Summary of Contents for BATHCO DTC
- Page 1 DRAWER RUNNER INSTRUCTIONS...
- Page 2 How to Identify Your Drawer Style? Unclip cover to see which mechanism underneath to match to corresponding diagram below. Magic Box Harn Drawers DTC Drawers...
- Page 3 DTC DRAWER ASSEMBLY & ADJUSTMENT Remove Cover Unclip cover on both sides of drawer Up/Down Adjustment Left/Right Adjustment You can adjust the drawer left or right To adjust the doors up or down, turn the by turning the front screw clockwise or back screw clockwise or counter clockwise counter clockwise to the desired position.
- Page 4 DTC DRAWER REMOVAL Remove Cover Unclip cover on both sides of drawer Drawer Removal 1. Turn screw driver to release the drawer front. 2. Lift the release handle and pull out the drawer. When reinstalling, push the drawer fully in to engage the soft close mechanism.
