Summary of Contents for Honest UF-40 Series
- Page 1 W A T E R F I L T R A T I O N S O L U T I O N S ULTRAFI LT RAT I O N S Y S T E MS (U F -40 SE RI E S ) OWN ER 'S M A N U A L...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Owner Information ......... 2 Inlet Water Plumbing ......13 General ..........2 Bypass Installation ......14 Technical Assistance ......2 Starting the Controller ......14 Important Safety information ....3 Rinsing the Ultrafilter......14 Warranty Information ......4 Sanitizing the System And Lines.. -
Page 3: Important Safety Information
OWNER INFORMATION (CONT.) IMPORTANT SAFETY INFORMATION • Do NOT allow the trans membrane pressure to exceed 45 psi (310 kPa). Trans membrane • Review the owner's manual prior to using the pressure is the pressure differential (delta) from water filtration system. the influent side of the membrane wall to the •... -
Page 4: Warranty Information
WARRANTY INFORMATION be invalidated by any abuse, misuse, misapplica- tion, improper installation or improper mainte- All Honest Water Filter products are constructed of the nance or alteration of the product. finest materials available and manufactured to high qual-ty standards. Complete Filtration Systems &... - Page 5 OWNER INFORMATION (CONT.) d. Send such notification together with the defec- tive Product to: Honest Water Filter Company. 5313 Crescent Edge Drive, Prescott, AZ U.S.A. (858) 842-4224 (Customer Service) THIS WARRANTY GIVES YOU SPECIFIC LE- GAL RIGHTS AND YOU MAY ALSO HAVE OTHER...
-
Page 6: System Specifications
SYSTEM SPECIFICATIONS REVISIONS REV. DESCRIPTION DATE DRAWN BY APPROVED PRE-RELEASE 6/23/20 7.47 7.47 UPDATED NOMENCLATURE IN BOM/TITLE BLOCK 7/7/2020 18.26 4X 1.000 CHANGED ORIENTATION OF ITEMS 15 & 16 7/15/2020 4X 1.000 13.04 ADDED DRAIN VALVE TO BOTH THE UF AND POST FILTER 7/29/2020 27.41 37.34 27.41... - Page 7 SYSTEM SPECIFICATIONS (CONTINUED) REVISIONS REV. DESCRIPTION DATE DRAWN BY APPROVED 8.07 PRE-RELEASE 6/24/20 13.04 4X 1.59 UPDATED NOMENCLATURE TO BOM/TITLE BLOCK 7/8/2020 CHANGED ORIENTATION OF ITEMS 20 & 21 7/17/2020 ADDED DRAIN VALVE TO UF AND POST FILTER 8/20/2020 40.02 27.41 UNLESS OTHERWISE SPECIFIED: NAME...
- Page 8 SYSTEM SPECIFICATIONS (CONTINUED) Peak UF Membrane Model Number of UF Number of Type of Flow Rate Membranes Post Filters Post Filer Diameter Length (gpm) UF-4210-0000X 4" 20" UF-4211-4925X 4" 20" 4925X UF-4211-4925P 4" 20" 4925P UF-4211-4933X 4" 20" 4933X UF-4211-4933P 4"...
- Page 9 SYSTEM SPECIFICATIONS (CONTINUED) UF Membrane Peak Model Number of UF Number of Type of Flow Rate Membranes Post Filters Post Filer Diameter Length (gpm) UF-4421-4933X 4" 40" 4933X UF-4421-4933P 4" 40" 4933P UF-4422-4925X 4" 40" 4925X UF-4422-4925P 4" 40" 4925P UF-4422-4933X 4"...
