w w w . l a r i u s . c o m

GHIBLI 10:1

PNEUMATIC

WASHING PUMP

LoW ANd MEdIUM PrESSUrE

WASH PUMPS

For INTENSIVE CLEANING

IN HAZArdoUS ENVIroNMENTS

USABLE WITH CoLd

or HoT WATEr UP To 90°

Trolley version Cod. 98690/1

Wall version Cod. 98691

drum Version 200L Cod. 96661/1

O Max 90°

Table of Contents

Need help?

Do you have a question about the GHIBLI 10:1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Larius GHIBLI 10:1

Page 1 . l a r i u s . c o m GHIBLI 10:1 PNEUMATIC WASHING PUMP LoW ANd MEdIUM PrESSUrE WASH PUMPS For INTENSIVE CLEANING IN HAZArdoUS ENVIroNMENTS USABLE WITH CoLd or HoT WATEr UP To 90°...
Page 2 This manual is to be considered as an English language translation of the original manual in Italian. The manufacturer shall bear no responsibility for any damages or inconveniences that may arise due to the incorrect translation of the instructions contained within the original manual in Italian. Due to a constant product improvement programme, the factory reserves the right to modify technical details mentioned in this manual without prior notice.
Page 3: Table Of Contents
WE ADVISE THE USE OF THIS EQUIPMENT ONLY BY PROFESSIONAL OPERATORS. ONLY USE THIS MACHINE FOR USAGE SPECIFICALLY MENTIONED IN THIS MANUAL. Thank you for choosing a LARIUS S.R.L. product. As well as the product purchased, you will receive a range of support services enabling you to achieve the results desired, quickly and professionally.
Page 4: Warnings
GHIBLI 10:1 PNEUMATIC WASHING PUMP WARNINGS A A A The table below provides the meaning of the symbols used in this manual in relation to using, earthing, operating, maintaining, and repairing of this equipment. • Read this operator’s manual carefully before using the equipment.
Page 5: Bworking Principle
GHIBLI 10:1 PNEUMATIC WASHING PUMP WORKING PRINCIPLE GHIBLI 10:1 PNEUMATIC WASHING PUMP is a low and medium transmitted through a connecting rod to the material pumping piston which allows to suck water. pressure pneumatic pump for professional use to be used for cleaning with water.
Page 6: Ctechnical Data
GHIBLI 10:1 PNEUMATIC WASHING PUMP TECHNICAL DATA GHIBLI 10:1 PNEUMATIC WASHING PUMP Feeding air pressure 7 bar Max water pressure 70 bar Feeding air inlet 1/2” BSPP Max delivery 12 l/min Material output 3/4" BSPP Max water temperature 90° Parts of the pump in contact with water...
Page 7 GHIBLI 10:1 PNEUMATIC WASHING PUMP Fig. 2D Pos. Description Pos. Description Trolley Drum Version 200L Lubrificant cap Wall version Pumping group Water inlet hose connection Wheel Water outlet hose connection www.larius.com REV. 02 - 06/2021 - Cod. 150186...
Page 8: Etransport And Unpacking
ENVIRONMENTAL REGULATIONS IN FORCE IN THE COUNTRY due to transportation. WHERE THE PLANT IS INSTALLED AND USED. In case of damage, call immediately LARIUS and the Shipping • KEEP YOUR WORK PLACE CLEAN AND TIDY. DISORDER Agent. All the notices about possible damage or anomalies must...
Page 9: Hgrounding
GHIBLI 10:1 PNEUMATIC WASHING PUMP • (IF PROVIDED) TIGHTEN AND CHECK ALL THE FITTINGS • Don’t place the pail on a non-conductive surface, such as FOR CONNECTION BETWEEN PUMP, FLEXIBLE HOSE AND paper or cardboard, which interrups grounding continuity SPRAY GUN BEFORE USING THE EQUIPMENT.
Page 10: Jsetting Up And Connection
GHIBLI 10:1 PNEUMATIC WASHING PUMP TUNING AND TYPES OF INSTALLATION CONNECTIONS WALL MOUNTING • Ensure that the wall on which you intend to install the pump is suitable to support the weight of the pump and accessories Install at the pump inlet an air pressure regulator...
Page 11: Lcleaning At The End Of The Work
GHIBLI 10:1 PNEUMATIC WASHING PUMP CLEANING AT THE END OF THE WORK • Close the water supply (L1) • Drain the water from the pumping circuit by pressing the spraying nozzle (L2) • Shut off the compressed air supply to the pump (L3) •...
Page 12: Ntroubleshooting
GHIBLI 10:1 PNEUMATIC WASHING PUMP TROUBLESHOOTING Problem Possible cause Solution The pump does not start Feeding air is not enough Check the air supply. Increase the diameter of the feeding hose Outlet water line clogged Clean. Disconnect the outlet liquid pipe.
Page 13: Omanual Reset Of The Pneumatic Motor
