6/ F210017-G7
CSA/ANSI Z83.26-2020 • CSA 2.37-2020
Gas-Fired Outdoor Infrared Patio Heater
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference
WARNING: For Outdoor Use Only.
Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
DANGER
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues,
and immediately call your gas supplier or fire
department.
DANGER
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the installation, operating, and maintenance instructions thoroughly
before installing or servicing this equipment.
keep away from the appliance
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
WARNING
Do not store or use gasoline, or other
flammable vapors and liquids, in the
vicinity of this or any other
appliance. An propane cylinder not
connected for use shall not be stored
in the vicinity of this or any other
appliance.
CARBON MONOXIDE HAZARD
01
Advertisement
Table of Contents
Related Manuals for patio F210017-B2
Summary of Contents for patio F210017-B2
- Page 1 PATIO HEATERS ITM./ART.#: FOP-210021/ FOP-210022/ FOP-210023 FOP-210024/ FOP-210025/ FOP-210026 MODEL#: F210017-B2 / F210017-C3 F210017-D4 / F210017-E5 F210017-F6/ F210017-G7 CSA/ANSI Z83.26-2020 • CSA 2.37-2020 Gas-Fired Outdoor Infrared Patio Heater INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference WARNING: For Outdoor Use Only.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable. -
Page 3: Specifications
IMPORTANT SAFETY INFORMATION (About Propane Gas) The propane gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Department of Transportation (D.O.T.) Specifications for propane Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable. -
Page 4: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Metal shield Glass fixture Wide glass Narrow glass Base Door Weather cover Foot glider (PRE-ASSEMBLED) -
Page 5: Safety Information
This manual contains important information about the assembly, operation and maintenance of this patio heater. General safety information is presented in these first few pages and is also located throughout the manual. Keep this manual for future reference and to educate new users of this product. - Page 6 SAFETY INFORMATION DANGER • CARBON MONOXIDE HAZARD. • This heater is a combustion appliance. All combustion appliances produce carbon monoxide (CO) during the combustion process. This product is designed to produce extremely minute, non-hazardous amounts of CO if used and maintained in accordance with all warnings and instructions.
-
Page 7: Burn Hazard
SAFETY INFORMATION WARNING WARNING BURN HAZARD Certain materials or items, when stored under • Never leave heater unattended when hot or in the heater, will be subjected to radiant heat and use. could be seriously damaged. • Keep out of reach of children. CAUTION SERVICE SAFETY •... - Page 8 ASSEMBLY INSTRUCTIONS 1. Side place the product base (E) on a non-abrasive flat Figure 2 surface to prevent scratching, unscrew the foot gliders (H) and remove from the base (E). Line up the hole on the ground fixer (DD) with the corresponding holes on the base (E), then insert the bolt on foot glider (H) into the holes and hand tighten them clockwise.
- Page 9 ASSEMBLY INSTRUCTIONS Figure 5 4. Cover and clamp the four narrow glass (D) with glass fixture (B) carefully. Afterwards, tighten the bolts (AA), but not tighten too much to avoid the glass pieces being damaged (See Figure 5). 5. Insert the four wide glass (C) into the "L" clips which Figure 6 have been welded together with table top, then attach them with bolts (AA) using the Phillips screwdriver...
- Page 10 ASSEMBLY INSTRUCTIONS 7. Place the gas cylinder into the cylinder holder. Secure Figure 8 the cylinder by tightening clockwise the retention point found on the cylinder holder, so that the cylinder cannot move from side to side or fall down. Connect the regulator, screw the black handle clockwise to tighten, turn the black handle counterclockwise to regulator...
- Page 11 OPERATION INSTRUCTIONS BATTERY Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery. BATTERY IS NOT INCLUDED. WARNING: 1.
-
Page 12: Lighting Instructions
OPERATION INSTRUCTIONS gas valve / regulator hose connection (Figure 13) inlet tube / bellows connection (Figure 14) To perform a leak test: 1. Make 2~3 oz. of leak solution by mixing one part liquid dishwasher detergent and three parts water. Noted: make sure control knob is “OFF”. 2. -
Page 13: Care And Maintenance
4. Carbon deposits may create a fire hazard. Clean burner with warm soapy water if any carbon deposits develop. 5. Cover your patio heater with an outdoor weather cover when not in use to protect it from the elements. NOTE: Always allow patio heater to cool COMPLETELY before you cover the patio heater with an... -
Page 14: Troubleshooting
Troubleshooting Problem Possible cuase Corrective action Wait until gas cylinder The gas cylinder is frosted over. warms up and becomes An opening is blocked. unfrosted. The burner The control knob is not in the Clear the blockage. will not ignite. “ON”... -
Page 15: Warranty
Failure caused by unreasonable or abusive use. Patio heater that were clearance items, display models or items purchased in an "as is" condition, freight damage, patio heater damaged by acts of nature, vandalism, fire, abuse, lack of proper care and maintenance, or improper assembly; straps and normal fading or discoloration from exposure to elements, oils, spills, fluids or chemicals;...