-
Page 10: Cartridge Specifications & Performance Data
CARTRIDGE SPECIFICATIONS & PERFORMANCE DATA Model Item Micron Flow NSF Std. NSF Std. Scale Capacity Dia. Rating Rate Inhibitor HWF-4925XHC 105298 265,000 Chlorine 4-1/2" 20" HWF-4925PHC 105299 265,000 Chlorine 4-1/2" 20" HWF-4933X 105284 60,000 Chloramines 4-1/2" 20" HWF-4933P 105285 60,000 Chloramines 4-1/2"... -
Page 11: Installation
INSTALLATION ELECTRICAL The line voltage must match the voltage on the specification label. The plug on the power cord must match the appropriate outlet. Do NOT connect the system to a switched electrical outlet. PLUMBING Wall System Only connect the system to the cold water line. Do NOT connect it to the hot water line. -
Page 12: Drain Valve Connection
INSTALLATION (CONTINUED) DRAIN VALVE CONNECTION The drain valve (solenoid valve) is used to flush buildup of particles from the system during self- cleaning. To properly install the drain valve connec- tion: 1. Cut tubing (not supplied) so that it is able to reach the drain from the drain valve. -
Page 13: Ultrafilter Rinse Valve Connection
INSTALLATION (CONTINUED) ULTRAFILTER RINSE VALVE CONNECTION Insert supplied tubing into ball valve prior to rinsing the membrane. SYSTEM INLET CONNECTION Outlet Inlet (Upper) The inlet connection on your water filtration sys- (Lower) tem has a 3/4" NPT male thread. Be sure to NOT overtighten the fittings, which could cause damage to the fittings. -
Page 14: Bypass Installation
INSTALLATION (CONTINUED) BYPASS INSTALLATION 6. Press the FL button to open the drain valve. Air and water will come out of the drain line. Installing an optional bypass on the system is recommended as it will help with cartridge replace- 7. -
Page 15: Sanitizing The System And Lines
INSTALLATION (CONTINUED) SANITIZING THE SYSTEM AND LINES 10. After 15 minutes, open the faucet or tap. (IF SANITATION T IS INSTALLED IN FRONT OF 11. Allow water to flow until the presence of sani- THE INLET CONNECTION) tizer is gone. Sanitizing the plumbing to eliminate any possible 12. -
Page 16: Operation
OPERATION OVERVIEW The system features two modes: Normal Operation Mode and Flush Mode. In Normal Operation Mode, water enters the inlet and flows into the filter and then out the Permeate Outlet as usable water. In Flush Mode, water enters the Inlet and cleans the ultrafilter by removing any debris from the mem- brane wall. -
Page 17: Maintenance
MAINTENANCE REPLACING THE ULTRAFILTER 14. After rinsing, open the outlet valve and inlet valve to repressurize the system. NOTE: Always install new Carbon Cartridge after re- placing the Ultra Filter Cartridge. REPLACING THE CARBON CARTRIDGE 1. Close the incoming water valve and outlet valve. 1. -
Page 18: Controller
MAINTENANCE (CONTINUED) CONTROLLER The controller on the UF system directs the interval timing and duration when the system flushes. When the system flushes, the controller will display "FLU" and then count down the duration of the flush. The settings of the flush interval can be changed, though it is recommended to leave them at the de- fault setting of flushing for 10 seconds every hour. -
Page 19: Replacement Parts
REPLACEMENT PARTS ITEM PART NUMBER DESCRIPTION QTY. 306085 HEAD/MANIFOLD, FLG B, 3/4 INCH NPT W/O-RINGS 306089 UNION, MEMBRANE W/O-RINGS 105065 MODULE, UF, MULTIBORE, 20 INCH 305512 VESSEL, PRESSURE, 20 INCH, SS T304 306037 FITTING, 3/4 INCH MNPT+PR W/O-RINGS 306038 FITTING, PLUG+PR W/O-RINGS 502806 FLOW CONTROL, 8 GPM, YELLOW 306040... - Page 20 REPLACEMENT PARTS (CONT.) ITEM PART NUMBER DESCRIPTION QTY. 306085 HEAD/MANIFOLD, FLG B, 3/4 INCH NPT W/O-RINGS 306089 UNION, MEMBRANE W/O-RINGS 105083 MODULE, UF, MULTIBORE, 40 INCH 305510 VESSEL, PRESSURE, 40 INCH, SS T304 306037 FITTING, 3/4 INCH MNPT+PR W/O-RINGS 306038 FITTING, PLUG+PR W/O-RINGS 502809 FLOW CONTROL, 15 GPM, YELLOW...
- Page 21 REPLACEMENT PARTS (CONT.) ITEM PART DESCRIPTION QTY. NUMBER 306073 UNIVERSAL MOUNTING BRACKET 501233 1/4-20 UNC X .219 L HEX NUT, ZINK PLATED 501234 1/4-20 X .50 L SHCS, BLK OXIDE HEAD/MANIFOLD, FLANGE A, 3/4 INCH NPT 306099 W/O-RINGS 306089 UNION, MEMBRANE W/O-RINGS 105065 MODULE, UF, MULTIBORE, 20 INCH 305512...
-
Page 22: Notes
NOTES Rev. 8 10/20... - Page 23 NOTES Rev. 8 10/20...
