Safety – Operation – Maintenance
Keep this document in a safe place
Read and understand this manual before operating your air tool
Tent & Vent
High Flow NESHAP Filtration System
Models: TV-1400
• Designed for the collection of wet paint overspray containing Hexavalent Chromium or other heavy metals
Scan this QR code for
online instructions and
documentation, or visit
www.ClaytonHowTo.com
WARNING
SAFETY LEGEND
Read and understand operator's manual before
using this equipment.
Hearing protection is recommended when
operating this equipment.
• The proper NESHAP Filters from Clayton Associates must be installed in the TV-1400 at all times..
• The TV-1400 must be used with the supplied or recommended accessories from Clayton Associates.
• Any alteration to the TV-1400 by a third party will nullify its warranty.
• Always lock the brakes on the TV-1400 once positioned so that it does not roll.
TV-1400
WARNING
WARNING
TV-1400_cover
WARNING
Eye protection is required when operating this
equipment.
WARNING
Respiratory protection is recommended
operating this equipment.
March 22, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tent & Vent TV-1400 and is the answer not in the manual?

Questions and answers

Related Manuals for Clayton Tent & Vent TV-1400

Summary of Contents for Clayton Tent & Vent TV-1400

  • Page 1 • The proper NESHAP Filters from Clayton Associates must be installed in the TV-1400 at all times.. • The TV-1400 must be used with the supplied or recommended accessories from Clayton Associates. • Any alteration to the TV-1400 by a third party will nullify its warranty.

  • Page 2: Table Of Contents

    Change the Inlet Baffle ......................14 Change Filters ........................15 Illustrated Parts Breakdown....................17 Limited Lifetime Warranty Terms And Conditions ..............22 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com...

  • Page 3: Applications & Environments

    NESHAP Test Method 319 for Aerospace painting and de-painting operations. The TV-1400 employs a specific set of Clayton filters that, when used together, provide filtration that passes the NESHAP Test Method 319 for both liquid and solid phase particulate.

  • Page 4: Specifications & Requirements

    Tools And Attachments The TV-1400 is only NESHAP compliant when used with the proper filters and accessories provided by Clayton. Proper order and orientation of the filters is required. Any alteration to this equipment by a third party will nullify its warranty.

  • Page 5: What's In The Box

    WHAT’S IN THE BOX The Clayton Tent & Vent was shipped with the items shown stored in the lower drawer. GL_006 TV-1400_001 TV-1400_007 Ground Hardware Cable TV-1400 Filter Unit TV-1400_002 TV-1400_003 TV-1400_005 TV-1400_006 TV-1400_004 Inlet Flange 12” Muffler 18” Inlet Extension...

  • Page 6: Consumables

    TV-1400_013 • 955-TVC5225 Ducting Cart The Ducting Cart provides storage for four sections of flexible ducting. TV-1400_014 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com...
  • Page 7 TV-1400_011 TV-1400_009 Carbon Filter NESHAP NESHAP NESHAP Pocket Filter Stage 2 Filter Stage 1 Filter Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 7...

  • Page 8: Getting Started

    • Using the six (6) sets of hardware provided, attach the inlet flange to the inlet opening. Bolt Bolt (x6) (x6) Washer (x6) (x6) TV-1400_022 TV-1400_023 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 8...
  • Page 9 • Using the 7 inch band clamp provided, attach the exhaust cap to the lower exhaust flange. 7” Band Clamp Exhaust Cap Exhaust Flange TV-1400_025 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 9...

  • Page 10: Before Each Use

    • Use the 8 inch band clamp from the cap to attach the 18 inch inlet extension to the upper inlet flange. 8” Band Clamp Inlet Flange TV-1400_027 Inlet Extension Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 10...
  • Page 11 • Clamp to either the work piece or the same grounding point as the work piece. Grounding Jack TV-1400_029 Grounding Cable Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com...
  • Page 12 • Refer to “Change Filters” on page 15 for complete information. Differential TV-1400_032 Pressure Gauge TV-1400_031 Compressed Air Valve Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 12...
  • Page 13 • Turn the compressed air valve to the ON position to activate the TV-1400. Compressed Air Valve TV-1400_034 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com...

  • Page 14: Change The Inlet Baffle

    • Thread new or existing 10-32 lock nuts onto the PEM studs. • DO NOT OVERTIGHTEN. Inlet Baffle Nuts (x4) TV-1400_035 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 14...

  • Page 15: Change Filters

    Filter Part Number Label NESHAP Carbon Filter Stage 2 Filter Multi-Pocket Filter Air Exit Side TV-1400_035 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 15...
  • Page 16 Lift Cover Straight Up NESHAP Stage 1 Filter Cover Latches (2 of 8) TV-1400_037 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 16...

  • Page 17: Illustrated Parts Breakdown

    Handle Tube Black Alminum NE20181623-HNSZ Nut 5/16-18 Nylon Lock Tall SS TV-1400-3 Tent Vent Lid TV-1400_038 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 17...
  • Page 18 Ducting Flange Galv 7In X 3.625In 921-7000G-S12 Duct Rolled Lip Galv 7In Dia X 12In Len TV-1400_039 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com...
  • Page 19 Ducting Flange Galv 8In X 3.625In 921-8000G-S18 Duct Rolled Lip Galv 8In Dia X 18In Len TV-1400_040 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com...
  • Page 20 FTG, Plug, 1/2 In MNPT 921-7000G-S12 Duct Rolled Lip Galv 7In Dia X 12In Len 945-HSEC08X3BK Heat Shrink End 1/2In TV-1400_041 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com...
  • Page 21 Tent Vent Filter Box TV-1400-4 Tent Vent Diverter WE112402-RFS-Z Washer .172ID x .375OD .031H Round Stainless TV-1400_042 Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 TV-1400 www.DustlessMadeSimple.com • Sales@JClayton.com Page 21...

  • Page 22: Limited Lifetime Warranty Terms And Conditions

    Repair within the Continental US During the first 90 days of the warranty period, Clayton will provide parts and labor to the customer’s site at no charge or pay freight costs associated with returning the products for repair to a Clayton selected service location and repair the product at no charge. Clayton personnel will determine the best way to repair the product.
  • Page 23 EC DECLARATION OF CONFORMITY Clayton Associates, Inc. of 1650 Oak Street, Lakewood New Jersey 08701 U.S.A. declare on our own responsibility that the following equipment: Industrial Pneumatically Powered NESHAP Filtration System and Accessories • Vacuum Models: TV-1400 • With serial numbers ranging from TV0000001 through TV9999999...
  • Page 24 Clayton products are proudly made in the USA Repair or Warranty Contact Clayton Associates, Inc. • 1650 Oak Street • Lakewood, New Jersey 08701 • P.+1-732-363-2100 F.+1-732-364-6084 www.DustlessMadeSimple.com • Sales@JClayton.com...
