OWNER'S MANUAL
MODELS: EST5868 | EST5870 | EST5880
INFLATABLE SPA
INSIDE & OUTSIDE
Well-being and relaxation at home
DO NOT RETURN THIS ITEM TO THE STORE
OR WEBSITE WHERE IT WAS PURCHASED.
CONTACT US DIRECTLY WITH ANY
QUESTIONS, OR FOR DEFECTIVE OR
WARRANTY CLAIMS. CALL US DIRECTLY
855-426-7727 • 855-H2O-SPAS
STOP
FOR IMMEDIATE HELP!
Advertisement
Table of Contents
Summary of Contents for Therapure EST5868
- Page 1 OWNER’S MANUAL MODELS: EST5868 | EST5870 | EST5880 INFLATABLE SPA INSIDE & OUTSIDE Well-being and relaxation at home STOP DO NOT RETURN THIS ITEM TO THE STORE OR WEBSITE WHERE IT WAS PURCHASED. CONTACT US DIRECTLY WITH ANY QUESTIONS, OR FOR DEFECTIVE OR WARRANTY CLAIMS.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS The following instructions are required to be printed by Underwriters Laboratory (U.L.) as well as ETL Testing Laboratories Inc. as a condition of their listing of this product. They contain important safety information and we strongly encourage you to read and apply them. - Page 3 WARNING: Do not switch on the spa if there is any possibility that the water in the spa is frozen. WARNING: Use only approved accessories. Use of non-approved accessories could void the warranty. DANGER: Risk of Accidental Drowning. Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use this spa unless they are supervised at all times.
- Page 4 SPECIFICATIONS Models: EST5868 | EST5870 | EST5880 Seating capacity: Up to 4 Adults (EST5868 / EST5880) | Up to 2 Adults (EST5870) Water capacity: 800L / 211gallons (EST5868 / EST5880) | 500L / 150 gallons (EST5870) Outer diameter: 1.85m / 73”...
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS PACKAGE CONTENTS: Verify that all parts are present: A. Spa pool B. Spa cover C. Inflation hose D. Filter cartridge (2) E. Filter cartridge cover (1) F. Rubber plug G. Repair kit H: Cover lock... -
Page 6: Site Requirements
SITE REQUIREMENTS: • The floor must be capable of supporting the total expected load (filled spa plus bathers). Total filled weight of spa is approximately 1800 lbs. • An adequate drainage system must be provided to deal with overflow water. •... - Page 7 WARNING: Do not use the spa if the above test fails. B. Open the air outlet on the spa. Screw one end of the inflation hose onto it. C. Open the air valve on the spa. Connect the other end of inflation hose into the valve. As previously outlined under the GFCI Test section, test the spa’s GFCI plug.
- Page 8 E. Remove the inflation hose from the air valve and replace valve cap tightly. F. Insert one filter cartridge into the mesh filter cartridge cover and screw the filter cartridge onto the water inlet on the spa wall by turning it clockwise. Store the second filter cartridge for later use.
-
Page 9: Operation
OPERATION You must ensure the water in the spa matches the water line printed on the spa wall. Never dry-run the power pack as such type of operation will void the warranty. CONTROL PANEL FUNCTIONS: Control Panel FILTER: Activates the filtration system. Pressing FILTER once will turn the filter pump on. Red indicator lamp will be lit. Pressing FILTER again will turn filter pump off. - Page 10 HEATER - Activates the heating system. Press HEATER once to turn heater on. Red indicator lamp will be lit. Press HEAT again to turn heater off. Red indicator lamp will turn off. Filter system will automatically start when heater is started. Heating system works on an internal thermostat.
-
Page 11: Cleaning The Filter Cartridge
CLEANING THE FILTER CARTRIDGE: 1. Unplug power pack from electrical receptacle before cleaning filter cartridge. 2. Unscrew the filter cartridge by turning counterclockwise. 3. Remove the filter cartridge cover. 4. The filter cartridge can be rinsed off with a garden hose and reused. However, if the filter cartridge remains soiled and discolored the filter cartridge should be replaced. -
Page 12: Troubleshooting
TROUBLE SHOOTING Here are some helpful tips to help you to diagnose and rectify some common sources of trouble. PROBLEM PROBABLE CAUSE SOLUTION • Air pump is too hot •Unplug the air pump. After the air pump has cooled, • Something is wrong with insert the plug and press the Jet button to activate. -
Page 13: Limited Warranty • Terms & Conditions
LIMITED WARRANTY • TERMS & CONDITIONS This warranty extends to the original purchaser only. The warranty period commences on the original purchase date through 3 MONTHS from date of purchase. The warranty is not transferable to subsequent owners. This warranty is subject to the limitations and exclusions listed below. EXTENT OF WARRANTY •... - Page 14 OWNER’S MANUAL MODELS: EST5868 | EST5870 | EST5880 110V, 60HZ, 1500W MANUFACTURER FOR THERAPURESPA, LAUDERDALE LAKES, FL 33311 READ THIS MANUAL IN ITS ENTIRETY PRIOR TO OPERATION. RETAIN MANUAL FOR FUTURE REFERENCE AND SPA MAINTENANCE. MADE IN CHINA...