GHIBLI 10:1 PNEUMATIC WASHING PUMP MANUAL RESET OF THE Immediately replace the plug with a usual M8 nut PNEUMATIC MOTOR before the guide rod slides into the cylinder (see illustration below). • The feed air pressure of the pump must never be higher than •...
Page 14: Qdisassembly Of The Suction Valve
GHIBLI 10:1 PNEUMATIC WASHING PUMP DISASSEMBLY OF THE • Check the condition of every part of the motor. SUCTION VALVE • For any replacement of the screws (P5) of the crosspiece (P6), for their reassembly and correct adjustment see the drawing below and the exploded view on page 16.
Page 15: Rreplacement Of The Lower Gaskets
GHIBLI 10:1 PNEUMATIC WASHING PUMP REPLACEMENT OF THE • Carefully screw again the fluid cylinder (it is suggested to lay a slight film of vaseline grease on the internal walls of the fluid LOWER GASKETS cylinder). Close the compressed air supply to the pump and release the residual pressure in the plant.
Page 16 GHIBLI 10:1 PNEUMATIC WASHING PUMP Fig. 1S • Extract the piston rod from the housing. • Unscrew the packing nut (S4) (use a metal rod with an internal diameter of 6 mm). • Remove the gaskets and packing glands. • For the correct reassembling of the gaskets see the illustration below and the exploded view on page 18.
Page 18: Tspare Parts - Complete Pneumatic Motor
GHIBLI 10:1 PNEUMATIC WASHING PUMP SPARE PARTS - COMPLETE PNEUMATIC MOTOR WARNING: always indicate code and quantity for every part required. 40050 40401 DrUM VErSION VERSIONE FUSTI 40052 www.larius.com REV. 02 - 06/2021 - Cod. 150186...
Page 19 GHIBLI 10:1 PNEUMATIC WASHING PUMP Pos. Code Descripcion Q. ty Pos. Code Descripcion Q. ty 96663 Complete motor - trolley version 96013 Motor piston 96663/1 Complete motor - wall version 96027 Complete valve screw 96669 Complete motor - drum version...
Page 20: Uspare Parts - Complete Pumping Group Split Stainless Steel
GHIBLI 10:1 PNEUMATIC WASHING PUMP COMPLETE PUMPING GROUP - SPLIT ST. STEEL SPARE PARTS - WARNING: always indicate code and quantity for every part required. CILINDRO CILINDRO SHOrT FLUID LONG FLUID CORTO LUNGO CyLINDEr CyLINDEr 16 A 16 B TIRANTE...
Page 21 GHIBLI 10:1 PNEUMATIC WASHING PUMP Pos. Code Descripcion Q. ty Pos. Code Descripcion Q. ty 95021 Ball Ø 7/8" Short - pumping group - 98051/3 trolley/wall version 98006 Washer 3805 Split pin - Trolley/wall version Long- pumping group - 98050/1...
Page 22: Vspare Parts - Complete Trolley
GHIBLI 10:1 PNEUMATIC WASHING PUMP SPARE PARTS - COMPLETE TROLLEY WARNING: Always indicate code and quantity for each part required. Pos. Code Description Q.ty Pos. Code Description Q.ty 96320/3 Complete trolley 91023 Wheel 16272/2 Trolley 91026 16271/2 Trolley handle 8029...
Page 23: Wspare Parts - Air Group - Trolley Version
GHIBLI 10:1 PNEUMATIC WASHING PUMP SPARE PARTS - AIR GROUP - TROLLEY VERSION WARNING: Always indicate code and quantity for each part required. Pos. Code Description Q.ty Pos. Code Description Q.ty 96250 Air group complete 96215 Quick coupling 1a+1b 91107...
Page 24: Xspare Parts - Air Group - Wall Version
Suction tube for tank 1000 lt with fitting BSPP 1" ATEX CERTIFICATION These safety instructions refer to the installation, use and maintenance of LArIUS GHIBLI series pneumatic piston transfer pumps in high risk environments where potentially explosive gasses or vapours are present.
Page 25 GHIBLI 10:1 PNEUMATIC WASHING PUMP MARKINGS II 2 G c IIB T6 : -20°C ÷ + 60°C fluid: 90°C Tech. File: GHIBLI/ATX/08 max. II = Group II (surfaces) Category 2 (zone 1) Explosive atmosphere containing gasses, vapours or mists Design safety “c”...
Page 26 GHIBLI 10:1 PNEUMATIC WASHING PUMP www.larius.com REV. 02 - 06/2021 - Cod. 150186...
Page 27: Declaration Of Conformity
GHIBLI 10:1 PNEUMATIC WASHING PUMP CE DECLARATION OF CONFORMITY Company LARIUS srl Via Antonio Stoppani 21 - 23801 Calolziocorte (LC) ITALY Tel: +39 0341 621152 Fax: +39 0341 621243 E-mail: larius@larius.com Declares under his owns resonsibility that the product: GHIBLI 10:1 PNEUMATIC WASHING PUMP...
Page 28 LARIUS srl Via Antonio Stoppani 21 - 23801 Calolziocorte (LC) ITALY TEL. +39 0341 621152 - Fax +39 0341 621243 - larius@larius.com www.larius.com...
