Page 2
Dies ist die Anleitung zu sicherer Nutzung und korrektem Einbau von • Schauen Sie nicht in die LED-Module, wenn sie eingeschaltet sind - Lichtsteuerung und LEDs! Bitte lesen Sie diese Anleitung vollständig sie sind sehr hell und können Ihre Augen verletzen. durch, bevor Sie Ihre Beleuchtungsanlage montieren oder in Betrieb nehmen.
Page 3
• LED-Leistungsausgang: 5 V, 3 A MAX A n S c h L I E S S E n D E r L E D S • Abmessungen: 75 x 24 x 17 mm, Gewicht: 35 g • Alle Systeme werden vor dem Verpacken vollständig geprüft und Stromkabel Status LED getestet, um sicherzustellen, dass der Kunde ein voll funktionsfähi-...
Page 4
• Achtung: Lichtsteuerung erzeugt während des Betriebs Wärme, SchrItt 1 proportional zur Anzahl der Leuchten. Deshalb bei mehr als 9 LED- Bereiten Sie Ihren Sender vor Modulen (2,5A Gesamtlast) eine zusätzliche Kühlung der Lichtsteue- Während des Einrichtungsvorgangs lernt die Lichtsteuerung Signale rung, z.B.
Page 5
‚Anschluss der LEDs‘ beschrieben. Schließen Sie das Empfängerkabel 10. Schalten Sie alles aus. der Lichtsteuerung an den Empfänger an. 11. Testen Sie den Normalbetrieb mit Standard-Blitzmuster. 2. Schalten Sie die Lichtsterung oder den Empfänger noch nicht ein. 3. Drehen Sie den Drehregler leicht gegen den Uhrzeigersinn, bis er auf SchrItt 3 Position 1 - Lernmodus - steht.
Page 6
Hinweis: Sie können das Blitzmuster jederzeit ändern, wenn die Hinweis: Nachdem die Lichtsteuerung zurückgesetzt wurde und sich im- Lichtsteuerung in Betrieb ist. mer noch in Position 3 befindet, werden die LEDs ein Testmuster oder eine Dauerleistung ausstrahlen. Dies ist normal. Damit ist der gesamte Programmiervorgang abgeschlossen.
Page 7
B L I t Z M u S t E r-Vo r E I n S t E L Lu n g E n S A f E t y Programm Blitzer 1 Blitzer 2 hinweise It is your responsibility to ensure that you operate the light control and Langer Blitz Langer Blitz LED modules within the stated specifications.
Page 8
L I g h t c o n t r o L f E At u r E S the rubber grommets into the tabs and mount the tabs on each side of the housing, securing them with a small drop of super glue •...
Page 9
• Pins are compatible with conventional servo plugs • LED modules will only work if polarity is correct but will not be dama- ged if plugged in with reverse polarity for a short time. • To add additional LED modules, use “Y”-cable Ord.No. 20/460. •...
Page 10
1. Connect all LEDs to the light controller described above in ‘Connecting StEP 3 the LEDs’. Connect the light controller receiver cable to the receiver. Setting the flash pattern of the AcLs: 2. Do not power on the light controller or receiver yet. The light controller has 10 pre-set flash patterns to choose from.
PrE-SEt fLASh PAttErnS 2. Connect the light controller power. 3. Connect the receiver power. Program Strobe 1 Strobe 2 Notes 4. The lighting controller will flash 1x to indicate it has reset. Long flash Long flash 5. Disconnect or switch off the receiver power and move the control dial Double flash Double flash to position 1.
