- Page 1 MMstR75x stR75xFR stR75x stR75x User’s Manual REV 1.1 Many ideas one solution...
-
Page 2: Table Of Contents
CONTENTS 1. 1. 1. 1. Introduction Introduction Introduction Introduction ............................3 Features ..............................3 2. 2. 2. 2. The Module The Module The Module The Module ............................4 Block Diagram ............................. 4 Terminal Layout ..........................5 STR75xFR Microcontroller ......................6 Serial Flash Memory ......................... -
Page 3: Introduction Introduction
ARM microcontrollers, by eliminating the need to design the printed board. The module is supplied with example software. The MMstr75xFR minimodule can be also used in didactic laboratories of informatics colleges and universities, and can be also used to build circuits realizing thesis projects. -
Page 4: The Module The Module
Block Diagram Block Diagram Block Diagram A block diagram of MMstr75xFR minimodule is shown on the image below: Figure 1Block Diagram of MMstr75xFR Minimodule Minimodule can be ordered in different configurations with use of selector: MMstr75xFR – f – d Flash Memory size: 0 –... -
Page 5: Terminal Layout
Terminal Layout Terminal Layout Terminal Layout Terminal Layout Figure 2 Terminals Layout – top view Main Main Alternate Function Alternate Function Function Function P0.0/BOOT0 TIM0_OC1 P0.29 TIM1_TI1 / ADC_IN8 P0.28 3.3V TIM1_OC1 UART1_TX (remappable P0.21 to P0.15) UART1_RX (remappable P0.20 to P0.14) USART1_RTS / CANTX P1.19... -
Page 6: Str75Xfr Microcontroller
STR75xFR STR75xFR Microcontroller Microcontroller STR75xFR STR75xFR Microcontroller Microcontroller • 32-bit ARM7TDMI-S core • 60 MHz, 54 DMIPS • From 64 to 256kB in system programmable flash memory • 16kB data flash memory • 16kB SRAM memory • 3 synchronizable timers each with up to 2 input captures and 2 output compare/PWMs •... -
Page 7: Reset Circuit
RESET circuit RESET circuit The MMstr75xFR has a built-in voltage monitoring circuit built around the DS1818 integrated circuit. The circuit generates a RESET signal in case when the supply voltage value is lower than 3V. This takes place when the supply voltage is switched on or off, when the VCC voltage changes its value from 0 to 3.3 V. -
Page 8: Voltage Regulator
Up circuit USB host recognize presence of device on the bus by sensing pull-up on D+ line. MMstr75xFR has built-in pull-up circuit, shown on drawing below. Figure 6 USB D+ Pull-Up circuit implementation Pull-up is by default turned off by R4 resistor. Active reset signal or low level on UDP_PUP (R5 mounted) line turns on pull-up, what is interpreted by USB host as connection of USB device. -
Page 9: Jtag Connection
The method of connecting the JTAG connector to the minimodule is shown in the drawing: Figure 7 JTAG connection on module JTAG programmer/debugger may be found on page: ARM cable I http://www.propox.com/products/t_122.html... -
Page 10: Evaluation Board Evaluation Board
3. 3. 3. 3. Evaluation Board Evaluation Board Evaluation Board Evaluation Board EVBmm™ EVBmm™ EVBmm™ EVBmm™... -
Page 11: Specifications Specifications
Guarantee Guarantee Guarantee The MMstr75xFR minimodule is covered by a six-month guarantee. All faults and defects not caused by the user will be removed at the Producer’s cost. Transportation costs are borne by the buyer. The Producer takes no responsibility for any damage and defects caused in the course of... -
Page 12: Assembly Drawings Assembly Drawings
7. 7. 7. 7. Assembly Assembly Assembly Assembly Drawings Drawings Drawings Drawings Figure 8 TOP Figure 9 BOTTOM... -
Page 13: Dimensions Dimensions
8. 8. 8. 8. Dimensions Dimensions Dimensions Dimensions Figure 10 Top View Figure 11 Side View 9. 9. 9. 9. Schematic Schematic Schematic Schematic...
