Face Recognition Terminal BA8200 Series

User Manual

Table of Contents

Need help?

Do you have a question about the BA8200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Aratek BA8200 Series

Page 1 Face Recognition Terminal BA8200 Series User Manual...
Page 2 Thank you for purchasing Aratek product. In order to ensure that this product is used safely. Please read this User Manual carefully before using the product. It also will help product to improve product life and have excellent performance. By reading the User manual, you can understand the performance...
Page 3: Table Of Contents
Catalog 1、Tips………………………………………………………………………………………………………………………………………2 2、Warning……………………………………………………………………………………………………………………………… 2 3、Product Overview………………………………………………………………………………………………………………3 4、Features………………………………………………………………………………………………………………………………4 5、Illustration……………………………………………………………………………………………………………………………6 6、Installation …………………………………………………………………………………………………………………………9 7、Parameter…………………………………………………………………………………………………………………………11 8、Maintenance………………………………………………………………………………………………………………………15 9、Description of the name and content of toxic and hazardous substances…………………………16...
Page 4: 1、Tips
1、Tips This manual is only for reference and do not have any commitment. The product appearance and function should be based on the actual object. We reserve the right to modify any information in this document at any time. The content of the modification will be added to the new version of this document.
Page 5: 3、Product Overview
3、Product Overview The smart device terminal BA8200 face recognition access control is develop by Aratek, which integrates face recognition, fingerprint recognition and access control solution together. It’s equipped with a high dynamic range camera which can support live facial recognition powered by Aratek algorithm. The Aratek facial recognition algorithm can realizes 1:1 or 1:N online or offline verification.
Page 6: 4、Features
4、Features Aratek Face Recognition Algorithms: The BA8200 has patent face recognition algorithm that the recognition rat is 99.72% in international face database LFW. Live detection: Support live detection, can detects photo, video or 3D models which are not live characters.
Page 7 2M Dual HDR cameras: Allows clear facial image capture under strong or against the light to match against the photo on the citizen ID card. Black list: Connects with the police database to monitor, detect and report any entry of blacklisted persons.
Page 8: 5、Illustration
5、Illustration 5.1 Pictures （Access Control）（Access Control With Turnstile）...
Page 9 5.2 Component Number Name Function Fill-in Light Dual HDR cameras Face Acquisition Screen 8” IPS touch screen Microphone Microphone Reset button Initialization Speaker Speaker IC Card Reader USB * 2 Vertical bracket Vertical bracket...
Page 10 5.3 Interface RJ 45 D2（5V） D1（5V） Adaptor URAT TTL VCC （5V） Relay Relay URAT TTL...
Page 11: 6、Installation
6.Installation 6.1 Access Control (1) Remove the bracket: Slide the bracket down and take it out. (2)Install bracket: Fix the bracket to the wall. (3)Connect the power, wire, access control relay. (4)fix the back chute of the equipment on the bracket, tighten the bottom screw, and fix the BA8200.
Page 12 6.2 Access Control With Turnstile (1) Drilling Open a hole with a 32mm diameter near the entrance or middle of the turnstile for installing the BA8200. (See the position shown on the right ⊕) (2) Installing a.Unscrew the bottom nut of the equipment bracket. b.Pass the column and cable through the hole.
Page 13: 7、Parameter
7、Parameter Physical Parameter Android 7.1 Quad core ARM CPU + ARM Mali-T76x GPU Frequency 1.8GHz Display 8” IPS touch screen Resolution 800*1280 2G（option: 4G） 8G（can support up to 64G） TF card Maximum support 128G 148*268.5*33.5(Wall-mounted) Dimension 148*377.8*95.5(Gate type)
Page 14 Facial Recognition 1080P Dual HDR Camera with fill light, Camera 105dB wide dynamic Distance 0.3-1.5m Accuracy ≥99% Response time ≤1s Live detection Support Stranger detection Support Fake face alarm Support...
Page 15 Fingerprint recognition Fingerprint Capture Optical Press Platen size 47.5*26.5*15.5 mm Sensing Area 16*22 mm image size 256*360pixel image resolution 500dpi Gray Scale 256 level...
Page 16 Other WiFi 802.11b/g/n (option to 802.11a/b/g/n ) Bluetooth Bluetooth 4.0 Interface Relay；RJ45；RS232；WG；Ethernet; USB Adaptor 12V/3A Lighting Comply with IEC 62471、IEC60825-1 Working humidity 5%~95% Working Temperature -10℃ ~50℃ Gate type installation or Wall-mounted Installation installation...
Page 17: 8、Maintenance
8、Maintenance To ensure your safe and efficient use of this product, please read the following precautions first: (1)Do not store equipment in overheated places. High temperatures shorten the life of electronic devices, deform or melt some plastic parts. (2)Do not store the equipment in an overcooled place. When the equipment temperature rises to normal temperature, moisture will form inside and destroy the circuit board.
Page 18: 9、Description Of The Name And Content Of Toxic And Hazardous Substances
9、Description of the name and content of toxic and hazardous substances Harmful substances or elements Name PBDE ○ ○ ○ ○ ○ ○ Shell × ○ ○ ○ ○ ○ Mainboard ○ ○ ○ ○ ○ ○ Screen ○ ○ ○...
Page 19 FCC Statement • 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • (1) This device may not cause harmful interference. • (2) This device must accept any interference received, including interference that may cause undesired operation. •...
