- Page 39 We are pleased that you have chosen the AsCARD A4 electro- cardiograph;...
- Page 40 The electrocardiograph AsCARD A4 is a high quality unit, three, six and twelve channels ECG unit which enables to make electrocardiogram in full 12 leads. The ECG unit maintenance is very simple and the modern keyboard makes the operation much easier.
- Page 42 AsCARD A4 Parameter Model A Model B Model C Model D Dimensions: (LxW xH) 310x230x66 310x230x66 310x230x66 310x230x66 [mm] W eight : ca [kg] 230 V ± 10% 230 V ± 10% 230 V ± 10% 230 V ± 10% Power supply 50 Hz ±...
- Page 43 Authorised Service only Attention ! The electrocardiograph AsCARD A4 is the unit belonging to the A class. If used in households the unit may cause radio-waves disturbance. If the disturbance occurs the user may be forced to take precautions and bear responsibility for them.
- Page 47 Technical Specification of ECG paper: - Kind of paper thermoactive, free of wax - Kind and colour of overprint millimetre net, orange - Width of paper 112 mm ± 1 mm - Diameter of a roll of paper 45 mm ± 1 mm - External diameter of the paper shaft 16 mm ±...
- Page 48 Note ! The producer of electrocardiographs do not take the responsibility for any defects caused by using the other kind of paper.
- Page 68 Basic Technical Parameters. Manufacturer and Representative. Version of the unit. WORKING CONDITIONS. FEATURES. How to prepare AsCARD A4 to work. How to put ECG paper roll to the unit. The arrangement of the keys. The arrangement of electrodes. EXAMINATION PERFORMANCE.
